OMRON CP1E-E60SDR-A 60 I/O Relay Output CPU Unit | Replacement, Equivalent & Selection Guide
The OMRON CP1E-E60SDR-A is a high-performance, cost-effective PLC CPU unit from the CP1E E-type series, featuring 60 I/O points and relay output. Designed for small-to-medium automation applications, it delivers reliable control with easy programming via CX-Programmer. This page serves as a comprehensive selection, replacement, and compatibility reference for industrial engineers and procurement teams.
Technical Specifications
- Model: CP1E-E60SDR-A
- Series: CP1E (E-type)
- Manufacturer: OMRON Corporation
- I/O Points: 60 (36 inputs / 24 outputs)
- Output Type: Relay
- Power Supply: AC 100–240 V
- Program Capacity: 8K steps
- Data Memory: 8K words
- USB Port: Yes (peripheral port for programming)
- Analog I/O: Not built-in (expandable via option boards)
- Communication: RS-232C / RS-485 (via option board)
- Dimensions (W×H×D): 202 × 90 × 80 mm
- Weight: Approx. 1,250 g
- Operating Temperature: 0–55 °C
- Protection Rating: IP20
- Standards: CE, UL, cUL
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the CP1E-E60SDR-A. Always verify I/O count, output type, and communication requirements before substitution.
- OMRON CP1E-N60SDR-A — N-type upgrade; adds built-in RS-232C & Ethernet option, same 60 I/O relay output. Direct functional upgrade.
- OMRON CP1L-M60DR-A — CP1L M-type, 60 I/O relay, AC power; higher program capacity (10K steps). Suitable for more complex logic.
- OMRON CP2E-N60DR-A — CP2E series, 60 I/O relay, built-in Ethernet; ideal for IoT-ready upgrades.
- OMRON CJ2M-CPU11 — Modular CJ2M platform; suitable when scalability beyond 60 I/O is required.
- Mitsubishi FX3U-64MR/ES — Third-party equivalent; 64 I/O relay output, AC power. Requires reprogramming in GX Works2.
- Siemens S7-1200 CPU 1214C DC/DC/RLY — Cross-brand alternative; 14 DI / 10 DO relay; expandable. TIA Portal programming required.
Note: Cross-brand replacements require full program migration and I/O remapping. Consult Konmask technical support for assistance.
Why Choose the Original Model
- Proven reliability in OMRON CP1E ecosystem — no firmware migration risk
- Native CX-Programmer compatibility — zero reprogramming cost
- Relay output handles resistive, inductive, and lamp loads without external relays
- AC power supply suits most industrial panel environments
- Compact DIN-rail form factor minimizes panel space
- Long product lifecycle with OMRON global support and spare parts availability
Typical Applications
- Conveyor and material handling control
- Packaging machine sequencing
- HVAC and building automation
- Water treatment and pump control
- Assembly line interlocking
- Small-scale process control panels
System Compatibility
- Programming Software: CX-Programmer Ver. 9.0 or later (CX-One suite)
- Expansion Units: CP1W series I/O expansion units (up to 3 units)
- Option Boards: CP1W-CIF01 (RS-232C), CP1W-CIF11 (RS-422A/485), CP1W-DAM01 (analog)
- HMI: Compatible with OMRON NB, NS series HMI via RS-232C/RS-485
- SCADA: Supports Modbus RTU (via option board) for third-party SCADA integration
- Power Supply: No external 24 VDC supply required for CPU (AC self-powered)
Selection Guide
Use the following criteria to confirm the CP1E-E60SDR-A is the right choice — or to identify a better-fit alternative:
- I/O Count: Need exactly 60 points? CP1E-E60SDR-A is optimal. Need more? Consider CP1L-M60DR-A + expansion or CJ2M.
- Output Type: Relay output (this model) suits mixed-voltage loads. For high-speed pulse output, choose transistor output variants (CP1E-E60SDT-A / CP1E-E60SDT1-A).
- Communication: No built-in serial on E-type. Add CP1W-CIF01 for RS-232C or upgrade to N-type (CP1E-N60SDR-A) for built-in port.
- Ethernet: Not available on E-type. Upgrade to CP2E-N60DR-A for native Ethernet/IP.
- Budget: CP1E E-type is the most cost-effective entry in the CP1E family — ideal for cost-sensitive projects without advanced communication needs.
- Environment: Standard IP20 panel installation. For harsh environments, consider IP67-rated remote I/O solutions.
Quality Assurance & Sourcing
- All units sourced from authorized OMRON distribution channels or verified secondary market suppliers
- Each unit inspected for physical integrity, label authenticity, and firmware version prior to shipment
- Batch traceability records maintained for B2B procurement compliance
- Warranty: 12 months from shipment date (DOA replacement within 7 days)
- Counterfeit risk mitigation: serial number verification available upon request
How to Order
- SKU: CP1E-E60SDR-A
- MOQ: 1 unit
- Lead Time: In-stock units ship within 1–3 business days; pre-order lead time 7–15 business days
- Packaging: Original OMRON retail box with accessories
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx / UPS worldwide; sea freight available for bulk orders
- Contact us for volume pricing, OEM procurement, or urgent delivery requirements
Replacement & Compatibility FAQ
Q: Can I replace CP1E-E60SDR-A with CP1E-N60SDR-A directly?
A: Yes, the N-type is a functional superset of the E-type with the same I/O and output type. Programs are compatible with minor adjustments for added features.
Q: Does CP1E-E60SDR-A support analog I/O?
A: Not natively. Add the CP1W-DAM01 option board for 1 analog input + 1 analog output.
Q: Can I use a Mitsubishi FX3U as a drop-in replacement?
A: No. Cross-brand replacement requires full program rewrite in GX Works2 and I/O rewiring. Not recommended unless OMRON units are unavailable long-term.
Q: What is the maximum expansion for CP1E-E60SDR-A?
A: Up to 3 CP1W expansion units, adding a maximum of 40 additional I/O points (total up to 100 I/O).
Q: Is this model still in production?
A: The CP1E series remains in active production. Contact Konmask for current availability and lead times.
