Precision Motion Control Solution — MOOG D638-177-0001 R02TB1F0HSS2MBOK1B1 | D638 Series
Where This Product Is Used
The MOOG D638-177-0001 R02TB1F0HSS2MBOK1B1 electrohydraulic servo control valve is engineered for high-demand industrial applications where precise, repeatable hydraulic flow control is non-negotiable. Typical deployment environments include:
- CNC Machining Centers & Grinding Machines — axis feed control, spindle clamping, and tool-change cylinders requiring sub-millisecond response.
- Injection Molding Machines — injection speed and pressure profiling, clamp force control, and back-pressure regulation on hydraulic presses up to 4,000-ton class.
- Die Casting & Forging Presses — shot-end velocity control and intensifier sequencing where thermal stability and contamination tolerance are critical.
- Hydraulic Test Rigs & Fatigue Testing Systems — servo-controlled load frames in aerospace, automotive, and materials-testing laboratories.
- Steel Mill & Rolling Mill Equipment — roll-gap control, looper tension, and AGC (Automatic Gauge Control) systems.
- Simulation & Motion Platforms — flight simulators, driving simulators, and 6-DOF hexapod platforms demanding high bandwidth and low hysteresis.
- Turbine Governor & Power Generation — steam and hydro turbine speed-governing systems requiring fail-safe spring-return behavior.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | MOOG Inc. |
| Part Number | D638-177-0001 |
| Configuration Code | R02TB1F0HSS2MBOK1B1 |
| Series | D638 (3-Stage Electrohydraulic Servo Valve) |
| Valve Type | Electrohydraulic Servo Control Valve |
| Stages | 3-Stage (Torque Motor → Nozzle-Flapper → Spool) |
| Rated Flow | Refer to MOOG D638 series datasheet (model-specific) |
| Rated Pressure | Up to 350 bar (5,000 psi) supply |
| Electrical Interface | Per configuration code (see R02TB1F0HSS2MBOK1B1 decode) |
| Feedback Type | Mechanical / LVDT (per configuration) |
| Hysteresis | < 1% (typical MOOG D638 class) |
| Weight | 3,500 g (approx.) |
| HS Code | 8481.20.00 |
| Country of Origin | USA |
Full performance curves and dimensional drawings available upon request. Contact support@konmask.com.
Why Engineers Specify This Model
- 3-Stage Architecture — the pilot-stage torque motor drives a nozzle-flapper second stage, which in turn positions the main spool. This cascade design delivers exceptional power gain with minimal electrical input, enabling precise control of large hydraulic actuators.
- Low Hysteresis & Threshold — MOOG D638 valves are benchmarked for <1% hysteresis, critical for closed-loop position and force control where deadband causes instability.
- High Bandwidth — suitable for control loops operating at 50–100 Hz, making this valve compatible with modern digital servo controllers (Bosch Rexroth, Parker, Siemens SIMOTION).
- Contamination Tolerance — internal filtration and hardened metering edges extend service life in real-world hydraulic circuits where ISO 4406 cleanliness is difficult to maintain.
- Drop-In Replacement Compatibility — D638 series mounts conform to ISO 4401 / CETOP interface standards, simplifying retrofit and OEM integration.
- Proven Field Reliability — MOOG D638 valves are specified by OEMs across aerospace, automotive, and heavy industry for their documented MTBF performance.
Complete System Bill of Materials
For a fully operational electrohydraulic servo axis using this valve, engineers typically source the following complementary components:
- Servo Amplifier / Valve Driver Card (e.g., MOOG T200, Bosch VT-VSPA2)
- Linear Position Transducer / LVDT (for closed-loop feedback)
- Hydraulic Power Unit (HPU) with pressure-compensated pump
- High-Pressure Filter (β₁₀ ≥ 200, ISO 4406 Class 16/14/11 or better)
- Accumulator (for peak-demand buffering)
- Manifold Block (ISO 4401-05 or custom porting)
- PLC / Motion Controller with analog ±10 V or fieldbus output
Konmask.com can assist in sourcing complementary automation components. Contact us for a full BOM quotation.
Compliance & Industry Standards
- ISO 4401 — Hydraulic fluid power; four-port directional control valves; mounting surfaces.
- ISO 10770 — Hydraulic fluid power; electrically modulated hydraulic control valves; test methods.
- CETOP RP 121H — Mounting interface compatibility.
- RoHS / REACH — Confirm with MOOG material declaration for specific production batch.
- CE Marking — As applicable per MOOG product documentation.
Quality Assurance & Sourcing
Konmask.com specializes in the procurement of industrial automation and motion control components from globally recognized manufacturers. Every unit offered through our platform is:
- Sourced from authorized distributors or verified surplus channels with full traceability.
- Inspected for physical integrity, label authenticity, and packaging condition prior to dispatch.
- Accompanied by available documentation (test certificates, conformity declarations) upon request.
- Supported by our technical team for pre-sale specification confirmation and post-sale application support.
How to Source This Part
- Request a Quote — Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Confirm Specifications — Our engineers will verify the configuration code R02TB1F0HSS2MBOK1B1 against your application requirements.
- Receive Proforma Invoice — Pricing is provided in USD/HKD with DDP, DAP, or EXW Incoterms options.
- Dispatch & Tracking — Units ship from our warehouse with full export documentation. Express air freight available for urgent requirements.
- After-Sales Support — Installation guidance, commissioning support, and warranty claim assistance provided by our technical team.
Application-Specific FAQ
Q: Can this valve replace a MOOG D633 or D634 series valve in my existing machine?
A: The D638 series is a 3-stage design versus the 2-stage D633/D634. While flow ratings may overlap, the dynamic response and electrical interface differ. Contact us for a cross-reference analysis before substitution.
Q: What hydraulic fluid is compatible with the D638-177-0001?
A: MOOG D638 valves are designed for mineral oil (ISO VG 32/46) as standard. Fire-resistant fluids (HFA, HFB, HFC, HFD) require specific seal configurations — confirm via the configuration code or MOOG datasheet.
Q: What is the lead time for this part number?
A: Lead time depends on current stock availability. Contact Konmask.com for real-time inventory status. Express sourcing from global distribution networks is available for urgent shutdowns.
Q: Do you provide a warranty on this valve?
A: Yes. Konmask.com provides a standard 90-day warranty against defects in material and workmanship for all components sourced through our platform. Extended warranty options are available upon request.
Q: Can you supply the MOOG servo amplifier card to drive this valve?
A: Yes. We stock and source MOOG T200 series amplifiers and compatible third-party valve driver cards. Include your control system details in your inquiry for a matched recommendation.
