PROFACE GP2300-TC41-24V – 5.7″ STN Color HMI Touch Panel | GP2300 Series
Engineering Background: The GP2300 Series represents Pro-face’s (PROFACE) mid-range operator interface platform, engineered for demanding industrial environments where reliable human-machine interaction is non-negotiable. Designed to integrate seamlessly with major PLC brands including Mitsubishi, Omron, Siemens, and Rockwell Automation, the GP2300-TC41-24V delivers proven field performance across discrete manufacturing, process control, and machine automation sectors.
Product Positioning: The GP2300-TC41-24V is a 5.7-inch STN color touch panel operating on 24VDC, programmed via GP-PRO/PBIII (Pro-face proprietary software). It targets OEM machine builders, system integrators, and MRO procurement engineers who require a drop-in replacement or new-build HMI with guaranteed compatibility and traceable sourcing. Konmask.com stocks and supplies this unit with full quality verification for global B2B buyers.
Complete Technical Specifications
- Model Number: GP2300-TC41-24V
- Manufacturer: PROFACE (Pro-face / Xycom / Schneider Electric HMI)
- Series: GP2300
- Display Type: 5.7″ STN Color LCD
- Resolution: 320 × 240 pixels (QVGA)
- Touch Panel Type: Analog resistive
- Power Supply: 24VDC (±10%)
- Power Consumption: Approx. 15W
- Communication Ports: RS-232C, RS-422/485
- Programming Software: GP-PRO/PBIII for Windows
- Memory: Internal flash memory for screen data
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -20°C to 60°C
- Humidity: 10% to 90% RH (non-condensing)
- Protection Rating: Front panel IP65
- Panel Cutout: Per PROFACE GP2300 series standard dimensions
- Weight: Approx. 960g
- Country of Origin: Japan
- Compliance: CE, UL listed
Proven Application Environments
- Discrete manufacturing: automotive assembly lines, press machines, conveyor control
- Process industries: water treatment, chemical dosing, HVAC control panels
- Packaging machinery: filling, labeling, and wrapping equipment
- Textile and printing machinery operator stations
- MRO replacement for existing GP2300-series installations
- OEM machine builder new-build HMI integration
Engineering Advantages
- Wide PLC Compatibility: Native driver support for Mitsubishi MELSEC, Omron SYSMAC, Siemens S7, Allen-Bradley, Modbus RTU/ASCII, and 200+ additional protocols via GP-PRO/PBIII
- IP65 Front Panel: Sealed against dust and water ingress for harsh shop-floor environments
- 24VDC Operation: Directly powered from standard industrial control panel DC bus — no additional PSU required
- Compact Footprint: Panel-mount design minimizes enclosure space while maximizing operator visibility
- Proven Longevity: GP2300 platform has 15+ years of field deployment history with extensive spare-parts ecosystem
- Analog Resistive Touch: Operable with gloves; resistant to false activation in vibration-prone environments
System Architecture & Signal Flow
The GP2300-TC41-24V operates as a master HMI node communicating with downstream PLCs or controllers via RS-232C or RS-422/485 serial links. Screen projects are developed offline in GP-PRO/PBIII, transferred to the unit via CF card or serial download, and executed locally on the panel’s embedded processor. Tag-based addressing maps PLC register addresses directly to display objects (numeric displays, bar graphs, alarm lists, trend charts), enabling real-time visualization of process variables without intermediate middleware. The 24VDC power input is isolated from the communication ground, reducing noise coupling in electrically noisy panel environments.
Sourcing & Quality Verification
- Source: Konmask.com procures GP2300-TC41-24V units through authorized industrial distribution channels and verified secondary-market suppliers with full traceability documentation
- Inspection: Each unit undergoes visual inspection, power-on functional test, and communication port verification prior to shipment
- Authenticity: Nameplate, serial number, and firmware version are cross-referenced against PROFACE factory records where available
- Packaging: Anti-static bag + foam-lined carton; original PROFACE packaging retained where present
- Warranty: 90-day Konmask operational warranty; extended warranty available on request
Procurement Process
- Submit RFQ: Contact support@konmask.com with quantity, required delivery date, and destination country
- Quotation: Receive formal quotation with unit price, lead time, and shipping options within 1 business day
- Order Confirmation: Issue PO or pay via secure online checkout; proforma invoice available for T/T wire transfer
- Quality Check & Dispatch: Unit tested, packed, and dispatched with tracking number and commercial invoice
- After-Sales Support: Technical support available via email for integration and commissioning questions
Technical FAQ
Q: Is the GP2300-TC41-24V compatible with GP-PRO/PBIII EX?
A: Yes. GP-PRO/PBIII EX is the successor software and maintains backward compatibility with GP2300 series screen projects.
Q: Can this unit communicate with Mitsubishi Q-series PLCs?
A: Yes, via the Mitsubishi MELSEC-Q driver available in GP-PRO/PBIII. RS-232C or RS-422 connection to the PLC’s serial port is required.
Q: What is the panel cutout dimension?
A: Refer to the PROFACE GP2300 series installation manual (document number available on request). Standard GP2300 cutout dimensions apply.
Q: Is a CF card required for operation?
A: No. Screen data is stored in internal flash memory. A CF card is used only during project download or for data logging functions.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com to request the official PROFACE GP2300-TC41-24V datasheet and installation manual.
