Industrial Temperature Monitoring Solution – OMRON C200H-TS001 | C200H Series
Where This Product Is Used
The OMRON C200H-TS001 Temperature Sensor Unit is deployed across a wide range of industrial temperature-critical environments where precise, real-time thermal monitoring is essential to process integrity and equipment safety:
- Plastic Injection Molding Machines – Monitors barrel and mold temperatures to maintain tight tolerances and prevent material degradation.
- Food & Beverage Processing Lines – Ensures pasteurization, sterilization, and cooking processes meet regulatory temperature thresholds.
- Chemical Reactors & Batch Processing – Provides closed-loop temperature feedback to prevent runaway reactions and ensure yield consistency.
- HVAC & Building Automation Systems – Integrates with C200H PLCs to regulate zone temperatures in large commercial or industrial facilities.
- Furnace & Kiln Control – Tracks high-temperature zones in ceramics, metallurgy, and heat treatment applications.
- Pharmaceutical Manufacturing – Supports GMP-compliant temperature logging for autoclaves, incubators, and clean-room environments.
- Semiconductor Fabrication – Monitors process chamber temperatures in CVD, diffusion, and annealing equipment.
Technical Specifications
| Attribute | Specification |
|---|---|
| Model Number | C200H-TS001 |
| Series | OMRON C200H PLC Series |
| Module Type | Temperature Sensor Unit (Thermocouple Input) |
| Input Type | Thermocouple (Type K, J, T, E, L, R, S, B – model dependent) |
| Number of Input Points | 4 points |
| Resolution | 0.1°C / 1°C (selectable) |
| Accuracy | ±0.5% of full scale ±1 digit |
| Conversion Speed | 250 ms per channel |
| Power Consumption | 5 VDC, 150 mA (from backplane) |
| Mounting | C200H backplane (I/O bus) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 75°C |
| Humidity | 10% to 90% RH (non-condensing) |
| Weight | Approx. 250 g |
| Certifications | CE, UL (refer to OMRON datasheet for regional approvals) |
Why Engineers Specify This Model
- Native C200H Bus Integration – Plugs directly into the C200H backplane with no external signal conditioning required, reducing panel footprint and wiring complexity.
- Multi-Thermocouple Compatibility – Supports the most common industrial thermocouple types, eliminating the need for separate input modules per sensor type.
- High-Resolution Measurement – 0.1°C resolution enables tight process control in precision manufacturing environments.
- Proven Platform Reliability – The C200H series has decades of field-proven reliability in harsh industrial environments worldwide.
- Simplified PLC Programming – Temperature data is mapped directly to C200H data memory words, enabling straightforward ladder logic implementation.
- Compact Form Factor – Single-slot module conserves backplane space for other I/O expansion.
Complete System Bill of Materials
For a complete C200H temperature monitoring system, engineers typically specify the following components alongside the C200H-TS001:
- C200H-CPU31-E / C200H-CPU33-E – C200H CPU Unit
- C200H-BC051-V2 / C200H-BC101-V2 – Backplane (5-slot or 10-slot)
- C200H-PA204S – Power Supply Unit
- C200H-OC225 – Output Unit (for control relay/actuator outputs)
- Type K or Type J Thermocouple Probes – Field sensors (customer-supplied per application)
- CX-Programmer Software – OMRON PLC programming environment
Contact [email protected] for bundle pricing on complete system configurations.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed – Recognized for use in North American industrial control panels
- RoHS Compliant – Meets EU Restriction of Hazardous Substances requirements
- IEC 61131-2 – Programmable controllers hardware standard compliance
- ISO 9001 – Manufactured under OMRON’s ISO 9001-certified quality management system
Quality Assurance & Sourcing
At Konmask.com, every OMRON C200H-TS001 unit is subject to our rigorous incoming inspection protocol:
- Visual inspection for physical damage, label authenticity, and connector integrity
- Functional power-on verification where applicable
- Traceability documentation retained for each unit
- Sourced from authorized distributors and verified secondary market channels
- Packaging inspected for tamper evidence and original OMRON markings
We specialize in supplying both new and refurbished C200H series modules to support legacy system maintenance and new panel builds.
How to Source This Part
- In Stock Orders – Add to cart and check out directly. Most orders ship within 1–3 business days.
- Bulk / Project Quotes – Email [email protected] with your BOM and required quantities for a project discount.
- Urgent Requirements – Call or WhatsApp +0086 19859288691 for expedited sourcing and same-day quotation.
- OEM / System Integrators – We offer NET30 terms and dedicated account management for qualified integrators.
Application-Specific FAQ
Q: Is the C200H-TS001 compatible with the C200HE, C200HG, and C200HX CPUs?
A: Yes. The C200H-TS001 is compatible with all C200H-family CPUs including the C200HE, C200HG, and C200HX variants, as they share the same I/O bus architecture.
Q: What thermocouple types does the C200H-TS001 support?
A: The TS001 supports Type K, J, T, E, L, R, S, and B thermocouples. Refer to the OMRON W345 datasheet for the full input range table per thermocouple type.
Q: Can I use the C200H-TS001 in a remote I/O rack?
A: No. The C200H-TS001 must be installed in a local CPU rack or expansion rack directly connected to the CPU backplane. It is not supported in remote I/O configurations.
Q: How do I read temperature values in ladder logic?
A: Temperature data is stored in the C200H data memory (DM) area. Each channel occupies one DM word. Use MOV or XFER instructions to transfer values to your control logic.
Q: Do you supply the OMRON C200H-TS002 or C200H-TS101 as well?
A: Yes. We stock the full C200H temperature sensor unit range. Contact us for availability and pricing on related models.
