Genuine ProSoft MVI56-DFCMR DF1 to Modbus RTU/ASCII Communication Module | MVI56 Series – Verified Source
The ProSoft MVI56-DFCMR is a high-performance communication bridge module designed for Allen-Bradley ControlLogix platforms, enabling seamless protocol conversion between DF1 (Allen-Bradley) and Modbus RTU/ASCII networks. Sourced directly through verified distribution channels, every unit sold by Konmask.com undergoes our rigorous 4-step authentication process before shipment.
Technical Specifications
- Part Number: MVI56-DFCMR
- Manufacturer: ProSoft Technology
- Series: MVI56 (ControlLogix Platform)
- Protocol Conversion: DF1 ↔ Modbus RTU / Modbus ASCII
- Backplane Interface: Allen-Bradley ControlLogix 1756 chassis
- Serial Ports: 2 × RS-232/422/485 configurable ports
- Data Transfer Rate: Up to 115,200 bps
- Power Consumption: 800 mA @ 5 VDC (from backplane)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Weight: 230 g
- Certifications: CE, UL, cUL
- Firmware: Field-upgradeable via ProSoft Configuration Builder (PCB)
Our 4-Step Quality Verification Process
- Source Authentication – All units are procured exclusively from ProSoft Technology authorized distributors or verified OEM surplus channels with traceable documentation.
- Physical Inspection – Each module is inspected for label integrity, serial number consistency, connector condition, and housing authenticity against ProSoft’s published specifications.
- Functional Bench Test – Where applicable, modules are powered and communication ports are verified using ProSoft Configuration Builder software prior to packaging.
- Secure Packaging & Documentation – Units ship with original or equivalent ESD-safe packaging, a packing slip with part number confirmation, and a Konmask authenticity seal.
Key Features & Benefits
- ✅ Bidirectional DF1 to Modbus RTU/ASCII protocol conversion in a single ControlLogix slot
- ✅ Supports both Master and Slave operation modes on Modbus network
- ✅ Configurable via ProSoft Configuration Builder (PCB) – no custom programming required
- ✅ Extensive diagnostic LEDs for real-time communication status monitoring
- ✅ Supports up to 5,000 registers of data exchange between DF1 and Modbus devices
- ✅ Compatible with RSLogix 5000 / Studio 5000 Logix Designer
- ✅ Field-proven in thousands of industrial installations worldwide
- ✅ Reduces integration cost by eliminating custom gateway hardware
Typical Applications
- Integrating legacy Allen-Bradley DF1 devices into modern Modbus-based SCADA systems
- Connecting third-party Modbus RTU/ASCII instruments (drives, meters, sensors) to ControlLogix PLCs
- Oil & gas pipeline monitoring and control systems
- Water/wastewater treatment plant automation
- Power generation and distribution control
- Manufacturing process control and data acquisition (SCADA/DCS integration)
- Building automation and energy management systems
Compatible System Components
- PLC Platform: Allen-Bradley ControlLogix 1756 series chassis
- Software: RSLogix 5000 / Studio 5000 Logix Designer, ProSoft Configuration Builder (PCB)
- Related ProSoft Modules: MVI56-MCM, MVI56-MNET, MVI56-DFNT, MVI56-GSC
- Compatible Devices: Any Modbus RTU/ASCII compliant device (drives, HMIs, meters, RTUs)
- Power Supply: Sourced from ControlLogix backplane (no external power required)
Global Sourcing & Shipping Capabilities
Konmask.com operates as a global industrial automation parts supplier headquartered in China, serving customers across North America, Europe, Southeast Asia, the Middle East, and beyond.
- Lead Time: In-stock units typically ship within 1–3 business days
- Shipping Methods: DHL Express, FedEx International Priority, UPS Worldwide, EMS
- Export Compliance: All shipments comply with applicable export control regulations (EAR/ECCN)
- Customs Documentation: Commercial invoice, packing list, and certificate of origin provided upon request
- Packaging: ESD-safe anti-static bag, foam-padded carton, moisture barrier where required
Certifications & Compliance Statement
- CE Marking: Compliant with EU Machinery Directive and EMC Directive
- UL / cUL Listed: Recognized for use in North American industrial environments
- RoHS Compliant: Meets EU Directive 2011/65/EU on restriction of hazardous substances
- REACH: Compliant with EU REACH regulation (EC) No 1907/2006
Konmask.com is an independent reseller and is not an authorized ProSoft Technology distributor. All trademarks remain the property of their respective owners. Authenticity is verified through our internal quality process as described above.
How to Order
- Confirm Part Number: Verify MVI56-DFCMR matches your ControlLogix system requirements and firmware revision needs.
- Request a Quote: Contact us at [email protected] or via WhatsApp/WeChat at +0086 19859288691 for volume pricing and availability confirmation.
- Place Your Order: Add to cart and complete checkout, or request a proforma invoice for bank transfer / TT payment.
- Receive & Verify: Inspect your shipment upon arrival. Our team provides post-sale technical support for installation and configuration queries.
Authenticity & Trust FAQ
- Q: Is this a genuine ProSoft MVI56-DFCMR?
- A: Yes. All units are sourced from verified supply channels and pass our 4-step quality verification process before shipment.
- Q: Do you provide a warranty?
- A: We offer a 90-day functional warranty on all modules. Extended warranty options are available upon request.
- Q: Can I return the module if it doesn’t work?
- A: Yes. We accept returns within 30 days of delivery for modules that fail to function as specified, subject to our return policy.
- Q: Do you provide technical support for installation?
- A: Yes. Our engineering team can assist with ProSoft Configuration Builder setup, RSLogix 5000 Add-On Instructions (AOI), and communication troubleshooting.
- Q: What payment methods do you accept?
- A: We accept major credit cards, PayPal, bank wire transfer (TT), and Western Union for international orders.
