OMRON C200H-AD002 Analog Input Module | Replacement, Equivalent & Selection Guide
The OMRON C200H-AD002 is a high-precision analog input module designed for the OMRON C200H/C200HS/C200HE/C200HG/C200HX PLC series. It converts real-world analog signals (voltage/current) into digital values for process monitoring and control. At Konmask.com, we specialize in sourcing genuine and compatible replacements for industrial automation components.
Technical Specifications
- Model: C200H-AD002
- Brand: OMRON
- Series: C200H
- Module Type: Analog Input Module
- Number of Input Points: 4 channels
- Input Signal Range: 0–10 V DC / 0–5 V DC / 1–5 V DC / 0–20 mA / 4–20 mA (selectable per channel)
- Resolution: 1/4000 (12-bit)
- Conversion Speed: 2.5 ms/channel
- Isolation: Photocoupler isolation between input and internal circuit
- Power Consumption: 5 V DC, 150 mA (from backplane)
- Operating Temperature: 0–55°C
- Storage Temperature: −20–75°C
- Dimensions (W×H×D): 35 × 130 × 126 mm
- Weight: Approx. 300 g
- Country of Origin: Japan
- Compliance: CE, UL
Compatible Replacement & Equivalent Models
If the C200H-AD002 is discontinued or unavailable, the following models offer compatible or equivalent functionality:
- OMRON C200H-AD003 – 8-channel analog input, same C200H backplane, higher channel density upgrade
- OMRON CS1W-AD041-V1 – CS1 series 4-channel analog input; requires CS1 CPU but offers enhanced resolution (1/6000)
- OMRON CJ1W-AD041-V1 – CJ1 series equivalent; suitable for system migration to CJ platform
- OMRON C200HW-AD002 – Direct functional equivalent for C200HW backplane systems
- Third-party compatible modules – Various DIN-rail analog input modules with C200H bus adapters (consult Konmask for verified compatibility)
Note: Always verify backplane compatibility and firmware version before substitution. Contact support@konmask.com for a verified replacement recommendation.
Why Choose the Original C200H-AD002
- ✅ Native plug-and-play compatibility with C200H/C200HS/C200HE/C200HG/C200HX CPUs
- ✅ Proven 12-bit resolution for stable process control
- ✅ No additional configuration adapter required
- ✅ Supported by OMRON CX-Programmer and legacy ladder logic
- ✅ Long field service record in manufacturing, food processing, and utilities
Typical Applications
- Temperature and pressure monitoring in process industries
- Flow rate measurement and PID loop control
- Level sensing in water treatment and chemical plants
- Conveyor speed feedback in packaging lines
- HVAC control systems in building automation
System Compatibility
- Compatible CPUs: C200H-CPU01/02/03/11/21/23/31/33, C200HS-CPU01/03/21/23/31/33, C200HE-CPU11/32/42, C200HG-CPU33/43/53/63, C200HX-CPU34/44/54/64/65/85
- Programming Software: OMRON CX-Programmer, SYSMAC Support Software (SSS)
- Backplane: C200H-BC031/051/081/101 and C200HW-BC031/051/081/101
- Not compatible with: C1000H, C2000H, or CVM1 series without bus conversion
Selection Guide
Use this guide to select the right analog input module for your application:
- Need 4 channels on C200H? → C200H-AD002 (this model) ✓
- Need 8 channels on C200H? → Upgrade to C200H-AD003
- Migrating to CS1 platform? → CS1W-AD041-V1 (4ch) or CS1W-AD081-V1 (8ch)
- Migrating to CJ1/CJ2 platform? → CJ1W-AD041-V1 or CJ1W-AD081-V1
- Need higher resolution (1/6000)? → CS1W-AD041-V1 or CJ1W-AD041-V1
- Budget-sensitive retrofit? → Contact Konmask for verified third-party alternatives
Quality Assurance & Sourcing
- 🔍 All units inspected for physical integrity and label authenticity before shipment
- 📦 Anti-static packaging with humidity indicator cards
- 🏭 Sourced from authorized distributors and verified industrial surplus channels
- 📋 Batch traceability records available on request
- 🔧 Functional testing available upon request (additional lead time may apply)
How to Order
- Add OMRON C200H-AD002 to cart on Konmask.com
- Or contact us directly: support@konmask.com | +0086 19859288691
- Provide your CPU model and required quantity for lead time confirmation
- Bulk orders (>5 units) qualify for volume pricing — request a quote
Replacement & Compatibility FAQ
Q: Can C200H-AD002 replace C200H-AD001?
A: The AD001 is a 2-channel module; the AD002 provides 4 channels. They share the same backplane slot but are not pin-for-pin identical — software reconfiguration is required.
Q: Is C200H-AD002 still in production?
A: OMRON has discontinued this model. Konmask stocks genuine surplus units. Contact us for current availability.
Q: Can I use C200H-AD002 with a CJ2 CPU?
A: No. The C200H bus is not directly compatible with CJ2. A bus conversion unit or platform migration is required.
Q: What is the warranty on your C200H-AD002 units?
A: We offer a 90-day functional warranty on all modules. Extended warranty available upon request.
Q: Do you provide datasheets or wiring diagrams?
A: Yes. Email support@konmask.com with your order number or inquiry.
