OMRON PYF08A-E Relay Socket | Replacement, Equivalent & Selection Guide
The OMRON PYF08A-E is an 8-pin relay socket designed for use with OMRON MY2 and MK2 series relays. It supports both DIN rail and surface mounting, making it a versatile choice for industrial control panels, PLC systems, and automation enclosures. This guide covers technical specifications, compatible replacements, and selection criteria to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | PYF08A-E |
| Brand | OMRON |
| Series | PYF |
| Pin Count | 8 pins |
| Compatible Relay Series | MY2, MK2 |
| Mounting Type | DIN Rail / Surface Mount |
| Rated Voltage | 250V AC / 300V DC |
| Rated Current | 10A |
| Contact Material | Silver alloy |
| Terminal Type | Screw terminal |
| Operating Temperature | -40°C to +70°C |
| Dimensions (W×H×D) | Approx. 35 × 38 × 38 mm |
| Weight | Approx. 50 g |
| Certifications | UL, CE, RoHS |
| Country of Origin | Japan / China (varies by batch) |
Compatible Replacement & Equivalent Models
The following models are commonly used as direct or functional replacements for the OMRON PYF08A-E. Always verify pin layout and rated current before substitution.
| Brand | Model | Compatibility | Notes |
|---|---|---|---|
| OMRON | PYF08A | Direct | Earlier version without -E suffix (EU compliance) |
| OMRON | PYF08-E | Direct | Slim-line variant, verify relay fit |
| Finder | 94.02 | Functional | 8-pin socket, verify terminal spacing |
| Phoenix Contact | PLC-RSC-24DC/21 | Functional | Different form factor, check panel layout |
| Idec | SY08 | Functional | Compatible with IDEC RY series relays |
| TE Connectivity | RXZE2M114 | Functional | Verify relay base dimensions |
Why Choose the Original Model
- Guaranteed compatibility — engineered specifically for OMRON MY2/MK2 relay series with precise pin alignment.
- Certified quality — UL, CE, and RoHS compliant for global deployment in industrial environments.
- Long service life — silver alloy contacts rated for 10A continuous load with minimal contact resistance.
- Ease of maintenance — relay can be replaced without rewiring; screw terminals accept standard wire gauges.
- Proven in field — widely deployed in automotive, food processing, and building automation industries worldwide.
Typical Applications
- PLC I/O expansion and relay output modules
- Industrial control panels and MCC (Motor Control Centers)
- HVAC and building automation systems
- Machine tool and conveyor control circuits
- Power distribution and protection relay circuits
- Process automation in chemical and food industries
System Compatibility
The PYF08A-E is compatible with the following OMRON relay models when used as the mating socket:
- OMRON MY2 / MY2N / MY2N-J (8-pin, DPDT)
- OMRON MK2P / MK2P-I (8-pin, DPDT)
- OMRON LY2 / LY2N (8-pin, high-power)
For 11-pin or 14-pin relay configurations, refer to the PYF11A-E or PYF14A-E models respectively.
Selection Guide
Use the following criteria to confirm the PYF08A-E is the correct socket for your application:
- Pin count: Confirm your relay has 8 pins (DPDT configuration).
- Relay brand/series: Verify relay is OMRON MY2, MK2, or LY2 series.
- Mounting method: PYF08A-E supports both DIN rail clip and direct panel screw mounting.
- Current rating: Ensure load current does not exceed 10A per contact.
- Voltage: Rated for 250V AC / 300V DC — suitable for most industrial control voltages.
- Environment: Rated for -40°C to +70°C; suitable for standard industrial enclosures.
If your relay is a different brand or series, consult the replacement table above or contact our technical team for a cross-reference.
Quality Assurance & Sourcing
All OMRON PYF08A-E units sourced through Konmask.com are:
- Procured from authorized distributors or verified surplus channels
- Inspected for physical integrity, pin condition, and label authenticity
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original packaging where available
- Backed by our 30-day return policy and technical support
How to Order
- Confirm your relay model and pin count (8-pin for PYF08A-E).
- Select quantity and add to cart.
- For bulk orders (>50 pcs) or project-based procurement, email support@konmask.com for a custom quote.
- We accept T/T, PayPal, and major credit cards. Lead time: 1–5 business days for in-stock items.
Replacement & Compatibility FAQ
Q: Can I use PYF08A-E with non-OMRON relays?
A: Functionally possible if the relay has an 8-pin octal base with matching pin spacing, but we recommend verifying the datasheet. Contact us for cross-reference support.
Q: What is the difference between PYF08A and PYF08A-E?
A: The “-E” suffix denotes compliance with European safety standards (CE marking). Electrically and mechanically identical.
Q: Is DIN rail clip included?
A: Yes, the PYF08A-E includes a DIN rail mounting clip. Surface mount screws are not included.
Q: Can this socket handle 24V DC relay coils?
A: The socket itself is coil-voltage agnostic — it connects to the relay’s contact pins. Coil voltage is determined by the relay, not the socket.
Q: What wire gauge is compatible with the screw terminals?
A: Accepts AWG 22–14 (0.3–2.5 mm²) stranded or solid wire.
