Flow Measurement & Totalization Solution – OMEGA DPF64-SQRT | DPF64 Series
Where This Product Is Used
The OMEGA DPF64-SQRT is engineered for demanding industrial environments where accurate flow rate display and totalization are critical. Typical deployment scenarios include:
- Water & Wastewater Treatment Plants – Real-time flow monitoring across influent, effluent, and recirculation lines with square root extraction for differential-pressure transmitters.
- Chemical & Petrochemical Processing – Continuous rate display and batch totalization for reagent dosing, blending, and transfer operations.
- HVAC & Building Automation – Chilled water and steam flow monitoring integrated into BMS panels via pulse or analog inputs.
- Food & Beverage Production – CIP flow verification and ingredient metering where hygienic process control is mandatory.
- Oil & Gas Upstream/Midstream – Wellhead and pipeline flow totalization with dual-power compatibility (110/220 VAC) for remote skid installations.
- Pharmaceutical Manufacturing – Purified water (PW) and WFI loop flow monitoring supporting 21 CFR Part 11 documentation requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DPF64-SQRT |
| Series | DPF64 |
| Brand | OMEGA Engineering |
| Function | Rate Meter with Square Root Extraction & Totalizer |
| Supply Voltage | 110/220 VAC (universal, auto-select or jumper) |
| Display | Dual 6-digit LED – Rate (upper) / Total (lower) |
| Input Signal | Pulse / Frequency from flow transmitters or turbine meters |
| Square Root Function | Built-in (for DP-based flow sensors) |
| Scaling | Fully programmable K-factor and decimal point |
| Relay Outputs | Configurable setpoint relays (model-dependent) |
| Panel Cutout | 1/8 DIN (92 × 45 mm typical) |
| Weight | 1,460 g |
| Enclosure | Panel-mount, IP65 front face |
| Operating Temp | 0 °C to 50 °C |
| Certifications | CE Marked |
Why Engineers Specify This Model
- Square Root Extraction Built-In – Eliminates the need for an external signal conditioner when using orifice plates, venturi tubes, or pitot sensors; the DPF64-SQRT linearizes the DP signal directly.
- Dual-Voltage Power Supply – A single SKU covers both 110 VAC (North America / Japan) and 220 VAC (Europe / Asia) installations, simplifying global procurement and spare-parts inventory.
- Simultaneous Rate + Total Display – Operators read instantaneous flow rate and accumulated total on one instrument without toggling screens, reducing read errors during shift handover.
- Programmable K-Factor – Compatible with virtually any pulse-output flow sensor; no custom firmware required.
- 1/8 DIN Form Factor – Fits standard panel cutouts already present in most control cabinets, minimizing retrofit cost.
- OMEGA Reliability – Backed by OMEGA Engineering’s 60+ year track record in industrial measurement instrumentation.
Complete System Bill of Materials
For a complete flow measurement loop using the DPF64-SQRT, consider the following complementary components:
- Flow Sensor – Turbine, magnetic, vortex, or DP transmitter with pulse/frequency output
- Signal Cable – Shielded twisted-pair, 22 AWG minimum
- Panel Enclosure – 1/8 DIN cutout panel or DIN-rail adapter kit
- Power Supply – 110/220 VAC branch circuit with appropriate fusing (250 mA recommended)
- Setpoint Relay Load – Solenoid valve, alarm horn, or PLC digital input
- Grounding Bar – For EMI/RFI shielding termination in industrial cabinets
Compliance & Industry Standards
- CE Marking – Complies with EU Low Voltage Directive (LVD) and EMC Directive for industrial environments.
- RoHS Compliant – Manufactured without restricted hazardous substances per EU Directive 2011/65/EU.
- IP65 Front Panel – Meets IEC 60529 ingress protection for dust-tight and water-jet resistant front face.
- UL/CSA Recognition – Verify current listing status with OMEGA for specific regional requirements.
- ISA-5.1 – Compatible with standard instrumentation loop documentation practices.
Quality Assurance & Sourcing
Konmask.com sources the OMEGA DPF64-SQRT exclusively through authorized distribution channels and verified industrial surplus networks. Every unit undergoes the following before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Power-on functional verification at rated voltage
- Display segment and programming interface check
- Anti-static packaging with humidity indicator card
- Photographic documentation available upon request
Counterfeit risk is mitigated through serial number cross-referencing with OMEGA’s published product database where applicable.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly on Konmask.com.
- Request a Quote – For quantities ≥ 3 units or project-based procurement, email support@konmask.com for volume pricing.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock units: contact us for ETA.
- Export & Cross-Border – We support international shipping with commercial invoice and packing list documentation. HS Code: 9026.20 (instruments for measuring or checking flow of liquids).
- Payment – Accepts major credit cards, PayPal, T/T bank transfer, and trade credit (approved accounts).
Application-Specific FAQ
Q: Can the DPF64-SQRT accept a 4–20 mA signal directly from a DP transmitter?
A: The DPF64-SQRT is optimized for pulse/frequency inputs. For 4–20 mA DP transmitters, a frequency converter or a model with analog input (e.g., DPF64-SQRT with optional analog input board) is recommended. Confirm with OMEGA Engineering for your specific transmitter.
Q: Is the square root extraction function defeatable for linear flow sensors?
A: Yes. The square root function is programmable and can be disabled via the front-panel menu, making the DPF64-SQRT suitable for turbine or magnetic meters that already output a linear pulse signal.
Q: What is the maximum pulse input frequency?
A: Refer to the OMEGA DPF64 series datasheet for maximum frequency rating (typically up to 10 kHz for standard models). Contact us if your sensor exceeds this range.
Q: Can this meter be used in a hazardous (classified) area?
A: The standard DPF64-SQRT is not ATEX or IECEx certified. For Zone 1/2 or Division 1/2 installations, a certified barrier or isolator must be used, or consult OMEGA for intrinsically safe variants.
Q: Does Konmask provide a warranty on this product?
A: Yes. Konmask.com offers a 90-day functional warranty on all verified units. Extended warranty and service contracts are available upon request.
