Industrial Automation Solution – Mitsubishi FX2N-48MT | FX2N Series
Where This Product Is Used
The Mitsubishi FX2N-48MT is a high-performance compact PLC widely deployed across demanding industrial environments. Typical application scenarios include:
- Automated Assembly Lines – Precise sequencing of robotic arms, conveyors, and pick-and-place stations in automotive and electronics manufacturing.
- Packaging Machinery – High-speed transistor outputs enable accurate control of servo drives and stepper motors in filling, sealing, and labeling machines.
- CNC & Machine Tool Control – Coordinates spindle start/stop, axis homing, and tool-change sequences in milling and turning centers.
- Material Handling Systems – Controls pallet conveyors, sorting gates, and lift tables in warehousing and logistics facilities.
- HVAC & Building Automation – Manages pump scheduling, valve actuation, and alarm annunciation in commercial building systems.
- Water Treatment Plants – Sequences dosing pumps, filtration cycles, and level control in municipal and industrial water systems.
- Textile & Printing Equipment – Synchronizes tension control, web feeding, and registration marks in high-speed printing lines.
Technical Specifications
| Model | FX2N-48MT |
| Series | Mitsubishi FX2N |
| Manufacturer | Mitsubishi Electric |
| Total I/O Points | 48 (24 Inputs / 24 Outputs) |
| Input Type | DC 24V Sink/Source |
| Output Type | Transistor (NPN Sink), 0.5A per point |
| Power Supply | AC 100–240V, 50/60Hz |
| Program Memory | 8,000 Steps (expandable to 16,000 with memory cassette) |
| Processing Speed | 0.08 µs / basic instruction |
| High-Speed Counters | 6 channels, up to 60 kHz |
| Built-in Communication | RS-422 (programming port) |
| Expansion Modules | Up to 8 expansion units / 128 additional I/O |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Humidity | 35% to 85% RH (non-condensing) |
| Weight | 1,120 g |
| Dimensions (W×H×D) | 285 × 90 × 87 mm |
| Protection Rating | IP20 |
| Certifications | CE, UL, cUL |
Why Engineers Specify This Model
- Transistor Output for High-Speed Applications – The MT suffix denotes transistor (non-contact) outputs, enabling pulse train output (PTO) for servo and stepper motor positioning without relay wear.
- Proven FX2N Platform – One of Mitsubishi’s most widely installed PLC families globally, with an extensive ecosystem of expansion modules, special function units, and third-party HMI compatibility.
- Compact DIN-Rail Footprint – Fits standard 35mm DIN rail; ideal for space-constrained control panels.
- Rich Instruction Set – Over 200 applied instructions including PID, floating-point math, and interrupt routines.
- Long-Term Parts Availability – Konmask.com maintains verified stock of FX2N-series modules to support legacy system maintenance and new builds alike.
Complete System Bill of Materials
For a complete FX2N-48MT control system, engineers typically specify the following companion components:
- FX2N-48MT – Main CPU unit (this product)
- FX2N-8EX / FX2N-16EX – Digital input expansion modules
- FX2N-8EYT / FX2N-16EYT – Transistor output expansion modules
- FX2N-4AD / FX2N-4DA – Analog input/output special function modules
- FX2N-232-BD / FX2N-485-BD – Communication expansion boards (RS-232/RS-485)
- FX2N-CNV-BD – Connector conversion board for BD module installation
- FX-EEPROM-8L – EEPROM memory cassette for program backup
- GOT2000 Series HMI – Mitsubishi touchscreen operator interface
- GX Works2 / GX Developer – Programming software (ladder, SFC, ST)
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive (LVD) and EMC Directive for European market deployment.
- UL / cUL Listed – Recognized under UL 508 (Industrial Control Equipment) for North American installations.
- RoHS Compliant – Meets EU Directive 2011/65/EU restrictions on hazardous substances.
- IEC 61131-3 – Programming conforms to international PLC programming language standards.
- SEMI S2 / S8 – Suitable for semiconductor equipment integration where applicable.
Quality Assurance & Sourcing
Konmask.com sources the FX2N-48MT exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition.
- Power-on functional verification confirming LED status indicators and communication port response.
- Authenticity check against Mitsubishi Electric serial number databases where applicable.
- Anti-static packaging with humidity indicator cards for safe international shipping.
All products are covered by Konmask’s 30-day return policy and backed by our technical support team.
How to Source This Part
- Add to Cart – Click “Add to Cart” above and proceed to checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Request a Quote – For bulk orders (5+ units) or project-based procurement, email support@konmask.com for a formal quotation with lead time confirmation.
- Expedited Shipping – DHL Express, FedEx International Priority, and UPS Worldwide available. Typical transit: 3–7 business days worldwide.
- OEM / System Integrator Accounts – Contact us to establish a trade account with volume pricing and priority allocation.
Application-Specific FAQ
Q: Can the FX2N-48MT output pulse trains for servo motor positioning?
A: Yes. The transistor (MT) outputs support high-speed pulse output (PLSY/PLSR instructions) up to 20 kHz on Y0 and Y1, making it suitable for single- or dual-axis servo/stepper positioning.
Q: Is the FX2N-48MT compatible with Mitsubishi GOT HMI panels?
A: Yes. It communicates natively with the GOT1000 and GOT2000 series via RS-422 or with an FX2N-232-BD/485-BD board for RS-232/RS-485 connectivity.
Q: Can I expand the I/O beyond 48 points?
A: Yes. Up to 8 expansion units can be connected, adding up to 128 additional I/O points (max 256 total I/O with special function modules counted).
Q: What programming software is required?
A: GX Works2 (recommended) or the legacy GX Developer software. Both support ladder diagram (LD), structured text (ST), and sequential function chart (SFC) programming.
Q: Is this unit suitable for replacement in an existing FX2N system?
A: Yes. The FX2N-48MT is a direct drop-in replacement for any existing FX2N-48MT installation. Programs stored on EEPROM cassettes are fully compatible.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com and our technical team will provide the official Mitsubishi FX2N hardware manual and wiring diagrams.
