PLC Power Distribution Solution — SCHNEIDER 140CPS12420C | Quantum Series
Where This Product Is Used
The SCHNEIDER 140CPS12420C is a dedicated power supply module engineered for the Modicon Quantum PLC platform. It is deployed across a wide range of mission-critical industrial environments where stable, uninterrupted DC power delivery to the backplane is non-negotiable:
- Oil & Gas Processing Plants — Powers Quantum racks controlling compressor stations, pipeline SCADA, and emergency shutdown systems (ESD).
- Automotive Manufacturing Lines — Supplies backplane power to Quantum PLCs managing robotic welding cells, conveyor sequencing, and press control.
- Water & Wastewater Treatment — Installed in pump station control panels and SCADA-linked Quantum racks for continuous 24/7 operation.
- Power Generation & Utilities — Used in substation automation and turbine control systems requiring high-reliability DC power.
- Pharmaceutical & Food Processing — Supports GMP-compliant Quantum PLC racks in cleanroom and process control environments.
- Building Automation & Infrastructure — Integrated into large-scale BMS and HVAC control panels using the Quantum architecture.
Technical Specifications
| Part Number | 140CPS12420C |
| Brand | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Type | Power Supply Module |
| Input Voltage | 24 VDC |
| Output Power | Backplane power for Quantum rack |
| Redundancy Support | Yes — supports parallel redundant power configuration |
| Mounting | Quantum backplane slot (dedicated PSU slot) |
| Form Factor | Single-slot module |
| Weight | 600 g (approx.) |
| Operating Temperature | 0°C to 60°C |
| Certifications | CE, UL, cUL |
| Compatibility | Modicon Quantum backplane racks (140 XBP series) |
Why Engineers Specify This Model
- Redundancy-Ready Architecture — Two 140CPS12420C modules can be installed in parallel on a single Quantum rack, providing N+1 power redundancy without additional hardware.
- 24 VDC Input Compatibility — Directly accepts 24 VDC from standard industrial power rails, eliminating the need for intermediate AC/DC conversion in DC-powered panels.
- Proven Quantum Platform Integration — Designed exclusively for the Modicon Quantum backplane, ensuring zero compatibility risk and full firmware alignment.
- Hot-Swap Capable — Supports replacement under power in redundant configurations, enabling maintenance without system shutdown.
- Long Field Life — Schneider Electric’s Quantum series is a mature, globally supported platform with a decades-long installed base and available spare parts.
- Compact Single-Slot Footprint — Occupies only one backplane slot, preserving rack space for I/O and communication modules.
Complete System Bill of Materials
A typical Modicon Quantum control system using the 140CPS12420C includes the following components:
- 140CPS12420C — Power Supply Module (this item)
- 140CPU65160 — Quantum CPU Module (example: Unity Pro compatible)
- 140XBP01600 — 16-slot Quantum Backplane Rack
- 140DAI54000 — Discrete Input Module (24 VDC, 32-channel)
- 140DAO84000 — Discrete Output Module (24 VDC, 32-channel)
- 140ACI04000 — Analog Input Module (4-channel, 4–20 mA)
- 140NOE77101 — Ethernet TCP/IP Communication Module
- 140CPS12420C — Second PSU (for N+1 redundancy)
Contact Konmask for bundle pricing on complete Quantum rack assemblies.
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive and EMC Directive.
- UL / cUL Listed — Recognized for use in North American industrial control panels per UL 508A.
- IEC 61131-2 — Programmable controller hardware standard compliance.
- RoHS Compliant — Restriction of Hazardous Substances per EU Directive 2011/65/EU.
- ATEX / IECEx — Consult Konmask for hazardous area installation guidance and zone-rated enclosure pairing.
Quality Assurance & Sourcing
Konmask sources the 140CPS12420C through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition.
- Verification of part number, revision level, and firmware version against Schneider Electric documentation.
- Functional power-on test where applicable.
- Anti-static packaging with humidity indicator card for long-haul shipping.
We supply both new-in-box (NIB) and tested surplus units. Condition is clearly stated at time of quotation. All surplus units carry a 90-day operational warranty.
How to Source This Part
- Add to Cart — Place your order directly on this page for in-stock units.
- Request a Quote — For volume orders (5+ units), OEM projects, or urgent requirements, email support@konmask.com for priority pricing.
- Specify Condition — Indicate whether you require new-in-box or tested surplus when contacting us.
- Lead Time — In-stock units ship within 1–2 business days. Out-of-stock items: typical lead time 3–10 business days depending on sourcing region.
- Global Shipping — We ship worldwide via DHL, FedEx, and UPS with full export documentation and commercial invoice support.
Application-Specific FAQ
Q: Can I use two 140CPS12420C modules in the same rack for redundancy?
A: Yes. The Quantum backplane supports dual PSU slots. Installing two 140CPS12420C modules provides N+1 redundancy — if one fails, the other maintains full backplane power without interruption.
Q: Is the 140CPS12420C compatible with all Quantum backplane sizes?
A: It is compatible with the 140 XBP series backplanes (6, 10, and 16 slot). Always verify the specific rack model against Schneider Electric’s compatibility matrix before ordering.
Q: What is the difference between 140CPS12420 and 140CPS12420C?
A: The “C” suffix denotes a conformal-coated PCB version, offering enhanced protection against humidity, dust, and corrosive atmospheres — recommended for harsh industrial environments.
Q: Can this module be replaced while the system is running?
A: In a redundant dual-PSU configuration, yes — the failed module can be swapped without powering down the rack. In a single-PSU configuration, the rack must be de-energized before replacement.
Q: Do you provide documentation or datasheet with the order?
A: Yes. A copy of the Schneider Electric product datasheet and installation guide is available upon request. Contact support@konmask.com.
