Moore Industries 16137-174 – Industrial Communications Module | NET Series Platform
Engineering Background
Moore Industries International has been a cornerstone of process automation signal conditioning since 1968. The 16137-174 is a factory-configured communications module engineered for demanding industrial environments where signal integrity, protocol translation, and loop-powered reliability are non-negotiable. Designed to bridge legacy field instruments with modern DCS, SCADA, and PLC architectures, this module delivers deterministic performance across continuous process industries.
Product Positioning
The 16137-174 targets procurement engineers and systems integrators sourcing a verified, OEM-traceable communications interface module for process control upgrades, panel retrofits, or spare-parts inventory. It is a direct-fit replacement and expansion component within Moore Industries’ NET Series ecosystem, ensuring backward compatibility and long-term supportability.
Complete Technical Specifications
| Part Number / SKU | 16137-174 |
| Manufacturer | Moore Industries International, Inc. |
| Product Series | NET Series Communications Platform |
| Module Type | Industrial Communications / Signal Interface Module |
| Form Factor | DIN-rail / Panel-mount compatible |
| Operating Temperature | -40°C to +85°C (standard industrial range) |
| Power Supply | Loop-powered / 24 VDC nominal (refer to datasheet for variant) |
| Signal Interface | 4–20 mA HART / RS-485 / proprietary NET bus (configuration-dependent) |
| Isolation | Galvanic isolation, channel-to-channel and channel-to-power |
| Enclosure Rating | IP20 (panel-mount); consult factory for hazardous-area variants |
| Approvals | CE, UL Listed, FM (configuration-dependent) |
| Weight | Approx. 440 g |
| Country of Origin | United States |
| HS Code | 8537.10 (programmable controllers / signal interface modules) |
Note: Full electrical specifications are available in the Moore Industries 16137-174 datasheet. Contact Konmask.com for the latest revision.
Proven Application Environments
- Oil & Gas: Upstream wellhead RTU communications, pipeline SCADA integration, and offshore platform signal marshalling.
- Chemical & Petrochemical: Distributed control system (DCS) I/O expansion and field device multiplexing in hazardous-area panels.
- Power Generation: Turbine control panel signal conditioning and protocol bridging between legacy PLCs and modern HMI systems.
- Water & Wastewater: Remote telemetry unit (RTU) communications interface for SCADA-connected pump stations and treatment facilities.
- Pharmaceutical & Food Processing: cGMP-compliant process monitoring loops requiring galvanically isolated signal paths.
- Pulp & Paper / Mining: Harsh-environment panel installations requiring extended temperature range and vibration tolerance.
Engineering Advantages
- OEM-Verified Traceability: Every unit sourced through Konmask.com is traceable to Moore Industries’ authorized supply chain, with full part-number and date-code documentation available on request.
- Galvanic Isolation: Eliminates ground loops and protects sensitive instrumentation from common-mode noise — critical in multi-drop 4–20 mA and RS-485 networks.
- Wide Temperature Tolerance: Rated for industrial extremes, reducing the need for panel air conditioning in outdoor or semi-outdoor enclosures.
- Protocol Flexibility: Supports HART pass-through and multi-drop configurations, enabling asset management software integration without additional hardware.
- Long-Term Availability: Moore Industries maintains extended product lifecycles; Konmask.com stocks current and legacy variants to support brownfield plant maintenance.
- Drop-In Replacement: Mechanically and electrically compatible with existing NET Series backplane installations — no rewiring required for like-for-like swap.
System Architecture & Signal Flow
The 16137-174 operates as a communications interface node within the Moore Industries NET Series backplane architecture. In a typical deployment:
- Field Instruments (transmitters, analyzers, positioners) output 4–20 mA ± HART signals to the module’s input terminals.
- The 16137-174 module performs signal conditioning, isolation, and protocol conversion on the NET Series backplane.
- Conditioned signals are transmitted via RS-485 / NET bus to the host DCS, PLC, or SCADA system over distances up to 1,200 m (RS-485 standard).
- The host system receives clean, isolated, protocol-compliant data for process monitoring, alarming, and control.
This architecture eliminates point-to-point wiring runs from field to control room, reducing installation cost and improving signal integrity in electrically noisy plant environments.
Sourcing & Quality Verification
Konmask.com operates as a specialist distributor of industrial automation components with a focus on verified, traceable supply. Our quality assurance process for the Moore Industries 16137-174 includes:
- Visual inspection against Moore Industries OEM packaging and labeling standards.
- Part number and date-code verification against manufacturer records.
- Functional power-on verification where applicable.
- Anti-counterfeit screening: UV marking check, PCB silkscreen verification, and connector tolerance inspection.
- Secure ESD-safe packaging for international shipment.
Certificate of Conformance (CoC) and test reports are available upon request for regulated industries.
Procurement Process
- Submit RFQ: Email support@konmask.com or call +0086 19859288691 with your required quantity, delivery timeline, and any special documentation requirements.
- Quotation: Receive a formal quotation within 1 business day, including unit price, lead time, and shipping options (DHL / FedEx / sea freight).
- Order Confirmation: Place order via purchase order (PO), PayPal, T/T bank transfer, or Shopify checkout.
- Quality Inspection & Dispatch: Units are inspected, documented, and dispatched within 3–5 business days. Tracking number provided upon shipment.
- After-Sales Support: 12-month warranty on verified OEM units. Technical support available via email for installation and commissioning queries.
Technical FAQ
Q: Is the 16137-174 a new or refurbished unit?
A: Konmask.com stocks both new OEM and professionally refurbished units. Condition is clearly stated on each quotation. New units carry full Moore Industries warranty; refurbished units carry Konmask.com’s 12-month functional warranty.
Q: Can this module be used as a direct replacement for an existing NET Series installation?
A: Yes. The 16137-174 is designed for drop-in replacement within compatible NET Series backplane configurations. Confirm your backplane model and slot assignment before ordering — our technical team can assist.
Q: What communication protocols does the 16137-174 support?
A: The module supports HART (pass-through and multi-drop), RS-485 Modbus RTU, and Moore Industries’ proprietary NET bus protocol. Specific protocol configuration depends on the factory firmware version. Contact us for datasheet confirmation.
Q: Is export documentation available for international shipments?
A: Yes. We provide commercial invoice, packing list, Certificate of Origin, and CoC as standard. ECCN classification and export license support available for regulated destinations.
Q: What is the lead time for bulk orders (>10 units)?
A: Standard stock orders ship within 3–5 business days. For bulk or project quantities, lead time is quoted individually based on current inventory. Contact us early in your project planning cycle.
