Provib Tech PT2060/43-A0-H – Proximity Relay Module | Vibration Monitoring Platform
Engineering Background
Provib Tech is an Italian manufacturer specializing in vibration monitoring and condition monitoring instrumentation for rotating machinery. The PT2060 series represents their field-proven proximity relay platform, widely deployed in power generation, petrochemical, and heavy industrial environments where continuous shaft displacement monitoring is critical to machine protection.
Product Positioning
The PT2060/43-A0-H is a dedicated proximity relay module designed to interface with eddy-current proximity probes for real-time radial shaft vibration and position monitoring. It provides configurable alarm and trip relay outputs, making it a core component in API 670-compliant machinery protection systems. Targeting maintenance engineers and OEM system integrators who require a reliable, rack-mountable relay module with deterministic response times.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Provib Tech (Italy) |
| Part Number / SKU | PT2060/43-A0-H |
| Series | PT2060 |
| Module Type | Proximity Relay Module |
| Function | Eddy-current proximity probe signal conditioning & relay output |
| Mounting | DIN rail / rack-mount (19″ chassis compatible) |
| Relay Outputs | Configurable alarm (Alert) and danger (Trip) relay contacts |
| Input Signal | Compatible with standard -24 VDC eddy-current proximity systems |
| Country of Origin | Italy |
| Weight | 800 g (approx.) |
| Compliance | Designed for API 670 machinery protection applications |
Proven Application Environments
- Power Generation: Steam and gas turbine shaft radial vibration monitoring
- Petrochemical & Refining: Compressor and pump protection systems
- Heavy Industry: Large motor and gearbox condition monitoring
- OEM Machine Builders: Integrated into custom machinery protection panels
- Retrofit Projects: Replacement module for legacy Provib Tech PT2060 series installations
Engineering Advantages
- Deterministic Relay Response: Fast trip relay actuation ensures machine protection within defined response windows
- Dual-threshold Architecture: Independent Alert and Danger setpoints reduce nuisance trips while maintaining protection integrity
- Italian Precision Manufacturing: Provib Tech’s ISO-compliant production ensures consistent calibration and long service life
- Direct Probe Compatibility: Designed for seamless integration with standard eddy-current proximity probe systems without additional signal conditioning
- Compact Form Factor: Rack-mountable design minimizes panel space while supporting multi-channel expansion
System Architecture & Signal Flow
The PT2060/43-A0-H operates within a three-component proximity measurement chain:
- Proximity Probe – Eddy-current sensor mounted adjacent to the rotating shaft
- Extension Cable – Coaxial cable transmitting the high-frequency oscillator signal
- PT2060/43-A0-H Relay Module – Receives the DC voltage signal from the driver/oscillator, applies configured Alert/Danger thresholds, and activates relay outputs to the control system or shutdown logic
The module’s relay contacts can be wired into PLC safety inputs, DCS interlock loops, or standalone annunciator panels, providing flexible integration into existing plant control architectures.
Sourcing & Quality Verification
- All Provib Tech modules at Konmask.com are sourced through verified industrial supply channels
- Each unit undergoes incoming inspection including visual, label, and functional continuity checks
- Original manufacturer documentation and calibration records provided where available
- Traceability documentation available upon request for critical plant applications
- Warranty: 12 months from shipment date against manufacturing defects
Procurement Process
- Confirm Part Number: Verify PT2060/43-A0-H matches your existing system documentation or probe driver specifications
- Request Quote: Contact support@konmask.com with quantity and delivery requirements
- Order Confirmation: Purchase order accepted via email; proforma invoice issued within 1 business day
- Shipping: DHL / FedEx international express; typical lead time 3–7 business days
- Documentation: Commercial invoice, packing list, and available test records shipped with unit
Technical FAQ
Q: Is the PT2060/43-A0-H compatible with all eddy-current proximity probe brands?
A: The module is designed for Provib Tech’s own proximity probe ecosystem. Compatibility with third-party probes (Bently Nevada, Metrix, etc.) should be verified against the probe driver output voltage range and cable impedance specifications.
Q: Can this module be used as a direct replacement for older PT2060 series variants?
A: The PT2060 series shares a common platform architecture. However, suffix codes (e.g., /43-A0-H) denote specific configuration options. Always cross-reference the full part number before substitution.
Q: What relay contact ratings does the PT2060/43-A0-H support?
A: Contact Konmask technical support for the full relay contact specification sheet. We can provide the original Provib Tech datasheet upon request.
Q: Do you offer expedited shipping for urgent plant shutdowns?
A: Yes. Contact support@konmask.com or call +0086 19859288691 to arrange priority handling and next-flight-out shipping options.
