Genuine HEIDENHAIN ROD 630 900 28S08-HY | Incremental Linear Encoder – ROD 630 Series | Verified Source
The HEIDENHAIN ROD 630 900 28S08-HY (ID: 684671-07) is a high-precision incremental rotary/linear encoder engineered for demanding CNC machine tool and industrial automation applications. Sourced directly through verified HEIDENHAIN distribution channels, every unit sold by Konmask.com undergoes a documented 4-step authenticity and quality verification process before dispatch.
Technical Specifications
- Manufacturer: HEIDENHAIN (Dr. Johannes Heidenhain GmbH)
- Part Number / SKU: ROD 630 900 28S08-HY
- HEIDENHAIN ID: 684671-07
- Series: ROD 630
- Type: Incremental Rotary Encoder
- Line Count: 900 lines/rev
- Interface: 28S08-HY (TTL/HTL sinusoidal output)
- Operating Voltage: 5 V DC (±5%)
- Operating Temperature: 0 °C to +70 °C
- Protection Class: IP 64
- Weight: Approx. 500 g
- Condition: New / Refurbished (specify at inquiry)
Our 4-Step Quality Verification Process
- Source Authentication — All units are procured from authorized HEIDENHAIN distributors or verified OEM surplus channels. Traceability documentation is retained on file.
- Physical Inspection — Each encoder is inspected for housing integrity, connector condition, cable sheath, and label authenticity against HEIDENHAIN factory standards.
- Functional Bench Test — Signal output, line count accuracy, and interface compatibility are verified using calibrated test equipment prior to packaging.
- Secure Packaging & Documentation — Units are packed in anti-static, shock-resistant packaging. A test report and sourcing declaration accompany every shipment.
Key Features & Benefits
- ✅ Genuine OEM Part — Not a clone or counterfeit; full HEIDENHAIN provenance
- ✅ High Resolution — 900-line incremental output for precise position feedback
- ✅ Robust Construction — IP 64 rated, suitable for coolant and dust environments
- ✅ Drop-in Replacement — Direct compatibility with existing ROD 630 series installations
- ✅ Fast Global Dispatch — In-stock units ship within 1–3 business days
- ✅ B2B Invoicing Available — VAT invoices, customs documentation, and COO certificates on request
Typical Applications
- CNC machining centers (milling, turning, grinding)
- Coordinate measuring machines (CMM)
- Servo motor feedback systems
- Semiconductor and PCB manufacturing equipment
- Robotics and precision motion control platforms
- Medical imaging and laboratory automation
Compatible System Components
- HEIDENHAIN TNC 320 / TNC 620 / TNC 640 CNC controls
- HEIDENHAIN iTNC 530 control systems
- Siemens SINUMERIK 840D / 828D servo drives
- Fanuc Series 0i / 30i / 31i CNC systems
- Mitsubishi MELDAS CNC controllers
- Standard TTL/HTL encoder input cards (28S08-HY interface)
Global Sourcing & Shipping Capabilities
Konmask.com operates as a specialist B2B supplier of industrial automation components with global reach. We ship the HEIDENHAIN ROD 630 900 28S08-HY to:
- 🌏 Asia-Pacific: China, Japan, South Korea, Taiwan, Southeast Asia
- 🌍 Europe: Germany, Italy, Spain, Poland, Czech Republic, and EU-wide
- 🌎 Americas: USA, Canada, Mexico, Brazil
- 🌐 Middle East & Africa: UAE, Saudi Arabia, South Africa
DHL Express, FedEx International Priority, and sea freight consolidation available. Export documentation (commercial invoice, packing list, COO) provided as standard.
Certifications & Compliance Statement
- CE Marking: Compliant (as per original HEIDENHAIN product certification)
- RoHS: Compliant
- ISO 9001: Konmask.com quality management processes are aligned with ISO 9001 principles
- Export Control: This product may be subject to export regulations. Buyers are responsible for compliance with applicable import/export laws in their jurisdiction.
How to Order
- Add to Cart — Click “Add to Cart” or “Buy Now” for immediate checkout
- Request a Quote — For bulk orders (5+ units), email support@konmask.com for volume pricing
- Specify Requirements — Indicate required condition (new/refurbished), lead time, and any documentation needs
- Payment — T/T bank transfer, PayPal, and major credit cards accepted; LC available for large orders
Authenticity & Trust FAQ
Q: How do I know this is a genuine HEIDENHAIN part?
A: Every unit is sourced from traceable channels and passes our 4-step verification. We provide sourcing declarations and test reports on request.
Q: Can I return the item if it doesn’t match my system?
A: Yes. We offer a 30-day return policy for unused items in original packaging. Contact support@konmask.com within 30 days of receipt.
Q: Do you offer a warranty?
A: New units carry a 12-month warranty against manufacturing defects. Refurbished units carry a 6-month functional warranty.
Q: Can you provide a datasheet or wiring diagram?
A: Yes. Contact us with your order number or inquiry reference and we will supply the relevant HEIDENHAIN technical documentation.
Q: What if I need a different ROD 630 variant?
A: We stock multiple ROD 630 configurations. Email support@konmask.com with your required line count, interface type, and ID number.
