Phoenix Contact OC-LK-2MBD Fiber Optic Monitoring Module | Replacement, Equivalent & Selection Guide
The Phoenix Contact OC-LK-2MBD is an industrial-grade fiber optic link/monitoring module designed for reliable optical signal transmission and supervision in demanding automation environments. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make the right sourcing decision.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | OC-LK-2MBD |
| Manufacturer | Phoenix Contact |
| Product Series | OC-LK (Optical Coupler – Link) |
| Function | Fiber Optic Monitoring Module |
| Interface Type | Fiber Optic (Duplex) |
| Transmission Rate | 2 Mbit/s |
| Fiber Type | Multi-mode (POF / HCS) |
| Supply Voltage | 24 V DC (nominal) |
| Housing / Form Factor | DIN Rail mountable |
| Weight | 323 g |
| Operating Temperature | -25 °C … +70 °C (typical Phoenix Contact range) |
| Protection Class | IP20 |
| Standards | CE, UL (refer to official datasheet for current certifications) |
Note: Always verify specifications against the official Phoenix Contact datasheet before final design-in.
Compatible Replacement & Equivalent Models
If the OC-LK-2MBD is discontinued, long lead-time, or outside budget, the following alternatives may be considered. Verify electrical and mechanical compatibility before substitution.
| Model | Manufacturer | Key Difference | Compatibility Notes |
|---|---|---|---|
| OC-LK-2MBD-R | Phoenix Contact | Redundant version | Drop-in for redundant topologies |
| OC-LK-1MBD | Phoenix Contact | 1 Mbit/s variant | Lower data rate; check system requirements |
| PSI-MOS-RS232/FO 850 E | Phoenix Contact | RS-232 to fiber converter | Different interface; evaluate protocol compatibility |
| FL MC 10/100BASE-T/FO ST | Phoenix Contact | Ethernet fiber media converter | For Ethernet-based upgrades |
| Third-party equivalents | Various | Varies by vendor | Confirm pinout, voltage, and protocol before use |
Need help selecting the right replacement? Contact our technical team at support@konmask.com.
Why Choose the Original OC-LK-2MBD
- Proven reliability – Phoenix Contact’s OC-LK series is field-tested in thousands of industrial installations worldwide.
- Guaranteed compatibility – Original part ensures full compatibility with existing Phoenix Contact INTERBUS and fiber optic network topologies.
- Factory certifications – CE, UL, and other regional approvals maintained by the OEM.
- Long service life – Designed for continuous 24/7 industrial operation in harsh environments.
- OEM support – Access to Phoenix Contact technical documentation, firmware, and after-sales support.
Typical Applications
- INTERBUS fiber optic ring and line topologies
- Industrial Ethernet fiber optic segment bridging
- PLC-to-field device optical communication links
- Long-distance noise-immune data transmission in manufacturing plants
- Process automation in chemical, oil & gas, and power generation facilities
- Machine tool and robotics control networks
System Compatibility
- Compatible bus systems: INTERBUS, PROFIBUS (with appropriate converters), RS-232/RS-485 optical links
- Compatible PLCs: Phoenix Contact ILC series, Siemens S7 (via gateway), Rockwell ControlLogix (via gateway)
- Fiber connectors: ST, SC, or proprietary Phoenix Contact connectors (verify per datasheet)
- Cable types: POF (Plastic Optical Fiber), HCS (Hard Clad Silica), glass fiber (model-dependent)
Selection Guide
Use the following criteria to confirm the OC-LK-2MBD is the right module for your application:
| Selection Criterion | OC-LK-2MBD Suitability |
|---|---|
| Required data rate ≤ 2 Mbit/s | ✅ Fully supported |
| Multi-mode fiber infrastructure | ✅ Fully supported |
| 24 V DC power supply available | ✅ Fully supported |
| DIN rail mounting required | ✅ Fully supported |
| INTERBUS network topology | ✅ Native support |
| Data rate > 2 Mbit/s required | ❌ Consider higher-speed variant |
| Single-mode fiber required | ❌ Check alternative OC-LK models |
| Ethernet protocol required | ❌ Use FL MC series instead |
Quality Assurance & Sourcing
- Source: Konmask.com sources OC-LK-2MBD units from authorized distributors and verified secondary-market suppliers.
- Inspection: All units undergo visual inspection and basic functional verification prior to shipment.
- Authenticity: Original Phoenix Contact labeling, part markings, and packaging are preserved.
- Warranty: 90-day return-to-base warranty on all stocked units. Extended warranty available on request.
- Traceability: Batch records and supplier documentation available for regulated industries.
How to Order
- Confirm your required quantity and delivery timeline.
- Add the OC-LK-2MBD to your cart and proceed to checkout, or contact us for a formal quotation.
- For bulk orders (>5 units) or urgent requirements, email support@konmask.com or call +0086 19859288691.
- We support T/T bank transfer, PayPal, and major credit cards.
- Shipping: DHL / FedEx / UPS express worldwide. Lead time: 1–5 business days for in-stock units.
Replacement & Compatibility FAQ
Q: Is the OC-LK-2MBD still in production?
A: Phoenix Contact periodically updates its product portfolio. Contact us or Phoenix Contact directly to confirm current production status.
Q: Can I use a third-party fiber optic module as a direct replacement?
A: Possibly, but you must verify data rate, fiber type, connector type, supply voltage, and protocol compatibility. We recommend testing in a non-production environment first.
Q: What is the difference between OC-LK-2MBD and OC-LK-1MBD?
A: The primary difference is the maximum transmission rate: 2 Mbit/s vs. 1 Mbit/s. Choose based on your network’s bandwidth requirements.
Q: Do you offer technical support for integration?
A: Yes. Our engineering team can assist with compatibility assessment and integration guidance. Contact support@konmask.com.
Q: Can you source the OC-LK-2MBD if it is not currently in stock?
A: Yes. We offer sourcing services for hard-to-find Phoenix Contact parts. Submit a sourcing request via email.
