Vibration Monitoring Solution – Provib Tech PT2060/40-A0-H | PT2060 Series
Where This Product Is Used
The Provib Tech PT2060/40-A0-H proximity relay module is deployed in critical rotating machinery protection and condition monitoring systems across heavy industry. Typical installation environments include:
- Steam & Gas Turbines – Shaft radial vibration and axial position monitoring per API 670
- Centrifugal & Screw Compressors – Continuous proximity measurement to detect rotor instability and surge events
- Pumps & Fans – Bearing journal orbit analysis and imbalance detection in process-critical assets
- Gearboxes – Gear mesh frequency monitoring and shaft displacement trending
- Electric Motors (HV/MV) – Air-gap monitoring and rotor eccentricity detection
- Marine Propulsion Systems – Shaft line vibration surveillance in confined machinery spaces
- Power Generation Plants – Integration into plant DCS/SCADA for real-time machinery health dashboards
Technical Specifications
| Parameter | Value |
|---|---|
| Model | PT2060/40-A0-H |
| Series | PT2060 |
| Manufacturer | Provib Tech |
| Function | Proximity Relay Module (Eddy-Current Signal Conditioning) |
| Measurement Range | 40 mm (nominal) |
| Output Type | Analog (A0 configuration) |
| Housing / Form Factor | DIN-rail mountable module (H variant) |
| Input Signal | Compatible with standard eddy-current proximity probe systems |
| Supply Voltage | Refer to datasheet (typically 24 VDC) |
| Operating Temperature | -20 °C to +70 °C (standard industrial range) |
| Weight | 800 g (packaged) |
| Approvals | CE; consult factory for SIL/ATEX variants |
Full datasheet available upon request. Contact support@konmask.com for OEM documentation.
Why Engineers Specify This Model
- Plug-and-play signal conditioning – Converts raw eddy-current probe output into a clean, calibrated analog signal ready for DCS, PLC, or standalone protection relay input
- 40 mm measurement range – Optimized for large-shaft turbomachinery where standard 8 mm or 14 mm probes are insufficient
- DIN-rail form factor (H variant) – Simplifies panel integration and reduces wiring complexity in marshalling cabinets
- Analog output (A0) – Direct 4–20 mA or voltage loop compatibility with existing SCADA/historian infrastructure
- Proven Provib Tech lineage – PT2060 series is a recognized platform in European turbomachinery OEM and EPC contractor specifications
- Reduced commissioning time – Factory-calibrated modules minimize field adjustment and accelerate plant startup schedules
Complete System Bill of Materials
For a complete proximity monitoring channel using the PT2060/40-A0-H, engineers typically specify:
- Eddy-current proximity probe (8 mm or 14 mm tip, application-dependent)
- Extension cable (probe-to-driver, matched impedance)
- Driver/oscillator unit (Provib Tech PT series or compatible)
- PT2060/40-A0-H – Signal conditioning relay module (this item)
- DIN-rail power supply (24 VDC, appropriately rated)
- Barrier / isolator (for hazardous area installations)
- DCS/PLC analog input card or standalone vibration monitor
Contact support@konmask.com to source complete channel kits or individual components.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (proximity probe channel architecture)
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machines
- IEC 61511 – Functional safety (SIL-rated variants available; consult factory)
- CE Marking – EMC Directive and Low Voltage Directive compliance
- ATEX / IECEx – Hazardous area variants available upon request
Quality Assurance & Sourcing
Konmask.com sources the Provib Tech PT2060/40-A0-H through verified industrial distribution channels. Every unit undergoes:
- Visual and dimensional inspection upon receipt
- Functional power-on verification
- Traceability documentation (batch/lot records retained)
- Secure anti-static packaging for international shipment
We supply to MRO procurement teams, EPC contractors, OEM service centers, and plant maintenance engineers globally. Lead times and stock availability confirmed at order.
How to Source This Part
- Add to cart directly on this page for in-stock units
- Request a quote – Email support@konmask.com with your PO number, required quantity, and delivery address
- Call / WhatsApp – +0086 19859288691 for urgent requirements or technical pre-sales questions
- Bulk / contract orders – Framework pricing available for recurring MRO procurement programs
Application-Specific FAQ
Q: Is the PT2060/40-A0-H compatible with third-party proximity probes (e.g., Bently Nevada, Emerson)?
A: The PT2060 series is designed for Provib Tech probe systems. Cross-compatibility with third-party probes depends on driver impedance matching. Contact us for a compatibility assessment before ordering.
Q: Can this module be used in SIL 2 safety loops?
A: Standard variants are not SIL-rated. Provib Tech offers SIL-certified variants in the PT2060 family. Contact Konmask for SIL documentation and FMEDA reports.
Q: What is the difference between the A0 and other output variants?
A: The A0 suffix denotes the standard analog output configuration. Other suffixes may indicate relay contact outputs, HART, or digital bus options. Confirm your DCS input card requirements before specifying.
Q: Do you provide calibration certificates?
A: Factory calibration records are available. Third-party NIST-traceable calibration certificates can be arranged at additional cost. Inquire at order placement.
Q: What is the typical lead time?
A: Lead time varies by stock position. Contact us for real-time availability. Expedited shipping (DHL Express, FedEx Priority) available for urgent plant shutdowns.
