Where This Product Is Used
The Mitsubishi FX0S-14MR-001 is a compact, high-reliability programmable logic controller engineered for demanding industrial environments. Engineers and system integrators specify this unit across a wide range of automation applications:
- Packaging Machinery – Precise sequencing control for filling, sealing, and labeling lines where compact footprint and relay output reliability are critical.
- Conveyor & Material Handling Systems – Start/stop logic, speed interlocking, and fault detection across multi-zone conveyor networks.
- Injection Molding & Plastics Processing – Cycle timing, mold clamping sequences, and temperature interlock control.
- HVAC & Building Automation – Fan, pump, and valve sequencing in commercial and light industrial HVAC systems.
- Water Treatment & Pump Stations – Level-based pump control, alarm relay outputs, and remote monitoring integration.
- Machine Tool Auxiliary Control – Coolant, lubrication, and door interlock logic on CNC machining centers.
- Food & Beverage Processing – Wash-down-compatible panel installations with relay outputs driving solenoid valves and contactors.
Technical Specifications
- Model: FX0S-14MR-001
- Series: Mitsubishi FX0S
- Manufacturer: Mitsubishi Electric
- I/O Points: 14 (8 Inputs / 6 Outputs)
- Output Type: Relay (MR)
- Power Supply: AC 100–240 V
- Program Memory: 800 Steps
- Processing Speed: 1.6 µs / basic instruction
- Communication: RS-422 programming port
- Expansion: Up to 2 expansion modules (max 30 I/O)
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: –20 °C to 70 °C
- Humidity: 35–85% RH (non-condensing)
- Weight: Approx. 400 g
- Dimensions (W × H × D): 130 × 90 × 75 mm
- Certifications: CE, UL, cUL
Why Engineers Specify This Model
- Proven FX0S Platform – Part of Mitsubishi Electric’s long-running FX family, with decades of field-proven reliability in global manufacturing facilities.
- Relay Output Versatility – MR-type relay outputs switch both AC and DC loads without additional interface relays, simplifying panel wiring and reducing BOM cost.
- Compact DIN-Rail Form Factor – Fits into tight control panels where space is at a premium, without sacrificing I/O count or expandability.
- Simple Programming via GX Developer / GX Works2 – Compatible with Mitsubishi’s standard IEC 61131-3 ladder logic toolchain, minimizing retraining costs.
- Expandable Architecture – Supports FX0N-series expansion modules for analog I/O, additional digital points, and communication adapters.
- Low Total Cost of Ownership – Minimal maintenance requirements, long MTBF, and wide spare-parts availability reduce lifecycle costs.
Complete System Bill of Materials
For a complete FX0S-14MR-001-based control system, engineers typically specify the following companion components:
- FX0N-8EX – 8-point digital input expansion module
- FX0N-8EYR – 8-point relay output expansion module
- FX0N-3A – Analog I/O expansion (2 AI / 1 AO)
- SC-09 – RS-422 to RS-232C programming cable
- FX-20P-E – Handheld programmer unit
- GOT1000 / GOT2000 Series HMI – Mitsubishi touchscreen operator interface
- 24 VDC Power Supply (e.g., Mitsubishi MEE-24S5) – For sensor and I/O circuit power
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL 508 – Listed for industrial control equipment (USA & Canada)
- IEC 61131-2 – Programmable controller hardware standard
- RoHS Compliant – Restriction of Hazardous Substances
- IP20 Enclosure Rating – Suitable for installation inside control panels
Quality Assurance & Sourcing
Konmask.com sources the FX0S-14MR-001 through verified industrial distribution channels. Every unit undergoes the following quality checks before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware and hardware revision verification against Mitsubishi Electric documentation
- Anti-static packaging with humidity indicator cards for long-term storage protection
- Batch traceability records maintained for warranty and compliance purposes
We supply both new original and tested surplus units — condition is clearly stated on each listing. Contact us to confirm current stock condition and lead time.
How to Source This Part
- Add to Cart – In-stock units ship within 1–3 business days via DHL Express, FedEx, or UPS.
- Request a Quote – For quantities of 5+ units or project-based procurement, email support@konmask.com for volume pricing.
- Urgent Requirement? – Call or WhatsApp +0086 19859288691 for same-day response on critical downtime situations.
- Export & Cross-Border Orders – We ship globally with full commercial invoice and packing list documentation for customs clearance.
Application-Specific FAQ
Q: Can the FX0S-14MR-001 control a 3-phase motor directly?
A: No. The relay outputs are rated for up to 2A resistive load. Use the relay outputs to drive a motor contactor or soft starter — do not connect 3-phase motor loads directly to the PLC output terminals.
Q: Is this unit compatible with GX Works3?
A: The FX0S series is supported by GX Developer and GX Works2. GX Works3 does not support the FX0S/FX0N platform. Use GX Works2 (Version 1.492N or later) for programming.
Q: Can I expand the I/O beyond 14 points?
A: Yes. The FX0S-14MR-001 supports up to 2 FX0N-series expansion modules, bringing the maximum I/O to 30 points. Analog expansion (FX0N-3A) is also supported.
Q: What is the battery backup duration for the program memory?
A: The built-in lithium battery (CR2032 equivalent) provides approximately 5 years of program and data retention with power off. Replace when the battery low indicator activates.
Q: Is this suitable for food industry applications?
A: The FX0S-14MR-001 is IP20 rated and must be installed inside a sealed enclosure (minimum IP54) when used in food processing environments with washdown or high-humidity exposure.
