Precision Motion Control Solution – MOOG IMI220-411A001 | TMC400 Series
The MOOG IMI220-411A001 is a high-performance Total Machine Controller from the TMC400 Series, engineered for demanding industrial motion control applications where synchronization, speed, and reliability are non-negotiable. Trusted by machine builders and OEMs worldwide, this controller integrates seamlessly into complex multi-axis systems, delivering deterministic real-time control across a wide range of industrial environments.
Where This Product Is Used
The IMI220-411A001 is deployed across a broad spectrum of high-precision industrial applications:
- Injection Molding Machines – Precise closed-loop control of clamp, injection, and ejection axes for consistent cycle repeatability
- Metal Forming & Stamping Presses – Synchronized multi-axis motion for die cushion and slide control
- Plastics Extrusion Lines – Speed and tension regulation across multiple driven zones
- Textile & Converting Machinery – Web tension control and register synchronization
- Test & Simulation Rigs – High-bandwidth force and position control for fatigue and durability testing
- Packaging Machinery – High-speed pick-and-place and servo-driven filling/sealing systems
- Semiconductor & Electronics Manufacturing – Ultra-precise positioning for wafer handling and PCB assembly
- Hydraulic Press Systems – Electrohydraulic motion control with real-time feedback
Technical Specifications
- Part Number: IMI220-411A001
- Series: TMC400 – Total Machine Controller
- Manufacturer: MOOG Inc.
- Controller Type: Multi-axis motion controller / machine controller
- Architecture: Real-time deterministic control platform
- Communication Interfaces: EtherCAT, CANopen, Ethernet (application-dependent)
- Programming Environment: IEC 61131-3 compliant (ST, LD, FBD, SFC)
- I/O Capability: Expandable digital and analog I/O via fieldbus modules
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -25°C to +70°C
- Power Supply: 24 VDC nominal
- Enclosure Rating: IP20 (panel-mount)
- Weight: Approx. 80 g (controller card)
- Certifications: CE marked; RoHS compliant
Why Engineers Specify This Model
- Deterministic Real-Time Performance – Hard real-time cycle times ensure precise synchronization across all axes without jitter
- Unified Machine Control – Combines PLC logic, motion control, and HMI communication in a single platform, reducing panel complexity
- MOOG Ecosystem Integration – Native compatibility with MOOG servo drives, amplifiers, and actuators for optimized system tuning
- Scalable Architecture – Supports single-axis to complex multi-axis configurations without hardware redesign
- Proven Reliability – MOOG’s industrial-grade components are rated for continuous 24/7 operation in harsh factory environments
- Open Standards Compliance – IEC 61131-3 programming ensures portability and reduces vendor lock-in for machine builders
Complete System Bill of Materials
The IMI220-411A001 is typically deployed as part of a complete MOOG motion control system. Common companion components include:
- MOOG Servo Drives (D136 / D137 Series) – Axis drives for brushless servo motors
- MOOG Servo Motors (G Series / BN Series) – Matched actuators for closed-loop axes
- MOOG I/O Expansion Modules – Digital/analog I/O for machine interfacing
- EtherCAT Fieldbus Couplers – For distributed I/O architectures
- 24 VDC Power Supply Unit – Regulated DIN-rail PSU (e.g., Phoenix Contact, PULS)
- Safety Relay / STO Module – For SIL 2 / PLd safety circuit integration
- HMI Panel (third-party compatible) – Modbus TCP or OPC-UA connected operator interface
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU
- RoHS Directive 2011/65/EU – Restriction of hazardous substances
- IEC 61131-3 – Programming language standard for industrial controllers
- IEC 61800-5-2 – Functional safety requirements for adjustable speed drive systems
- ISO 13849 / EN 954-1 – Safety of machinery, safety-related control systems
- UL Listed – Suitable for North American market deployment (verify with current datasheet)
Quality Assurance & Sourcing
At Konmask.com, every MOOG IMI220-411A001 unit is sourced through verified industrial supply channels. Our quality process includes:
- Visual and dimensional inspection upon receipt
- Authenticity verification against MOOG part number and serial number databases
- Functional bench testing where applicable
- Anti-static packaging and climate-controlled storage
- Full traceability documentation available on request
We supply both new original and factory-refurbished units, clearly labeled and priced accordingly. All units ship with a minimum 90-day warranty.
How to Source This Part
- Click Add to Cart or Request a Quote on this page
- Provide your required quantity, delivery timeline, and destination country
- Our technical team will confirm availability, lead time, and pricing within 24 hours
- Payment via T/T bank transfer, PayPal, or credit card (Visa/Mastercard)
- Worldwide shipping via DHL, FedEx, or UPS with full tracking and export documentation
Application-Specific FAQ
Q: Can the IMI220-411A001 control hydraulic axes as well as electric servo axes?
A: Yes. The TMC400 platform supports electrohydraulic control via analog ±10V command outputs, making it suitable for hybrid electric-hydraulic machine architectures.
Q: Is this controller compatible with third-party servo drives?
A: The TMC400 supports standard EtherCAT and CANopen drives from other manufacturers, though optimal performance is achieved with MOOG’s native drive ecosystem.
Q: What programming software is required?
A: MOOG’s proprietary programming environment (based on IEC 61131-3) is used. Contact MOOG or your local distributor for software licensing.
Q: Can I replace an existing TMC400 controller without re-programming?
A: If the replacement unit has the same firmware version and hardware revision, configuration backup/restore is typically straightforward. Always verify firmware compatibility before swapping.
Q: Do you provide installation or commissioning support?
A: Konmask.com provides pre-sales technical consultation. For on-site commissioning, we can refer you to certified MOOG system integrators in your region.
