NORGREN VAC030-S4-S4 Servo Drive Board | IMI Precision Engineering
Engineering Background
NORGREN, a flagship brand of IMI Precision Engineering, has been a global leader in motion and fluid control technology for over 90 years. The VAC030 series represents NORGREN’s dedicated servo drive electronics platform, engineered for demanding industrial automation environments where precision, reliability, and signal integrity are non-negotiable.
Product Positioning
The NORGREN VAC030-S4-S4 is a factory-original servo drive board designed as a core control component within NORGREN’s VAC030 servo actuator ecosystem. It serves as the intelligence layer between the motion controller and the servo actuator, processing command signals and delivering precise drive outputs. This part is sourced directly from authorized distribution channels and is verified against OEM specifications before shipment.
Complete Technical Specifications
| Part Number | VAC030-S4-S4 |
| Manufacturer | NORGREN (IMI Precision Engineering) |
| Product Series | VAC030 |
| Component Type | Servo Drive Board (PCB Assembly) |
| Input Signal Type | S4 – Analog / Digital Command Interface |
| Output Interface | S4 – Servo Motor Drive Output |
| Mounting | Internal PCB, integrated within VAC030 actuator housing |
| Weight | Approx. 600 g (packaged) |
| Condition | New / Surplus New (OEM) |
| Compliance | CE, RoHS |
| Country of Origin | Germany / UK (IMI Group) |
Proven Application Environments
- Semiconductor wafer handling and precision positioning systems
- Automated assembly lines requiring closed-loop servo feedback
- Packaging machinery with high-cycle servo actuator demands
- Medical device manufacturing with strict motion repeatability requirements
- Robotics end-effector control and multi-axis servo coordination
- Test & measurement equipment requiring stable drive electronics
Engineering Advantages
- OEM-Grade Signal Fidelity: Factory-designed PCB ensures zero signal degradation versus aftermarket alternatives
- Drop-In Replacement: Direct form-fit-function replacement for VAC030 series actuators — no recalibration required
- Thermal Stability: Industrial-grade components rated for continuous duty in elevated ambient temperatures
- EMI Shielding: Integrated board-level EMI suppression for noise-sensitive automation environments
- Rapid Commissioning: Plug-and-play compatibility with existing VAC030 wiring harnesses and connectors
System Architecture & Signal Flow
The VAC030-S4-S4 board operates within a closed-loop servo architecture:
- Command Input (S4 Interface): Receives position, velocity, or torque commands from the upstream motion controller via the S4 analog/digital interface
- Signal Processing: On-board DSP logic interprets command signals and generates PWM drive waveforms
- Power Stage Drive (S4 Output): Delivers conditioned drive signals to the servo motor windings within the VAC030 actuator
- Feedback Loop: Encoder or resolver feedback is processed on-board to maintain closed-loop position accuracy
- Fault Detection: Integrated protection circuits monitor over-current, over-temperature, and communication faults
Sourcing & Quality Verification
- All NORGREN parts at Konmask.com are sourced from authorized distributors or verified surplus channels
- Each unit undergoes visual inspection and part number verification prior to listing
- Original manufacturer packaging and labeling preserved where available
- Traceability documentation available upon request for regulated industries
- Anti-counterfeit verification: holographic labels and OEM markings cross-checked against NORGREN/IMI databases
Procurement Process
- Confirm Compatibility: Verify your VAC030 actuator variant accepts the S4-S4 drive board configuration
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation
- Place Order: Secure checkout via Konmask.com with HKD/USD pricing; wire transfer and PayPal accepted
- Shipping: DHL / FedEx Express worldwide; export documentation included for cross-border shipments
- After-Sales: 30-day DOA warranty; technical support available from our engineering team
Technical FAQ
Q: Is the VAC030-S4-S4 compatible with all VAC030 actuator variants?
A: The S4-S4 designation specifies both the input command interface and output drive interface. Confirm your actuator’s interface codes before ordering. Contact us if unsure.
Q: Can this board be used as a standalone servo drive?
A: No. The VAC030-S4-S4 is an integrated PCB assembly designed exclusively for installation within the NORGREN VAC030 actuator housing. It is not a standalone drive unit.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock inquiries, typical lead time is 2–6 weeks depending on sourcing channel. Contact us for real-time availability.
Q: Do you provide installation support?
A: Yes. Our engineering team can provide wiring diagrams, installation guidance, and commissioning support via email or video call.
Q: Is this a new or refurbished part?
A: We stock both new OEM and verified surplus-new units. Condition is clearly stated on each listing. Refurbished units are not sold without explicit disclosure.
