Servo Motion Control Solution – Bosch Rexroth CSH01.3C-SE-EN2-NNN-CCD-S2-S-NN-FW | IndraDrive Cs Series
Where This Product Is Used
The Bosch Rexroth CSH01.3C-SE-EN2-NNN-CCD-S2-S-NN-FW (Part No. R911329914) is an IndraDrive Cs series single-axis servo drive control unit engineered for precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers – Axis interpolation and spindle synchronization in multi-axis milling and turning machines
- Packaging Machinery – High-speed pick-and-place, form-fill-seal, and labeling lines requiring sub-millisecond positioning accuracy
- Printing & Converting Equipment – Register control and tension management in web-fed offset and flexographic presses
- Semiconductor & Electronics Assembly – Wafer handling, SMT placement, and precision dispensing systems
- Robotics & Handling Systems – Coordinated multi-axis gantry and SCARA robot joint control
- Plastics Processing – Injection molding clamping and ejector axis control with force feedback
- Textile Machinery – Warp beam and let-off tension regulation on weaving and knitting machines
Technical Specifications
| Manufacturer Part Number | R911329914 |
| Model / Type Code | CSH01.3C-SE-EN2-NNN-CCD-S2-S-NN-FW |
| Product Family | IndraDrive Cs (Compact Single-Axis) |
| Device Class | Control Section (C-type, single-axis) |
| Communication Interface | SERCOS II / EtherNet (EN2 option) |
| Encoder Interface | Hiperface / EnDat / Resolver (S2 option) |
| Firmware | FW (factory-loaded firmware) |
| Cooling | Integrated (self-cooled, compact form factor) |
| Weight | 5.3 kg |
| Operating Temperature | 0 °C to +45 °C (derating above 40 °C) |
| Protection Class | IP20 (cabinet installation) |
| Supply Voltage | 3 × 200–480 V AC, 50/60 Hz |
| Standards | CE, UL, cUL, RoHS |
Why Engineers Specify This Model
- Compact footprint – IndraDrive Cs integrates power and control sections in a single housing, reducing panel space by up to 40% vs. modular alternatives
- EN2 dual-port Ethernet – Supports SERCOS III and EtherNet/IP simultaneously, enabling seamless integration with Bosch Rexroth IndraMotion MTX/MLC and third-party PLCs
- S2 universal encoder interface – Compatible with Hiperface, EnDat 2.1/2.2, and resolver feedback without additional adapter hardware
- CCD cross-communication – Direct drive-to-drive communication for electronic gearing and cam synchronization without PLC cycle overhead
- Integrated safety (S option) – STO (Safe Torque Off) and SS1 functions certified to SIL 2 / PLd, eliminating external safety relays
- FW factory firmware – Pre-loaded and validated firmware reduces commissioning time and ensures version consistency across multi-axis systems
Complete System Bill of Materials
For a fully operational IndraDrive Cs axis, the following components are typically required alongside this control unit:
- IndraDrive Cs Power Section (HCS01 or HCS02 matching current rating)
- Bosch Rexroth MSK / MKD / MHD servo motor with compatible encoder
- SERCOS fiber-optic or Ethernet cable (axis-to-controller)
- 24 V DC control power supply (PSL01 or equivalent)
- Rexroth IndraWorks DS commissioning software license
- Motor power cable and feedback cable (application-length)
- DC bus capacitor module (if multi-axis common DC bus topology)
Compliance & Industry Standards
- CE Marking – Machinery Directive 2006/42/EC, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU
- UL / cUL Listed – UL 508C (Power Conversion Equipment)
- Functional Safety – IEC 62061 SIL 2, ISO 13849-1 PLd (integrated STO/SS1)
- RoHS 2 – Directive 2011/65/EU compliant
- REACH – No SVHC above threshold
Quality Assurance & Sourcing
Every unit offered by Konmask.com undergoes a structured verification process before dispatch:
- Visual inspection: housing integrity, connector condition, label legibility
- Part number cross-check against Bosch Rexroth official documentation
- Firmware version verification where applicable
- Anti-static packaging with humidity indicator card
- Traceable sourcing from authorized distributors or OEM decommissioned equipment
We supply both new-in-box and tested-used / refurbished units. Condition is clearly stated at time of quotation.
How to Source This Part
To request a quote or confirm availability for R911329914 / CSH01.3C-SE-EN2-NNN-CCD-S2-S-NN-FW:
- Add to cart and proceed to checkout for standard pricing
- Email [email protected] for volume pricing, lead time, or condition-specific requirements
- WhatsApp / WeChat: +0086 19859288691 for urgent inquiries
- Typical lead time: 3–7 business days (stock-dependent); expedited options available
Application-Specific FAQ
Q: Is this control unit compatible with IndraDrive M (HMS/HMD) power sections?
A: No. The CSH01 control section is designed exclusively for IndraDrive Cs compact power sections (HCS01/HCS02). It is not mechanically or electrically compatible with IndraDrive M modular power sections.
Q: Can this unit operate on a PROFINET network?
A: The EN2 option supports EtherNet/IP and SERCOS III natively. PROFINET requires a separate communication option module (e.g., CSE02 with PROFINET interface). Please confirm your fieldbus requirement before ordering.
Q: What is the difference between S1 and S2 encoder options?
A: S1 supports a single encoder interface; S2 provides dual encoder inputs, enabling motor encoder plus external linear scale feedback simultaneously — preferred for high-accuracy positioning applications.
Q: Do you provide the IndraWorks commissioning software?
A: IndraWorks DS is licensed separately through Bosch Rexroth. We can advise on version compatibility for this firmware variant upon request.
Q: Is a warranty provided?
A: Yes. New units carry the original manufacturer warranty. Refurbished units carry a 90-day Konmask functional warranty. Terms available on request.
