Panasonic PV500 / PV500V2 (ANPV0504TS1) – High-Performance Industrial Panel PC | PV Series Platform
The Panasonic PV500 / PV500V2, part number ANPV0504TS1, is a ruggedized industrial panel computer engineered for demanding factory automation, process control, and HMI applications. Built on Panasonic’s proven PV Series platform, this unit delivers the processing reliability and I/O flexibility required by procurement engineers specifying long-lifecycle automation infrastructure.
Product Positioning: Designed as a front-end operator interface and data-processing node within distributed control architectures, the ANPV0504TS1 integrates seamlessly with Panasonic PLC networks, SCADA systems, and third-party fieldbus environments. It is the preferred choice for OEM machine builders and system integrators requiring a certified, supply-chain-stable panel PC.
Complete Technical Specifications
| Part Number | ANPV0504TS1 |
| Model Series | PV500 / PV500V2 |
| Manufacturer | Panasonic Corporation (Japan) |
| Form Factor | Industrial Panel PC (Flat-Panel Mount) |
| Display | TFT LCD Touchscreen |
| Operating System | Windows Embedded / CE (platform-dependent) |
| Communication Interfaces | RS-232C, RS-422/485, Ethernet (RJ-45) |
| I/O Expansion | Compatible with Panasonic PV Series I/O modules |
| Power Supply | 24 VDC (nominal) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cut-out, rear-mount brackets included |
| Weight | Approx. 2.0 kg |
| Country of Origin | Japan |
Proven Application Environments
- Automotive body-shop and assembly-line HMI stations
- Food & beverage packaging line supervisory control
- Pharmaceutical batch-process monitoring and recipe management
- Semiconductor fab equipment front-end interfaces
- Water treatment SCADA operator workstations
- Discrete manufacturing MES data-entry terminals
Engineering Advantages
- Long Product Lifecycle: Panasonic PV Series components are supported with extended availability commitments, reducing obsolescence risk for multi-year projects.
- IP65 Front Panel: Sealed against dust ingress and low-pressure water jets, suitable for wash-down environments.
- Fanless Design Option: Eliminates mechanical wear points, lowering MTTR and maintenance intervals.
- Native Panasonic Network Integration: Direct compatibility with MEWNET-W0 and Ethernet-based Panasonic PLC links reduces integration engineering hours.
- Compact Panel Footprint: Optimized cut-out dimensions minimize control-cabinet real estate.
System Architecture & Signal Flow
The ANPV0504TS1 operates as the HMI/supervisory layer in a three-tier automation hierarchy:
- Field Level: Sensors, actuators, and drives communicate via digital/analog I/O or fieldbus (PROFIBUS, DeviceNet, CC-Link).
- Control Level: Panasonic FP or FPΣ series PLCs execute ladder/structured-text programs and pass process data upstream via Ethernet or serial link.
- Supervisory Level (PV500): The ANPV0504TS1 hosts the HMI runtime, logs historian data, and provides the operator touchscreen interface. Upstream connectivity to MES/ERP via OPC-UA or Modbus TCP.
Sourcing & Quality Verification
- OEM-Traceable Stock: Units sourced through authorized Panasonic distribution channels with full traceability documentation available on request.
- Pre-Shipment Inspection: Each unit undergoes functional power-on verification, cosmetic inspection, and label/serial-number cross-check before dispatch.
- Authenticity Guarantee: Konmask.com provides a written counterfeit-free guarantee backed by supplier chain-of-custody records.
- Packaging: Original OEM packaging or equivalent ESD-safe anti-static packaging with foam cushioning for international freight.
Procurement Process
- Inquiry: Submit your BOM line or part number to support@konmask.com or via the product page quote form.
- Lead Time Confirmation: Our team confirms stock availability and lead time within 1 business day.
- Quotation: Formal quotation issued with unit price, freight terms (EXW Xiamen / DDP options), and payment terms.
- Order Placement: Purchase order accepted via email; proforma invoice issued for T/T or LC payment.
- Shipment: Dispatched via DHL Express, FedEx, or sea freight with full export documentation (commercial invoice, packing list, CO if required).
- After-Sales: 12-month warranty against manufacturing defects; RMA process available.
Technical FAQ
Q: Is the ANPV0504TS1 compatible with Panasonic FP7 series PLCs?
A: Yes. The PV500 communicates with FP7 via Ethernet (MEWTOCOL-COM) and RS-232C serial link using standard Panasonic driver libraries.
Q: Can the unit run third-party SCADA software?
A: Yes. The Windows Embedded OS supports industry-standard SCADA packages including Wonderware InTouch, Ignition, and iFIX, subject to hardware resource compatibility.
Q: What is the typical lead time for ANPV0504TS1?
A: In-stock units ship within 3–5 business days. Out-of-stock lead time is 4–8 weeks depending on Panasonic factory allocation.
Q: Do you provide a Certificate of Origin for customs clearance?
A: Yes. A Japan-origin CO is available for all shipments requiring preferential tariff treatment under applicable trade agreements.
Q: Is repair/refurbishment service available?
A: Konmask.com partners with certified Panasonic service centers. Contact us for repair quotation and turnaround time.
