SCHNEIDER 140CPU11303 – Modicon Quantum Central Processing Unit | Modicon Quantum Platform
Engineering Background
The Modicon Quantum series represents Schneider Electric’s flagship programmable automation controller platform, engineered for mission-critical process control, discrete manufacturing, and hybrid industrial environments. The 140CPU11303 is a mid-range CPU module within this architecture, delivering deterministic scan-cycle performance and robust I/O expansion capability across the Quantum backplane ecosystem.
Product Positioning
Designed for procurement engineers sourcing verified replacement or expansion hardware, the 140CPU11303 occupies the performance tier between entry-level Quantum CPUs and high-availability redundant processors. It is the preferred choice for facilities requiring reliable ladder logic / function block execution with moderate memory footprint and standard communication interfaces — without the overhead of a hot-standby redundancy license.
Complete Technical Specifications
| Part Number | 140CPU11303 |
| Manufacturer | Schneider Electric (Modicon) |
| Series / Platform | Modicon Quantum |
| Module Type | Central Processing Unit (CPU) |
| User Memory | 512 KB (application RAM) |
| Executive Memory | Flash EEPROM (non-volatile) |
| Max I/O Points | Up to 31 local / remote I/O drops |
| Communication Ports | Modbus Plus (MB+) × 2, RS-232 Modbus × 1 |
| Programming Software | Concept, ProWORX, Unity Pro (legacy compatibility) |
| Backplane Compatibility | Modicon Quantum 140 series backplanes (6, 10, 16 slot) |
| Power Supply Requirement | Supplied via Quantum backplane (140CPS series PSU) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % (non-condensing) |
| Vibration Resistance | IEC 68-2-6 compliant |
| EMC Compliance | CE, UL, CSA |
| Weight | 400 g (approx.) |
| Form Factor | Single-slot Quantum module |
Proven Application Environments
- Oil & Gas: Pipeline SCADA, compressor station control, wellhead automation
- Water & Wastewater: Pump station sequencing, treatment plant process control
- Power Generation: Auxiliary system control, switchgear interlocking
- Discrete Manufacturing: Assembly line PLC control, conveyor sequencing
- Chemical Processing: Batch control, reactor sequencing with Modbus Plus network integration
- Building Automation: HVAC plant room control, BMS integration via Modbus RTU
Engineering Advantages
- Deterministic Scan Cycle: Fixed-time task execution ensures predictable response in time-sensitive control loops.
- Dual Modbus Plus Ports: Enables peer-to-peer network topology without additional communication modules, reducing BOM cost.
- Non-Volatile Flash Storage: Application program retained through power loss without battery dependency on executive firmware.
- Broad Backplane Compatibility: Slots into any standard Quantum 140-series rack — simplifies spares management across multi-rack installations.
- Mature Ecosystem: Extensive third-party I/O, communication, and specialty module support within the Quantum platform.
- Long Field Service History: Widely documented, with large installed base supporting long-term parts availability and engineering knowledge.
System Architecture & Signal Flow
The 140CPU11303 resides in Slot 1 of the Quantum backplane. It communicates with local I/O modules via the backplane bus and with remote I/O drops via the Modbus Plus network (coaxial or fiber). The RS-232 port provides direct HMI or programming terminal connectivity. A typical architecture consists of:
- 140CPS series power supply → Quantum backplane → 140CPU11303 CPU
- Local I/O modules (140DAI, 140DDO, 140ACI, 140ACO series) on the same rack
- Remote I/O drops via 140NOM series Modbus Plus network option modules
- SCADA / HMI connectivity via Modbus RTU (RS-232) or Modbus Plus peer link
Sourcing & Quality Verification
- Origin: Sourced from verified industrial distributors and decommissioned OEM installations with documented service history.
- Inspection: Each unit undergoes visual inspection for physical integrity, connector condition, and label authenticity prior to listing.
- Firmware: Executive firmware version confirmed and documented on request.
- Packaging: Anti-static bag + foam-lined carton; ESD-safe handling throughout fulfillment.
- Warranty: 90-day functional warranty against DOA; extended warranty available on request.
Procurement Process
- Confirm Part Number: Verify 140CPU11303 against your existing rack label or engineering BOM.
- Request Datasheet / Firmware Version: Contact us at support@konmask.com for documentation.
- Place Order: Add to cart or submit a purchase order via email for net-terms arrangements.
- Shipping: DHL / FedEx international express available; lead time typically 1–3 business days from stock.
- Incoming Inspection: We recommend bench-testing in a spare rack slot before installation in a live system.
Technical FAQ
Q: Is the 140CPU11303 compatible with Unity Pro software?
A: Unity Pro supports legacy Quantum CPUs in a compatibility mode. Full native support requires Concept or ProWORX. Confirm your software version before migration.
Q: Can this CPU support hot-standby redundancy?
A: No. The 140CPU11303 is a standard (non-redundant) CPU. For hot-standby configurations, the 140CPU67160 or 140CPU67261 series is required.
Q: What is the maximum remote I/O drop count?
A: Up to 31 remote I/O drops via Modbus Plus, depending on network topology and cable length constraints.
Q: Is a battery required for program retention?
A: The executive firmware is stored in Flash EEPROM (non-volatile). A battery (140CPU11303 uses an internal lithium cell) maintains the real-time clock and RAM data during power-off. Battery replacement is a standard maintenance item.
Q: Can I mix this CPU with newer Quantum I/O modules?
A: Yes. The Quantum backplane bus is backward-compatible across the 140-series I/O module range. Verify firmware compatibility for specialty modules.
