Schneider Electric MC-4/11/10/400 HW: E0P603 SW:00.22.03 Multi-Axis Motion Controller – ELAU PAC DRIVE Series
When a multi-axis motion controller fails on a high-speed packaging or printing line, the entire production cell comes to a halt. Servo drives lose synchronization, cam profiles cannot execute, and every minute of downtime translates directly into lost output and missed delivery windows. The Schneider Electric MC-4/11/10/400 with hardware revision E0P603 and firmware SW:00.22.03 is the precision brain that keeps these coordinated motion sequences running flawlessly — and finding a verified replacement quickly is critical.
Within the ELAU PAC DRIVE ecosystem, the MC-4/11/10/400 occupies the mid-to-high tier of the PAC DRIVE M (Motion) controller family, designed to coordinate up to 4 servo axes with 11 digital inputs, 10 digital outputs, and a 400 V power supply interface. This specific hardware/firmware combination (HW: E0P603 / SW:00.22.03) represents a mature, field-proven revision widely deployed across European and Asian OEM packaging machinery, and remains one of the most sought-after replacement units in the global industrial automation aftermarket.
Technical Specifications
- Part Number / SKU: MC-4/11/10/400
- Hardware Revision: HW: E0P603
- Firmware Version: SW:00.22.03
- Series: ELAU PAC DRIVE (PAC DRIVE M)
- Manufacturer: Schneider Electric (formerly ELAU AG)
- Controlled Axes: Up to 4 servo axes
- Digital Inputs: 11
- Digital Outputs: 10
- Supply Voltage: 400 V AC
- Weight: 3.54 kg
- Communication: CANopen / SERCOS (per system configuration)
- Programming Environment: PacDrive SoftMotion / IEC 61131-3
Key Features & Benefits
- Synchronized Multi-Axis Control: Coordinates up to 4 servo axes with precise electronic cam and gearing functions, essential for packaging, labeling, and converting machinery.
- Proven Hardware Revision E0P603: This specific board revision is known for stable thermal performance and long MTBF in continuous 24/7 industrial environments.
- IEC 61131-3 Compliant: Supports structured text, function block diagram, and ladder logic programming for flexible application development.
- Integrated I/O: 11 DI / 10 DO onboard reduces external wiring complexity and cabinet footprint.
- Drop-in Replacement Compatibility: Maintains full backward compatibility within the PAC DRIVE M platform, minimizing re-commissioning time.
- Firmware SW:00.22.03: A stable release supporting advanced motion functions including electronic cam, virtual master, and synchronization objects.
Industry & Equipment Applications
- Packaging Machinery: Flow wrappers, cartoners, case packers, and form-fill-seal machines requiring synchronized servo motion.
- Printing & Converting: Web tension control, register control, and cut-to-length applications.
- Food & Beverage Processing: High-speed filling, capping, and labeling lines.
- Pharmaceutical Manufacturing: Blister packaging and serialization lines with strict motion accuracy requirements.
- Textile & Nonwoven: Winding, unwinding, and cross-cutting applications.
System Integration & Compatible Parts
The MC-4/11/10/400 operates as the central controller within a PAC DRIVE M system. Compatible and commonly paired components include:
- ELAU / Schneider Electric SH Series Servo Motors (SH-070, SH-100, SH-140)
- ELAU SD Series Servo Drives (SD-316, SD-332, SD-364)
- ELAU PS Series Power Supplies (PS-4/xxx/400)
- CANopen I/O Expansion Modules for extended field I/O
- PacDrive SoftMotion Engineering Software (compatible versions for SW:00.22.03)
When replacing this controller, ensure the replacement unit carries the same or a compatible hardware revision (E0P603) and that firmware SW:00.22.03 is loaded or can be flashed prior to installation.
Our Quality Assurance Process
- Visual Inspection: All units are inspected for physical damage, corrosion, and component integrity upon receipt.
- Functional Verification: Where applicable, units are bench-tested to confirm power-on and communication readiness.
- Authentic Sourcing: We source from verified industrial channels — no counterfeit or refurbished-without-disclosure units.
- Secure Packaging: ESD-safe packaging with foam cushioning to prevent transit damage.
- Documentation: Hardware revision and firmware version confirmed and documented before shipment.
How to Order
- Submit an inquiry via the “Request a Quote” button on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange secure export packaging and international freight.
- Tracking information and commercial invoice provided upon shipment.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC, DCS, servo drives, and motion controllers from leading global brands.
- ✅ B2B Export Experience — Serving OEMs, system integrators, and MRO buyers across Europe, Southeast Asia, and the Middle East.
- ✅ Fast Inquiry Response — Dedicated team responds within 24 hours with accurate stock and pricing information.
- ✅ Transparent Part Identification — We clearly state hardware revision and firmware version so you order exactly what you need.
- ✅ Secure International Shipping — DHL, FedEx, and UPS express options with full export documentation.
Frequently Asked Questions
Q: Is the MC-4/11/10/400 with HW: E0P603 / SW:00.22.03 a new or refurbished unit?
A: We clearly disclose the condition of each unit in our quotation. Please specify your requirement (new, tested-used, or refurbished) when submitting your inquiry.
Q: Can I use a different hardware revision as a replacement?
A: Hardware revisions within the PAC DRIVE M MC-4 family are generally backward compatible, but we recommend confirming with your machine OEM or Schneider Electric technical support before substituting revisions.
Q: Do you provide the PacDrive SoftMotion software or firmware files?
A: We supply the hardware unit only. Firmware and engineering software are licensed by Schneider Electric and must be obtained through official channels.
Q: What is the typical lead time for this part?
A: Lead time varies by stock availability. Submit an inquiry and we will confirm within 1 business day.
Q: Do you ship to my country?
A: We ship internationally via DHL, FedEx, and UPS. Contact us with your destination for a freight estimate.
—
