Motion Control Solution – Bosch Rexroth HMS01.1N-W0110-A-07-NNNN | IndraDrive HMS Series
The Rexroth HMS01.1N-W0110-A-07-NNNN is a high-performance single-axis inverter from the IndraDrive HMS Series, engineered for demanding servo motion applications requiring precise speed and torque control. Rated at 11 kW continuous output power, this drive is a proven choice for machine builders and system integrators across heavy industry, precision manufacturing, and process automation.
Where This Product Is Used
The HMS01.1N-W0110-A-07-NNNN is specified in applications where high dynamic response and reliable axis control are critical:
- CNC Machining Centers – Feed axis and spindle control in multi-axis milling, turning, and grinding machines
- Injection Molding Machines – Clamp, injection, and ejector axis drives requiring precise force and velocity profiles
- Robotics & Handling Systems – Joint actuation in Cartesian, SCARA, and articulated robot arms
- Printing & Packaging Machinery – Register control, web tension, and cut-to-length positioning
- Metal Forming Presses – Servo press axis control with programmable force curves
- Semiconductor & Electronics Assembly – High-precision pick-and-place and wafer handling stages
- Textile Machinery – Winding, unwinding, and traverse axis synchronization
- Test Benches & Dynamometers – Torque and speed simulation for motor and gearbox validation
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | HMS01.1N-W0110-A-07-NNNN |
| Series | IndraDrive HMS (High Dynamic / Multi-Axis Supply) |
| Drive Type | Single Axis Inverter (Axis Module) |
| Continuous Output Power | 11 kW (W0110) |
| Supply Voltage | 3 × AC 400 V / 480 V (±10%) |
| Control Mode | Servo (closed-loop torque, velocity, position) |
| Firmware Variant | A (Standard) |
| Communication Interface | 07 – PROFIBUS DP + SERCOS II |
| Safety Option | NNNN – No integrated safety (external STO wiring required) |
| Cooling | Forced air (internal fan) |
| Protection Class | IP20 |
| Weight | ~5.3 kg |
| Compatible Supply Units | HMV01, HMV02 (IndraDrive supply modules) |
| Compatible Motors | Rexroth MKD, MKE, MSK, MAD, MAF series |
Why Engineers Specify This Model
- High Dynamic Performance – Fast current loop and velocity loop response for demanding servo axes
- Dual Fieldbus (PROFIBUS + SERCOS II) – Flexible integration into both PLC-centric and motion-centric architectures
- DC Bus Sharing – Pairs with IndraDrive HMV supply modules for energy-efficient multi-axis configurations
- Compact Bookshelf Design – Optimized for high-density control cabinet layouts
- Proven Reliability – Widely deployed in Rexroth IndraMotion MTX and MLC platforms
- Rich Diagnostic Tools – Compatible with IndraWorks DS commissioning and diagnostic software
Complete System Bill of Materials
A typical IndraDrive HMS axis requires the following components:
- Supply Module – e.g., Rexroth HMV01.1E-W0120 or HMV02.1R (regenerative)
- Axis Inverter – HMS01.1N-W0110-A-07-NNNN (this unit)
- Servo Motor – e.g., Rexroth MSK071C or MKD071B with resolver/encoder
- Motor Power Cable – RKL series (shielded, matched to motor frame)
- Encoder Feedback Cable – RKG series (resolver or EnDat)
- Control Cable – PROFIBUS or SERCOS fiber/copper per topology
- Braking Resistor – HLB01 (if non-regenerative supply is used)
- Control Voltage PSU – 24 VDC, ≥10 A for drive logic supply
Compliance & Industry Standards
- CE Marked – EU Machinery Directive 2006/42/EC & Low Voltage Directive 2014/35/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- RoHS Compliant – Directive 2011/65/EU
- EMC – EN 61800-3 Category C2 (with external EMC filter)
- Functional Safety – IEC 62061 / ISO 13849 (external STO circuit required for this variant)
Quality Assurance & Sourcing
Every unit offered by Konmask.com undergoes a structured inspection process:
- Visual inspection for physical damage, corrosion, and counterfeit indicators
- Label and firmware version verification against Rexroth documentation
- DC bus capacitor and power stage functional check where applicable
- Secure anti-static packaging with humidity indicator card
- Full traceability documentation available on request
We source from decommissioned OEM lines, certified surplus dealers, and authorized distribution channels. All units are sold with a 90-day functional warranty.
How to Source This Part
Ready to order or need a formal quotation?
- Email: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Payment: T/T (Wire Transfer), PayPal, Trade Assurance accepted
- Export: DDP / DAP worldwide; HS Code available for customs pre-clearance
Application-Specific FAQ
Q: Can this drive replace an HMS01.1N-W0110-A-07-NNNN with a different firmware suffix?
A: The firmware variant (position 4 of the part number) affects software features. Confirm the firmware version via IndraWorks before substitution. Contact us for compatibility assessment.
Q: Is SERCOS III supported?
A: No. The -07- interface code indicates SERCOS II + PROFIBUS DP. For SERCOS III, specify the HMS01.1N-W0110-A-07-NNNN with the appropriate interface variant (e.g., -09-).
Q: What supply module is required?
A: This axis module requires a compatible IndraDrive HMV supply module (HMV01 or HMV02 series) sharing the same DC bus rail. Size the supply based on total axis power demand.
Q: Can it drive a non-Rexroth motor?
A: Yes, with a custom motor data set configured in IndraWorks. Third-party motors with resolver or EnDat 2.1 encoders are supported. Engineering support available upon request.
Q: What is the minimum order quantity?
A: Single units are available. Volume pricing applies for orders of 3+ units.
