Precision Motion Control Solution – Rorze RD-023MS | RD Series Stepping Motor Drive
Where This Product Is Used
The Rorze RD-023MS is a high-resolution stepping motor drive engineered for demanding industrial automation environments where positional accuracy and repeatability are non-negotiable. Typical deployment scenarios include:
- Semiconductor wafer handling systems – FOUP/FOSB transport, wafer pre-aligners, and end-effector positioning on atmospheric and vacuum robots
- Flat panel display (FPD) manufacturing – glass substrate transfer, LCD/OLED panel alignment stages
- PCB assembly & SMT equipment – pick-and-place axis drives, gantry positioning, and feeder indexing
- Laboratory automation & life science instruments – liquid handling robots, slide scanners, and multi-axis sample stages
- General industrial motion control – CNC auxiliary axes, conveyor indexing, and precision dispensing systems
Technical Specifications
- Model: RD-023MS
- Manufacturer: Rorze Corporation (Japan)
- Series: RD Series – High-Resolution Stepping Motor Drive
- Drive Type: Microstepping / High-Resolution Stepping
- Compatible Motors: Rorze 2-phase and 5-phase stepping motors (series-matched)
- Control Interface: Pulse/Direction (P&D) signal input; compatible with standard PLC and motion controller outputs
- Resolution: High-resolution microstepping for smooth, low-vibration motion
- Protection: Over-current, over-temperature, and motor disconnection protection
- Weight: Approx. 500 g
- Origin: Japan
Note: Full electrical specifications (supply voltage, current rating, I/O levels) are available upon request. Contact our technical team for the official datasheet.
Why Engineers Specify This Model
- OEM-matched performance – Designed by Rorze to pair with their own robot and stage platforms, eliminating tuning guesswork
- High micro-step resolution – Reduces vibration and audible noise versus standard full/half-step drives, critical in cleanroom environments
- Compact DIN-rail or panel-mount form factor – Fits inside standard control cabinets without custom brackets
- Proven reliability in semiconductor fabs – Rorze drives are deployed in Tier-1 fabs across Japan, Korea, Taiwan, and China
- Drop-in replacement compatibility – Maintains original wiring harness pinout for fast MRO swap-outs with minimal downtime
Complete System Bill of Materials
For a fully functional Rorze stepping axis, engineers typically specify the following alongside the RD-023MS:
- Rorze 2-phase or 5-phase stepping motor (RM series)
- Rorze robot controller or compatible 3rd-party motion controller (pulse/direction output)
- 24 VDC or 48 VDC regulated power supply (per drive spec)
- Motor cable assembly (Rorze OEM harness or equivalent shielded cable)
- Encoder feedback module (optional, for closed-loop stall detection)
- DIN rail mounting hardware and terminal blocks
Contact support@konmask.com for BOM assistance and compatible part sourcing.
Compliance & Industry Standards
- Manufactured under Rorze Corporation’s ISO 9001-certified quality management system
- Designed for compatibility with SEMI E1.9 / SEMI E84 equipment interface standards (semiconductor automation)
- RoHS-compliant materials (confirm specific lot with documentation request)
- CE marking applicability – consult Rorze official declaration of conformity for your region
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for semiconductor, electronics, and process manufacturing industries. Every unit of the RD-023MS we supply is:
- Sourced from verified supply channels with full traceability
- Inspected for physical integrity and label authenticity prior to dispatch
- Shipped with original manufacturer packaging where available
- Supported by our technical team for installation and compatibility queries
How to Source This Part
- Add to cart and proceed to checkout for in-stock units
- Request a quote for volume orders (>5 units) or long-term supply agreements
- Contact us at support@konmask.com or +0086 19859288691 for urgent MRO requirements, datasheet requests, or cross-reference verification
- Lead time: Typically 3–15 business days depending on stock availability; expedited options available
Application-Specific FAQ
Q: Is the RD-023MS compatible with non-Rorze motion controllers?
A: Yes. The drive accepts standard pulse/direction (P&D) signals, making it compatible with most industrial PLCs and motion controllers that output 5 V or 24 V differential or single-ended step pulses. Confirm signal levels with our team before installation.
Q: Can this drive replace an older Rorze stepping drive model?
A: In many cases, yes. The RD series maintains backward-compatible connector pinouts across generations. Provide your existing model number to our team for a formal cross-reference check.
Q: Is this unit suitable for cleanroom (ISO Class 1–5) environments?
A: The drive itself is typically mounted in the equipment’s control cabinet outside the cleanroom envelope. The paired Rorze motor may be rated for cleanroom use – consult the motor datasheet for outgassing and particle specifications.
Q: Do you provide a warranty?
A: We offer a 90-day functional warranty on all units. Extended warranty and service contracts are available for volume customers.
Q: Can I get an official Rorze datasheet or test report?
A: Yes. Contact support@konmask.com with your order reference and we will provide available documentation.
