The Schneider Electric Modicon 140DDI36400 is a 32-point, 24 VDC DC digital input module engineered for the Modicon Quantum PLC platform. Designed for mission-critical industrial environments, this module delivers reliable discrete signal acquisition across process control, manufacturing, and infrastructure applications.
Where This Product Is Used
The 140DDI36400 is deployed across demanding industrial sectors where deterministic digital input scanning and high channel density are non-negotiable:
- Automotive Assembly Lines — Monitoring conveyor position sensors, end-of-travel switches, and safety interlocks across multi-zone production cells.
- Oil & Gas Processing Plants — Acquiring discrete signals from valve position feedback, pressure switches, and emergency shutdown (ESD) circuits.
- Water & Wastewater Treatment — Reading pump run/fault status, level float switches, and flow confirmation signals in SCADA-integrated systems.
- Power Generation & Utilities — Interfacing with breaker status, relay feedback, and protection relay trip signals in substation automation.
- Food & Beverage Processing — Capturing machine-ready, door-open, and product-present signals in hygienic, high-cycle-rate environments.
- Pharmaceutical Manufacturing — Supporting validated batch control systems requiring traceable, high-integrity digital input acquisition.
- Building Automation & HVAC — Integrating with damper position, fan status, and fire/smoke detector discrete outputs.
Technical Specifications
- Part Number / SKU: 140DDI36400
- Brand: Schneider Electric (Modicon)
- Series: Modicon Quantum
- Module Type: DC Digital Input
- Number of Input Points: 32 points
- Input Voltage: 24 VDC
- Input Current (per point): Approx. 7.5 mA @ 24 VDC
- Logic Level 1 (ON): 11–30 VDC
- Logic Level 0 (OFF): 0–5 VDC
- Isolation: Optical isolation between field and backplane
- Backplane Current Consumption: 800 mA @ 5 VDC
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Storage Temperature: -40°C to +85°C
- Relative Humidity: 5%–95% non-condensing
- Connector Type: 40-pin front connector (field wiring)
- Backplane Compatibility: Modicon Quantum 140XBP series backplanes
- Weight: Approx. 200 g
Why Engineers Specify This Model
- High Channel Density: 32 inputs in a single slot minimizes rack space and reduces cost per point versus lower-density alternatives.
- Optical Isolation: Protects the PLC backplane from field-side voltage transients, ground loops, and noise — critical in electrically noisy environments.
- Proven Quantum Platform: Decades of installed base in process industries ensures long-term spare parts availability and engineering familiarity.
- Fast Input Scan: Compatible with Quantum CPU scan cycles for responsive machine control.
- Wide Operating Range: Accepts 24 VDC field signals with generous ON/OFF thresholds, accommodating real-world wiring voltage drops.
- Hot-Swap Capable: Supports module replacement without full system shutdown on compatible Quantum configurations.
Complete System Bill of Materials
For a complete Modicon Quantum digital input subsystem alongside the 140DDI36400:
- Quantum CPU: 140CPU65150 / 140CPU67160 — System processor
- Quantum Backplane: 140XBP01600 (16-slot) / 140XBP00600 (6-slot)
- Power Supply: 140CPS11420 — 24 VDC backplane power supply
- Field Wiring Adapter: 140XTS00200 — Terminal block for 40-pin connector
- Communication Module: 140NOE77101 — Ethernet TCP/IP (SCADA integration)
- Programming Software: EcoStruxure Control Expert (Unity Pro successor)
Compliance & Industry Standards
- CE Marking: EU Low Voltage and EMC Directives
- UL Listed: UL 508 — Industrial Control Equipment
- IEC 61131-2: Programmable controllers — Equipment requirements and tests
- RoHS Compliant: Restriction of Hazardous Substances Directive
- EMC: Class A industrial electromagnetic environments per IEC 61000 series
Quality Assurance & Sourcing
At Konmask.com, every Schneider Electric Modicon module is sourced through verified industrial supply channels. Each unit undergoes:
- Visual inspection for physical damage, label integrity, and connector condition
- Part number and date code verification against manufacturer documentation
- Functional power-on check where applicable
- Anti-static packaging with humidity indicator cards for safe international shipping
We supply both new original and tested refurbished units — condition is clearly stated on each listing. All items ship with a 90-day replacement warranty.
How to Source This Part
- In Stock: Add to cart — most orders ship within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead time confirmation.
- Urgent Requirement: Email [email protected] or call +0086 19859288691 for expedited sourcing.
- System Integration Support: Our technical team assists with Quantum BOM verification and compatibility checks.
Application-Specific FAQ
Q: Is the 140DDI36400 compatible with all Modicon Quantum backplanes?
A: Yes, compatible with the full 140XBP series. Ensure your power supply budget accommodates 800 mA @ 5 VDC backplane draw.
Q: Can this module be used with EcoStruxure Control Expert?
A: Yes. The 140DDI36400 is fully supported in Unity Pro and EcoStruxure Control Expert under the Quantum I/O hardware catalog.
Q: What is the difference between 140DDI36400 and 140DDI35300?
A: The 140DDI36400 provides 32 input points; the 140DDI35300 offers 16 points. The 36400 is preferred where higher channel density is required.
Q: Is this module suitable for SIL-rated safety applications?
A: No. For SIL 2/3 applications, specify Schneider Electric’s Modicon Safety (Preventa range).
Q: Can I replace this module while the PLC is running (hot-swap)?
A: Hot-swap capability depends on CPU and system configuration. Consult the Quantum Hardware Reference Guide before live module replacement.
Q: Do you supply the matching field wiring terminal block?
A: Yes. The 140XTS00200 terminal block adapter is available separately — contact us to bundle with your order.
