ProSoft MVI69-104S Input/Output Module | Replacement, Equivalent & Selection Guide
The ProSoft MVI69-104S is a high-performance serial communication I/O module designed for the Allen-Bradley CompactLogix platform. Whether you are sourcing an original unit, evaluating compatible replacements, or selecting the right module for a new project, this guide provides the technical depth and selection criteria your engineering team needs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | MVI69-104S |
| Manufacturer | ProSoft Technology |
| Platform Compatibility | Allen-Bradley CompactLogix (1769 backplane) |
| Protocol | IEC 60870-5-104 Slave (TCP/IP) |
| Communication Ports | Ethernet (RJ45) |
| Power Consumption | 800 mA @ 5 VDC (from backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | Standard 1769 single-slot module |
| Weight | Approx. 200 g |
| Certifications | CE, UL |
| Firmware | Field-upgradeable via USB |
Compatible Replacement & Equivalent Models
When the MVI69-104S is unavailable or end-of-life, the following models may serve as functional equivalents depending on your application requirements. Always verify protocol, backplane compatibility, and firmware version before substitution.
- ProSoft MVI69E-104S — Enhanced Ethernet version with additional diagnostic features; direct functional upgrade for most IEC 104 Slave applications on CompactLogix.
- ProSoft MVI56-104S — ControlLogix platform equivalent; requires chassis change but identical protocol stack.
- ProSoft MVI69-104M — IEC 60870-5-104 Master variant; select when the CompactLogix must act as master rather than slave.
- Moxa MGate 5105-MB-EIP — Third-party gateway option for protocol bridging; suitable for retrofit scenarios where backplane slot is unavailable.
- Red Lion DA10D — Universal protocol converter supporting IEC 104; applicable in multi-protocol environments.
Note: Third-party replacements may require additional configuration and are not plug-and-play substitutes. Contact Konmask for compatibility assessment.
Why Choose the Original Model
- Native backplane integration — Communicates directly over the 1769 backplane with zero external wiring overhead.
- ProSoft Configuration Manager (PCM) — Dedicated software tool for rapid commissioning, diagnostics, and firmware updates.
- Proven IEC 104 compliance — Certified interoperability with SCADA systems including GE iFIX, Wonderware, and Ignition.
- Long-term vendor support — ProSoft provides firmware updates, technical documentation, and application engineering support.
- Deterministic data transfer — Optimized for real-time telemetry in power utility and infrastructure SCADA networks.
Typical Applications
- Power utility SCADA — substation automation and remote terminal unit (RTU) integration via IEC 60870-5-104.
- Water and wastewater treatment — remote monitoring of pump stations and flow control systems.
- Oil & gas pipeline telemetry — pressure, flow, and valve status reporting to control centers.
- Building management systems (BMS) — energy metering and HVAC integration with IEC 104 master SCADA.
- Transportation infrastructure — tunnel ventilation and traffic management PLC-to-SCADA communication.
System Compatibility
- PLC Platform: Allen-Bradley CompactLogix 1769 series (L23, L24, L27, L30, L31, L32, L33, L35, L36, L43, L45)
- Studio 5000 / RSLogix 5000: Version 16.0 and above
- SCADA / HMI: Any IEC 60870-5-104 compliant master — GE iFIX, Wonderware InTouch, Ignition, Citect SCADA
- Network: Standard Ethernet TCP/IP; supports multiple simultaneous master connections
- Backplane slots: Occupies one 1769 I/O slot; compatible with all standard 1769 power supplies
Selection Guide
Use the criteria below to confirm the MVI69-104S is the correct module for your project, or to identify the appropriate alternative:
- Platform: CompactLogix 1769 → MVI69-104S ✓ | ControlLogix 1756 → MVI56-104S
- Role: IEC 104 Slave (RTU/field device) → MVI69-104S ✓ | IEC 104 Master (SCADA) → MVI69-104M
- Connectivity: Ethernet TCP/IP required → MVI69-104S ✓ | Serial RS-232/485 only → consider MVI69-MCM
- Slot availability: Backplane slot available → MVI69-104S ✓ | No slot available → external gateway (Moxa MGate)
- Budget / lead time: Original preferred for warranty and support; certified refurbished available from Konmask stock.
Quality Assurance & Sourcing
All MVI69-104S units supplied by Konmask.com undergo the following quality process:
- Visual inspection and label verification against ProSoft factory markings.
- Power-on functional test with backplane communication verification.
- Firmware version check and documentation of installed version.
- Anti-static packaging with humidity indicator card for safe international shipping.
- Certificate of conformance (CoC) available upon request for regulated industries.
We source directly from authorized distributors and verified secondary-market channels. Counterfeit risk is mitigated through serial number traceability and factory cross-reference.
How to Order
- Online: Add to cart directly from this page. Bulk pricing available for orders of 3+ units — contact us for a quote.
- Email: Send your PO or RFQ to support@konmask.com with quantity, required delivery date, and destination country.
- Phone / WhatsApp: +0086 19859288691 — available Monday–Saturday, 09:00–18:00 CST.
- Lead time: In-stock units ship within 1–3 business days. Out-of-stock units: 7–21 business days depending on sourcing.
- Export: We ship worldwide. DDP (Delivered Duty Paid) terms available for select countries. HS Code: 8537.10 (subject to customs verification).
Replacement & Compatibility FAQ
Q: Can the MVI69-104S replace an older MVI69-104S with a different firmware version?
A: Yes. Firmware is field-upgradeable via USB using ProSoft Configuration Manager. Ensure the ladder logic add-on instruction (AOI) version matches the firmware.
Q: Is the MVI69E-104S a drop-in replacement for the MVI69-104S?
A: Physically and functionally yes for most applications. The MVI69E variant adds enhanced Ethernet diagnostics. Verify your PCM project file is compatible with the E-series firmware before swapping.
Q: Can I use this module with MicroLogix instead of CompactLogix?
A: No. The MVI69-104S requires the 1769 CompactLogix backplane. For MicroLogix, ProSoft offers the MVI46 or MVI71 series depending on the platform.
Q: What is the warranty on units purchased from Konmask?
A: New units carry the original ProSoft manufacturer warranty. Refurbished units carry a 90-day Konmask functional warranty. Extended warranty available upon request.
Q: Do you provide the ProSoft Configuration Manager software?
A: PCM is freely available from ProSoft Technology’s website. We can provide the sample ladder logic and configuration files for common SCADA integrations upon request.
