Genuine Allen-Bradley 1769-OB32 32-Point 24VDC Digital Output Module | CompactLogix 1769 Series — Verified Source
Konmask.com is a dedicated industrial automation components supplier specializing in genuine Allen-Bradley / Rockwell Automation hardware. The 1769-OB32 is a high-density 32-point sourcing digital output module designed for the CompactLogix 1769 platform, delivering reliable 24VDC discrete control in demanding industrial environments. Every unit we ship is sourced through verified supply channels and undergoes our documented quality verification process before dispatch.
Technical Specifications
- Part Number: 1769-OB32
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: CompactLogix 1769
- Module Type: Digital Output (Sourcing)
- Number of Output Points: 32
- Output Voltage: 24V DC
- Output Current per Point: 0.5 A max
- Total Module Current: 4 A max (all outputs ON)
- Backplane Current Draw (5V): 120 mA
- Backplane Current Draw (24V): 0 mA
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to 85 °C
- Relative Humidity: 5% to 95% (non-condensing)
- Dimensions (H × W × D): 118 × 35 × 87 mm (approx.)
- Weight: ~400 g
- Certifications: UL, CE, cUL
- Wiring Type: Removable terminal block
Our 4-Step Quality Verification Process
Every 1769-OB32 unit shipped from Konmask.com passes through our documented four-step verification protocol:
- Step 1 — Source Validation: We confirm the supply chain origin and cross-reference supplier credentials against known authorized distributor networks. No grey-market or unverified sources are accepted.
- Step 2 — Physical Inspection: Each unit is inspected for label integrity, firmware revision markings, housing condition, and connector pin alignment. Counterfeit indicators are checked against Rockwell Automation’s published authentication guidelines.
- Step 3 — Functional Bench Test (where applicable): Selected units undergo power-on verification and I/O point continuity checks prior to packaging.
- Step 4 — Secure Packaging & Documentation: Units are packed in anti-static ESD-safe materials with a packing slip, inspection record, and traceability reference. A certificate of conformance is available upon request.
Key Features & Benefits
- High-density 32-point output in a single compact module slot — reduces panel footprint
- Sourcing (PNP) output type compatible with standard 24VDC field devices
- Removable terminal block simplifies wiring and module replacement without rewiring
- LED status indicators per output point for rapid field diagnostics
- Hot-swap capable within CompactLogix system (controller-dependent)
- Fully compatible with Studio 5000 Logix Designer for seamless configuration
- Robust design rated for industrial ambient conditions up to 60 °C
Typical Applications
- Discrete actuator and solenoid valve control in manufacturing lines
- Conveyor and material handling system I/O expansion
- Packaging machinery output control
- Automotive assembly line automation
- Food & beverage processing equipment
- Water/wastewater treatment plant control panels
- Building automation and HVAC control systems
Compatible System Components
- Controllers: 1769-L16ER-BB1B, 1769-L18ER-BB1B, 1769-L24ER-QB1B, 1769-L27ERM-QBFC1B, 1769-L30ER, 1769-L33ER, 1769-L36ERM and other CompactLogix 5370/5380 controllers
- Power Supplies: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
- End Caps: 1769-ECR (right end cap), 1769-ECL (left end cap)
- Programming Software: Studio 5000 Logix Designer v21.00 or later
- Related Output Modules: 1769-OB16, 1769-OB32T, 1769-OW8, 1769-OA8
Global Sourcing & Shipping Capabilities
Konmask.com maintains established procurement relationships across Asia-Pacific, Europe, and North America, enabling us to source both current-production and legacy/discontinued Allen-Bradley modules. We ship worldwide with the following capabilities:
- Domestic (China): SF Express / JD Logistics — typically 1–3 business days
- International: DHL Express, FedEx International Priority, UPS Worldwide — typically 3–7 business days depending on destination and customs clearance
- Export Documentation: Commercial invoice, packing list, and certificate of origin available for all international shipments
- Customs HS Code: 8537.10 (Boards, panels, consoles for electric control) — we can assist with customs classification queries
- Minimum Order: 1 unit; volume pricing available for orders of 5+ units
Certifications & Compliance Statement
The Allen-Bradley 1769-OB32 carries the following certifications as issued by Rockwell Automation:
- UL Listed (UL 508)
- CE Marked (EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU)
- cUL Listed (Canadian Standards)
- RoHS Compliant
Konmask.com does not manufacture or modify any hardware. All certification marks are original to the manufacturer. We provide documentation traceability upon request. If your project requires specific compliance documentation, please contact us before ordering.
How to Order
- Online: Add to cart directly on this page. We accept T/T bank transfer, PayPal, and major credit cards.
- Bulk / B2B Inquiry: Email [email protected] with your required quantity, delivery timeline, and destination country for a formal quotation within 24 hours.
- Phone / WhatsApp: +0086 19859288691 (Monday–Saturday, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–2 business days of payment confirmation. Out-of-stock units: estimated lead time provided at inquiry stage.
- Returns: 30-day return policy for unused, unopened units in original packaging. DOA (Dead on Arrival) units replaced at no charge within 7 days of receipt.
Authenticity & Trust FAQ
Q: How do I know the 1769-OB32 I receive is genuine?
A: Every unit passes our 4-step verification process (detailed above). We provide a packing inspection record with each shipment. If you have any authenticity concerns upon receipt, contact us immediately — we will work with you to resolve the issue.
Q: Are you an authorized Allen-Bradley distributor?
A: Konmask.com is an independent industrial automation components supplier. We are not an official Rockwell Automation authorized distributor. We source through verified secondary-market and surplus channels. This allows us to offer competitive pricing on both current and legacy parts. We are fully transparent about our supply chain model.
Q: Can you provide a certificate of conformance or test report?
A: Yes. A certificate of conformance is available upon request for all units. Bench test reports are available for units that have undergone functional verification. Please request these documents at the time of order.
Q: What if the module is incompatible with my system?
A: Please verify compatibility using the technical specifications and compatible components list above, or consult the official Rockwell Automation 1769-OB32 Installation Instructions (Publication 1769-IN059). If you are unsure, contact us before purchasing — we are happy to assist with compatibility checks.
Q: Do you offer warranty?
A: Yes. We offer a 90-day warranty against manufacturing defects and DOA failures. Warranty does not cover damage caused by incorrect installation, overvoltage, or physical mishandling.
