Industrial Motion Control Solution – MKS AS00800-10 | SCOM CPCI Board Series
Where This Product Is Used
The MKS AS00800-10 (SCOM-0800) SCOM CPCI Board is deployed across demanding industrial environments where high-speed serial communication and compact PCI bus integration are mission-critical. Typical deployment scenarios include:
- CNC Machine Tool Controllers – Provides the SCOM communication backbone for multi-axis servo drive coordination in precision machining centers.
- Semiconductor Fabrication Equipment – Used in wafer handling and lithography systems requiring deterministic, low-latency data exchange between motion controllers and drives.
- Industrial Robot Controllers – Integrates into CPCI-based robot controller racks for real-time axis synchronization.
- Drive System Integration (Siemens SINAMICS) – Cross-referenced as 6SL3130-6AE15-0AB0, this board interfaces directly with SINAMICS drive platforms for SCOM protocol communication.
- Automated Production Lines – Embedded in CPCI chassis within PLC/motion controller cabinets for high-throughput manufacturing automation.
Technical Specifications
- Manufacturer: MKS (also cross-referenced with Siemens SINAMICS platform)
- Primary Part Number: AS00800-10
- Alternate / Cross-Reference SKUs: SCOM-0800 | 0190-41127 | 0021-39792 | 6SL3130-6AE15-0AB0
- Board Type: SCOM CPCI (Compact PCI) Communication Board
- Form Factor: CompactPCI (CPCI) — 3U or 6U compatible (verify with system chassis spec)
- Communication Protocol: SCOM (Serial Communication) — high-speed synchronous serial bus
- Interface: CPCI backplane bus
- Application Domain: Motion control, drive communication, industrial automation
- Weight: Approx. 20 g (bare board)
- Condition Available: New OEM / Tested Refurbished / Exchange
Why Engineers Specify This Model
- Multi-SKU Interoperability: Recognized under four cross-reference numbers (AS00800-10, SCOM-0800, 0190-41127, 0021-39792, 6SL3130-6AE15-0AB0), making it a verified drop-in replacement across multiple OEM BOM revisions.
- SCOM Protocol Native Support: Eliminates the need for protocol converters — the board natively handles SCOM serial communication, reducing latency and improving determinism.
- CPCI Standard Compliance: Hot-swap capable CPCI form factor supports high-availability system designs with minimal downtime during maintenance.
- Proven in Siemens SINAMICS Ecosystems: The 6SL3130-6AE15-0AB0 cross-reference confirms validated compatibility with SINAMICS S120 and related drive families.
- Long-Term Availability: Konmask maintains stock of legacy and current-generation CPCI boards to support installed base maintenance without forced system upgrades.
Complete System Bill of Materials
When integrating the MKS AS00800-10 SCOM CPCI Board, engineers typically source the following complementary components:
- CPCI Chassis / Backplane (3U or 6U, matching slot count)
- SINAMICS S120 Control Unit (CU320-2 or equivalent) — if used in Siemens drive topology
- DRIVE-CLiQ cables or SCOM fiber-optic cables (application-dependent)
- Power Supply Module (PSM) compatible with SINAMICS S120 booksize or chassis format
- Motor Module (MM) — single-axis or double-axis, matched to motor rating
- Encoder feedback module (SMC20 / SMC30) for closed-loop axis control
- PLC CPU module (e.g., Siemens S7-300/400 or equivalent MKS controller)
Contact Konmask for complete BOM sourcing assistance: [email protected]
Compliance & Industry Standards
- CompactPCI (CPCI) Standard: PICMG 2.0 R3.0 compliant form factor
- CE Marking: Applicable for EU machinery directive compliance (verify with system integrator)
- RoHS: Confirm RoHS status with batch documentation — available upon request
- ISO 9001: Sourced from ISO 9001-certified supply chain partners
- IEC 61131: Compatible with IEC 61131-3 compliant PLC environments
Quality Assurance & Sourcing
Every MKS AS00800-10 SCOM CPCI Board shipped by Konmask undergoes the following quality process:
- Visual Inspection: PCB, connectors, and component integrity checked against OEM reference standards.
- Functional Verification: Where applicable, boards are bench-tested for SCOM communication link establishment and CPCI bus enumeration.
- Traceability: Batch and serial number documentation provided with each unit.
- Packaging: Anti-static ESD packaging with desiccant — compliant with IPC/JEDEC J-STD-033 moisture sensitivity handling.
- Warranty: 90-day replacement warranty on all verified units. Extended warranty available on request.
How to Source This Part
- Add to Cart directly on this page for in-stock units.
- Request a Quote for volume orders (>3 units) or exchange/repair programs — email [email protected].
- Provide your cross-reference number (AS00800-10 / SCOM-0800 / 0190-41127 / 0021-39792 / 6SL3130-6AE15-0AB0) when contacting us to ensure exact part matching.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock units: 2–6 weeks sourcing lead time.
- Global Shipping: DHL / FedEx / UPS express available to 150+ countries.
Application-Specific FAQ
Q: Is the MKS AS00800-10 a direct replacement for 6SL3130-6AE15-0AB0?
A: Yes. The 6SL3130-6AE15-0AB0 is a recognized cross-reference for this board within SINAMICS-compatible systems. Always verify firmware revision compatibility with your system integrator before installation.
Q: What CPCI chassis slot does this board occupy?
A: The SCOM-0800 occupies a standard CPCI peripheral slot. Confirm slot type (3U/6U, 32-bit/64-bit bus width) against your chassis specification sheet.
Q: Can this board be used in a hot-swap configuration?
A: CPCI standard supports hot-swap; however, hot-swap capability depends on the chassis backplane and system software support. Consult your system documentation.
Q: Do you provide firmware or software drivers?
A: Konmask supplies hardware only. Firmware and driver packages are available from the OEM (MKS / Siemens). Contact us for OEM documentation support.
Q: What is the minimum order quantity?
A: MOQ is 1 unit. Volume pricing available for orders of 3+ units.
