NTron AV56A-1XFX6YXGP50 Encoder – High-Resolution Incremental Position Feedback | NTron AV Series
Engineering Background
The NTron AV56A-1XFX6YXGP50 is a 56 mm body incremental encoder engineered for demanding industrial motion-control and position-feedback applications. Built on NTron’s proven AV Series platform, it delivers reliable quadrature output with robust EMI immunity, making it the preferred choice for servo drives, CNC axes, conveyor systems, and process automation lines where signal integrity is non-negotiable.
Product Positioning
Targeted at OEM machine builders and MRO procurement engineers who require a drop-in replacement or new-build encoder with guaranteed dimensional and electrical compatibility. Konmask.com supplies this unit from verified OEM-authorized channels with full traceability documentation available on request.
Complete Technical Specifications
- Part Number: AV56A-1XFX6YXGP50
- Manufacturer: NTron
- Series / Platform: AV Series – 56 mm Incremental Encoder
- Encoder Type: Incremental, Optical
- Output Type: Quadrature (A, B, Z channels)
- Resolution (PPR): 50 Pulses Per Revolution
- Output Circuit: Push-Pull (Totem Pole)
- Supply Voltage: 5–26 V DC
- Max Shaft Speed: 6,000 RPM (mechanical)
- Shaft Diameter: 6 mm solid shaft
- Housing Diameter: 56 mm
- Protection Rating: IP50
- Operating Temperature: −10 °C to +70 °C
- Connector / Cable Exit: Axial cable exit (GP-style)
- Weight: approx. 600 g (with mounting hardware)
- Compliance: CE, RoHS
Proven Application Environments
- CNC machine tool spindle and axis feedback
- Servo motor position sensing on packaging lines
- Conveyor speed and distance measurement
- Printing and converting machine registration control
- Textile and winding machine tension control
- Robotics joint position feedback
- Material handling and AGV navigation
Engineering Advantages
- Compact 56 mm body – fits standard servo motor flanges without adapter plates
- Wide supply voltage range (5–26 V DC) – compatible with both 5 V TTL and 24 V PLC I/O cards
- Push-pull output – drives long cable runs without external line drivers
- Optical sensing element – immune to magnetic field interference common in motor enclosures
- IP50 sealed housing – protects against dust ingress in open-panel environments
- Z-channel index pulse – enables homing routines and absolute position recovery after power cycle
System Architecture & Signal Flow
The AV56A-1XFX6YXGP50 generates two 90°-phase-shifted square-wave channels (A and B) plus a once-per-revolution index pulse (Z). The controller reads the quadrature pair to determine both direction and incremental position. The push-pull output stage sources and sinks current, allowing direct connection to differential-input receiver cards or single-ended PLC high-speed counter modules without additional buffering. Recommended cable: shielded twisted-pair, ≤ 30 m at 50 PPR.
Sourcing & Quality Verification
- Sourced exclusively from NTron-authorized distribution channels
- Each unit ships with original manufacturer packaging and date code
- Certificate of Conformance (CoC) available upon request
- Batch traceability records retained for 5 years
- Visual and functional inspection performed prior to dispatch
- Anti-counterfeit hologram label verified against NTron master database
Procurement Process
- Add to cart and complete checkout on Konmask.com
- Receive order confirmation with estimated lead time within 2 business hours
- Unit dispatched with DHL / FedEx express tracking
- CoC and datasheet emailed upon shipment
- 30-day DOA warranty; 12-month quality guarantee on genuine parts
Technical FAQ
Q: Is the AV56A-1XFX6YXGP50 compatible with Siemens S7-1200 high-speed counter inputs?
A: Yes. The push-pull output at 24 V DC is directly compatible with S7-1200 HSC inputs (IEC Type 1/3). No external resistor or converter is required.
Q: Can this encoder replace a 50 PPR resolver on a legacy servo drive?
A: Only if the drive supports incremental encoder feedback mode. Consult your drive’s parameter manual to switch from resolver to encoder input before substitution.
Q: What is the maximum frequency output at rated speed?
A: At 6,000 RPM with 50 PPR: f = (6000 × 50) / 60 = 5,000 Hz. Well within the bandwidth of standard PLC HSC modules.
Q: Is a mating connector or cable assembly available?
A: Yes. Contact support@konmask.com with your cable length and connector type requirements for a custom cable quote.
Q: Do you offer volume pricing for OEM orders (> 10 units)?
A: Yes. Submit your BOM or RFQ to support@konmask.com and our technical sales team will respond within 1 business day.
