MOOG G392-024-020-001 – Brushless AC Servo Amplifier | G392 Series Motion Control Platform
Engineering Background: The MOOG G392 Series represents MOOG Inc.’s high-performance servo amplifier platform engineered for demanding closed-loop motion control applications. Designed to interface directly with brushless AC servo motors, the G392-024-020-001 delivers precise torque, velocity, and position control across a wide range of industrial environments. MOOG’s servo technology is trusted globally in aerospace ground support, CNC machining centers, semiconductor handling, and advanced robotics.
Product Positioning: The G392-024-020-001 is a compact, high-bandwidth servo amplifier targeting OEM machine builders and system integrators who require deterministic motion performance, robust fault diagnostics, and seamless integration into multi-axis motion architectures. It is the preferred choice for procurement engineers sourcing a drop-in replacement or upgrade for existing MOOG G392 platform installations.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | G392-024-020-001 |
| Manufacturer | MOOG Inc. |
| Series | G392 Servo Amplifier Series |
| Drive Type | Brushless AC Servo Amplifier |
| Continuous Output Current | 20 A (RMS) |
| Peak Output Current | 40 A (RMS, typical) |
| Supply Voltage | 24 VDC Control / AC Bus Input |
| Control Modes | Torque / Velocity / Position |
| Feedback Interface | Resolver / Encoder (application dependent) |
| Communication | Analog ±10 V, Step/Direction, Serial |
| Protection Class | Over-current, Over-voltage, Under-voltage, Over-temperature, Short-circuit |
| Operating Temperature | 0 °C to +45 °C |
| Storage Temperature | -25 °C to +70 °C |
| Weight | Approx. 400 g |
| Compliance | CE Marked |
Proven Application Environments
- CNC Machining Centers: Multi-axis contouring with sub-micron repeatability requirements
- Industrial Robotics: Joint-level torque control for articulated and SCARA robot arms
- Semiconductor & Electronics Manufacturing: High-speed pick-and-place and wafer handling stages
- Aerospace Ground Support Equipment: Actuator control for test rigs and flight simulation platforms
- Printing & Packaging Machinery: Tension control and register synchronization
- Medical Device Manufacturing: Precision dispensing and surgical tool positioning systems
Engineering Advantages
- High Bandwidth Torque Loop: Enables fast dynamic response for demanding servo applications
- Compact Form Factor: Optimized for panel-mount integration in space-constrained control cabinets
- Comprehensive Fault Diagnostics: Real-time fault codes reduce MTTR during commissioning and field service
- Multi-mode Control: Single unit supports torque, velocity, and position loop closure — reducing BOM complexity
- MOOG Ecosystem Compatibility: Direct compatibility with MOOG brushless servo motors and motion controllers
- Proven Field Reliability: Deployed in mission-critical OEM platforms with documented MTBF performance
System Architecture & Signal Flow
The G392-024-020-001 operates as a standalone servo amplifier within a cascaded control loop architecture:
- Command Input: Receives analog ±10 V velocity/torque reference or digital step/direction signals from the host motion controller or CNC
- Feedback Processing: Resolver or encoder feedback is decoded and processed by the internal DSP for real-time position/velocity estimation
- Current Loop: High-frequency PWM switching regulates phase currents to the brushless AC servo motor with minimal ripple
- Fault Monitoring: Continuous hardware and firmware monitoring of bus voltage, phase currents, and thermal sensors — fault relay output available for PLC interlock
- Enable/Inhibit Logic: Hardware enable input compatible with safety relay circuits and STO (Safe Torque Off) architectures
Sourcing & Quality Verification
All MOOG G392-024-020-001 units supplied by Konmask.com are sourced through verified industrial surplus and authorized distribution channels. Each unit undergoes the following pre-shipment process:
- Visual inspection for physical damage, corrosion, and counterfeit indicators
- Label and date-code verification against MOOG factory standards
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Certificate of conformance available upon request
Konmask.com maintains a strict no-counterfeit policy. All parts are traceable and backed by our quality guarantee.
Procurement Process
- Inquiry: Submit your RFQ via support@konmask.com or WhatsApp +0086 19859288691 with quantity and required delivery date
- Quotation: Receive a formal quotation within 24 business hours including lead time and shipping options
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for payment
- Payment: T/T bank transfer, PayPal, or other agreed terms
- Shipment: DHL / FedEx / UPS express with full tracking; export documentation provided
- After-sales: 90-day warranty on verified functional units; technical support available
Technical FAQ
Q: Is the G392-024-020-001 compatible with non-MOOG servo motors?
A: The amplifier is optimized for MOOG brushless AC motors. Use with third-party motors requires careful matching of feedback type, pole count, and current ratings — consult our technical team before ordering.
Q: What feedback devices are supported?
A: The G392-024-020-001 supports resolver and incremental encoder feedback depending on the firmware and hardware variant. Confirm your motor feedback type before procurement.
Q: Can this drive be used as a direct replacement for a failed unit?
A: Yes, provided the replacement unit carries the identical part number G392-024-020-001. Parameter settings may need to be re-entered via the configuration interface — contact us for commissioning guidance.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Technical documentation is available upon request for verified procurement inquiries. Contact support@konmask.com.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 1–3 business days. Lead time for sourced units is quoted individually based on availability.
