OMRON CP1H-X40DR-A Programmable Logic Controller – CP1H High-Performance Series
When a programmable logic controller fails on the production floor, the consequences are immediate and costly: assembly lines halt, robotic arms freeze mid-cycle, conveyor systems stop, and every idle minute translates directly into lost revenue and missed delivery commitments. The OMRON CP1H-X40DR-A is the critical intelligence at the heart of countless automated systems worldwide — without it, the coordinated precision of modern manufacturing simply ceases to exist.
The CP1H-X40DR-A occupies a commanding position within OMRON’s CP1H High-Performance Series — the flagship compact PLC line engineered for applications demanding both processing power and I/O density. With 40 built-in I/O points (24 inputs / 16 relay outputs), this model is purpose-built for mid-scale machine control where relay output durability and broad voltage compatibility are non-negotiable. Globally, the CP1H Series has earned recognition as one of the most deployed compact PLCs in packaging, food processing, and material handling industries, trusted by OEMs and system integrators across Asia, Europe, and the Americas.
Technical Specifications
- Model: CP1H-X40DR-A
- Brand: OMRON
- Series: CP1H High-Performance Series
- I/O Configuration: 40 points (24 inputs / 16 relay outputs)
- Output Type: Relay (DR)
- Power Supply: AC 100–240V (suffix -A)
- CPU Type: X-type (standard, without pulse I/O expansion)
- Program Capacity: 20K steps
- Data Memory: 32K words
- Communication Ports: USB (peripheral), RS-232C (built-in)
- Expandable I/O: Up to 320 points via expansion units
- Analog I/O: 4 analog inputs / 2 analog outputs (built-in)
- Interrupt Inputs: 4 points
- Execution Speed: 0.1 μs/instruction (basic)
Key Features & Benefits
- High-Speed Processing: 0.1 μs basic instruction execution enables real-time control of fast-moving processes without latency.
- Relay Output Durability: Relay outputs handle resistive, inductive, and lamp loads across a wide voltage range — ideal for direct actuation of solenoids, motors, and contactors.
- Built-in Analog I/O: Eliminates the need for separate analog expansion modules in many applications, reducing panel space and wiring complexity.
- AC Power Supply Flexibility: Wide-range AC input (100–240V) simplifies global deployment without power supply modifications.
- Extensive Expansion Capability: Supports up to 7 expansion I/O units, scaling to 320 total I/O points for complex machine architectures.
- USB + RS-232C Communications: Dual communication ports enable simultaneous programming access and HMI/device connectivity.
- Compact DIN-Rail Footprint: Space-efficient design reduces control panel size while delivering full-featured PLC performance.
- OMRON CX-Programmer Compatible: Seamless integration with OMRON’s industry-standard programming environment accelerates development and commissioning.
Industry & Equipment Applications
- Packaging Machinery: Carton forming, filling, sealing, and labeling lines requiring precise sequence control and relay-driven actuators.
- Food & Beverage Processing: Conveyor control, batch processing, and temperature-regulated filling systems.
- Material Handling: Palletizers, sorters, and automated storage/retrieval systems (AS/RS).
- Textile & Printing Equipment: Web tension control, registration, and multi-axis coordination.
- Water Treatment & HVAC: Pump sequencing, valve control, and environmental monitoring systems.
- General Factory Automation: Assembly lines, test rigs, and custom OEM machine control panels.
System Integration & Compatible Parts
The CP1H-X40DR-A is designed for seamless integration within the OMRON automation ecosystem. Compatible and commonly paired components include:
- Expansion I/O Units: CP1W-40EDR, CP1W-20EDR, CP1W-8ED, CP1W-8ET series
- Analog Expansion: CP1W-AD041, CP1W-DA021
- Communication Modules: CP1W-CIF01 (RS-232C), CP1W-CIF11 (RS-422/485)
- HMI Panels: OMRON NB Series, NS Series touchscreens
- Programming Software: OMRON CX-Programmer (CX-One Suite)
- Power Supplies: OMRON S8VS, S8VK Series DIN-rail power supplies
Our Quality Assurance Process
At Konmask.com, every OMRON CP1H-X40DR-A unit undergoes a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Cross-referenced against OMRON’s official part numbering and date code standards to confirm genuine origin.
- Visual Inspection: Full examination of housing, terminals, labels, and connector integrity.
- Functional Pre-Check: Power-on verification and communication port testing where applicable.
- Secure Packaging: Anti-static packaging with moisture barrier and shock-absorbing materials for safe international transit.
- Documentation: Each shipment includes a packing list and, upon request, a certificate of conformity.
How to Order
- Submit your inquiry via the Contact / Request a Quote form on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical sales team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange secure packaging and international shipping with full tracking.
For urgent requirements, contact us directly:
📧 [email protected]
📞 +0086 19859288691
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — deep technical expertise in PLC, DCS, servo, and drive systems.
- ✅ Global Supply Network — sourcing from verified distributors and authorized channels across Asia, Europe, and North America.
- ✅ Fast Response — dedicated B2B inquiry handling with quotations within 24 hours.
- ✅ Competitive Pricing — direct sourcing relationships enable cost-effective pricing for both small and large volume orders.
- ✅ Reliable Logistics — experienced in international export compliance, customs documentation, and secure freight forwarding.
- ✅ After-Sales Support — technical assistance available post-delivery for integration and commissioning queries.
Frequently Asked Questions
- Q: What is the difference between CP1H-X40DR-A and CP1H-X40DT-A?
- A: The CP1H-X40DR-A features relay (DR) outputs, suitable for a wide range of AC/DC loads. The CP1H-X40DT-A uses transistor (NPN) outputs, which are faster and better suited for high-frequency pulse outputs and DC loads.
- Q: Can the CP1H-X40DR-A be expanded with additional I/O?
- A: Yes. The CP1H-X40DR-A supports up to 7 CP1W expansion units, allowing the total I/O count to reach up to 320 points.
- Q: What programming software is required for the CP1H-X40DR-A?
- A: OMRON CX-Programmer (part of the CX-One software suite) is the standard programming environment. It supports Ladder Diagram, Function Block Diagram, and Structured Text.
- Q: Does Konmask.com ship internationally?
- A: Yes. We ship to customers worldwide including Southeast Asia, the Middle East, Europe, and the Americas. Please contact us for shipping rates and lead times to your specific destination.
- Q: How can I verify the authenticity of the unit I receive?
- A: All units supplied by Konmask.com are sourced from verified channels. We provide full traceability documentation upon request and welcome pre-shipment inspection arrangements for large orders.
