OMRON E5ZE-8AQHD1TCB 8-Channel Multipoint Temperature Controller – E5ZE Series
In high-precision industrial environments — from plastic injection molding to semiconductor fabrication — uncontrolled temperature variation is not merely an inconvenience; it is a root cause of product defects, equipment damage, and costly production downtime. When a single temperature controller fails or lacks the channel capacity to manage multiple heating zones simultaneously, operators face cascading failures across entire production lines. The OMRON E5ZE-8AQHD1TCB was engineered precisely to eliminate this vulnerability, delivering centralized, simultaneous control over eight independent temperature zones from a single compact unit.
The E5ZE-8AQHD1TCB occupies a commanding position within OMRON’s E5ZE multipoint temperature controller series — the flagship platform designed for applications demanding synchronized multi-zone thermal management. With its 8-channel architecture, advanced PID algorithm, and RS-485 serial communication capability, this model is widely deployed across global manufacturing facilities in automotive, food processing, plastics, and electronics industries. OMRON’s E5ZE series is recognized internationally as a benchmark for reliability and precision in industrial temperature control.
Technical Specifications
- Model Number: E5ZE-8AQHD1TCB
- Brand: OMRON
- Series: E5ZE Multipoint Temperature Controller Series
- Number of Channels: 8 channels (independent control per zone)
- Control Method: PID / ON-OFF selectable
- Input Type: Thermocouple / Resistance thermometer (RTD)
- Output Type: Relay output (SPST-NO)
- Communication: RS-485 serial communication
- Mounting: DIN rail mount
- Power Supply: 100–240 VAC, 50/60 Hz
- Weight: Approx. 1,250 g
- Compliance: CE, UL, cUL
Note: All specifications are based on OMRON official documentation. Please consult the official datasheet or contact us to confirm parameters for your specific application.
Key Features & Benefits
- 8 Independent Control Channels: Manage up to 8 heating/cooling zones simultaneously, eliminating the need for multiple standalone controllers and reducing panel space by up to 60%.
- Advanced PID Control: Auto-tuning PID algorithm ensures rapid setpoint achievement and minimal overshoot, critical for temperature-sensitive processes.
- RS-485 Communication: Seamless integration with SCADA systems, PLCs, and HMIs via Modbus RTU or OMRON CompoWay/F protocol, enabling centralized monitoring and remote parameter adjustment.
- Universal Input Compatibility: Accepts thermocouple (K, J, T, E, L, U, N, R, S, B, W) and RTD (Pt100, JPt100) inputs, providing flexibility across diverse sensor installations.
- Compact DIN Rail Design: Space-efficient form factor designed for standard DIN rail mounting, simplifying panel integration and maintenance access.
- Alarm Functions: Configurable upper/lower limit alarms and deviation alarms per channel, with independent alarm outputs for rapid fault response.
- High Reliability: Built to OMRON’s industrial-grade standards with proven long-term stability in demanding 24/7 production environments.
Industry & Equipment Applications
- Plastics & Rubber: Injection molding machines, extruders, hot runner systems — precise barrel and nozzle zone temperature control.
- Food & Beverage Processing: Pasteurization lines, baking ovens, retort systems — hygienic multi-zone thermal management.
- Semiconductor & Electronics Manufacturing: Reflow soldering ovens, wafer processing equipment, burn-in test chambers.
- Automotive Manufacturing: Paint curing ovens, adhesive bonding stations, composite material forming presses.
- Packaging Machinery: Heat sealing equipment, shrink tunnel systems, form-fill-seal machines.
- Chemical & Pharmaceutical: Reactor temperature control, distillation column management, sterilization autoclaves.
System Integration & Compatible Parts
The OMRON E5ZE-8AQHD1TCB is designed for seamless integration within OMRON’s industrial automation ecosystem and broader third-party control architectures:
- Compatible PLCs: OMRON CJ2M, CJ2H, NJ/NX Series via RS-485 or EtherNet/IP gateway
- Compatible HMIs: OMRON NS Series, NB Series touchscreens
- Communication Converters: OMRON CJ1W-SCU21-V1 Serial Communications Unit
- Related Temperature Controllers: OMRON E5CC, E5EC, E5AC series for single-channel applications
- Solid State Relays (SSR): OMRON G3NA, G3PA series for high-cycle switching applications
- Thermocouples & RTD Sensors: Compatible with standard K-type, J-type thermocouples and Pt100 RTDs
Our Quality Assurance Process
At Konmask.com, every OMRON E5ZE-8AQHD1TCB unit undergoes a rigorous multi-stage quality verification process before shipment:
- Authenticity Verification: All units are sourced from authorized distributors or verified supply chains. Serial numbers and manufacturer markings are cross-checked against OMRON’s product authentication standards.
- Visual & Physical Inspection: Each unit is inspected for physical integrity — housing condition, terminal block completeness, label clarity, and connector integrity.
- Functional Pre-check: Where applicable, units undergo power-on verification to confirm basic operational status prior to packaging.
- Secure Packaging: Anti-static packaging with shock-absorbing materials ensures safe transit for international shipments.
- Documentation: Original manufacturer documentation, certificates of conformity, and test records are provided upon request.
How to Order
- Submit an Inquiry: Contact us via email at [email protected] or call +0086 19859288691 with your required quantity and delivery timeline.
- Receive a Quotation: Our technical sales team will provide a competitive quotation within 24 business hours, including lead time and shipping options.
- Order Confirmation: Confirm your purchase order. We accept T/T bank transfer, PayPal, and other B2B payment methods.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Typical international delivery: 5–10 business days.
- After-Sales Support: Our engineering team provides post-delivery technical support for installation and commissioning queries.
Why Choose Konmask.com?
- ✅ Specialized B2B Industrial Supplier — Focused exclusively on industrial automation components with deep technical expertise.
- ✅ Global Sourcing Network — Access to genuine OMRON products with competitive lead times for both standard and obsolete parts.
- ✅ Technical Pre-Sales Support — Our engineers help you select the right model and verify compatibility before purchase.
- ✅ Flexible MOQ — Single-unit orders accepted; volume pricing available for OEM and system integrator customers.
- ✅ Reliable International Shipping — Experienced in export documentation, customs compliance, and secure packaging for global delivery.
- ✅ Responsive Communication — Dedicated account managers available via email, WhatsApp, and phone for fast inquiry response.
Frequently Asked Questions
Q1: Is the OMRON E5ZE-8AQHD1TCB still in production?
A: The E5ZE series has been a long-standing product in OMRON’s portfolio. Availability may vary by region. Contact us to confirm current stock status and lead time for the E5ZE-8AQHD1TCB.
Q2: What communication protocol does the E5ZE-8AQHD1TCB support?
A: The unit supports RS-485 serial communication using OMRON’s CompoWay/F protocol, which is compatible with most OMRON PLCs and can be adapted to Modbus RTU via protocol converters.
Q3: Can I control heating and cooling simultaneously on different channels?
A: Yes. Each of the 8 channels operates independently, allowing different setpoints, control modes, and output configurations per zone — ideal for complex multi-zone thermal processes.
Q4: What input sensors are compatible with the E5ZE-8AQHD1TCB?
A: The controller accepts a wide range of thermocouple types (K, J, T, E, L, U, N, R, S, B, W) and resistance thermometers (Pt100, JPt100), making it compatible with most industrial temperature sensing installations.
Q5: Do you provide a warranty for this product?
A: Yes. We offer a standard warranty period on all products. Please contact our sales team for specific warranty terms applicable to the E5ZE-8AQHD1TCB and your order conditions.
Q6: Can I request a sample or trial unit before placing a bulk order?
A: Yes, single-unit orders are accepted. Please submit an inquiry and our team will arrange accordingly.
