PLC I/O Wiring Solution — SCHNEIDER 140XTS00200 | Quantum Series Terminal Strip
Where This Product Is Used
The SCHNEIDER 140XTS00200 Terminal Strip is a field-wiring interface component designed for use with Schneider Electric Modicon Quantum PLC I/O modules. It is deployed wherever reliable, organized, and maintainable field-device connections are required in industrial control panels.
Typical deployment environments include:
- Discrete Manufacturing: Assembly lines, robotic cells, and conveyor control panels where digital I/O modules interface with sensors, actuators, and safety devices.
- Process Industries: Oil & gas, chemical, and water treatment facilities using Quantum PLC racks for analog and digital field-device termination.
- Power Generation & Utilities: Substation automation and generator control systems requiring high-density, labeled terminal blocks.
- Building Automation & HVAC: Large-scale BMS panels integrating Quantum PLCs for HVAC, lighting, and access control.
- Material Handling & Logistics: Warehouse automation and sortation systems with extensive I/O wiring requirements.
- OEM Machine Builders: Panel builders standardizing on Quantum I/O architecture for repeatable, serviceable machine designs.
Technical Specifications
| Part Number | 140XTS00200 |
| Manufacturer | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Product Type | Terminal Strip / Field Wiring Interface |
| Compatible Modules | Quantum Series I/O Modules (140 series) |
| Mounting | Direct plug-in to Quantum I/O module connector |
| Terminal Count | 20-point (per standard 140XTS002xx naming) |
| Wire Gauge | Refer to Schneider Electric Quantum I/O wiring guide |
| Weight | 200 g (approx.) |
| Operating Temperature | 0°C to +60°C |
| Standards | CE, UL, cUL (per Quantum platform certification) |
Why Engineers Specify This Model
- Direct Plug-In Design: Eliminates intermediate terminal blocks — field wires connect directly to the I/O module via the terminal strip, reducing panel footprint and wiring errors.
- Modular Serviceability: The terminal strip can be disconnected from the I/O module without disturbing field wiring, enabling hot-swap module replacement during maintenance windows.
- Labeling Compatibility: Accepts standard Schneider label inserts for clear, permanent circuit identification — critical for compliance and troubleshooting.
- Platform Standardization: Part of the Modicon Quantum ecosystem, ensuring long-term spare parts availability and cross-site interchangeability.
- Reduced Commissioning Time: Pre-wired terminal strips can be prepared off-line and plugged in during final panel assembly, compressing project schedules.
Complete System Bill of Materials
The 140XTS00200 is typically specified alongside the following Quantum platform components:
- Quantum I/O Modules (e.g., 140DDI35300, 140DDO35300, 140ACI04000)
- Quantum CPU Modules (e.g., 140CPU65150, 140CPU67160)
- Quantum Power Supply Modules (e.g., 140CPS11420, 140CPS21400)
- Quantum Backplane / Rack (e.g., 140XBP01600, 140XBP01000)
- Quantum Remote I/O Head (e.g., 140CRA93100) for distributed architectures
- Cable Duct, DIN Rail, and Panel Enclosures per IEC 61439
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive as part of the Quantum platform.
- UL / cUL Listed: Recognized under UL 508 (Industrial Control Equipment) as part of the Modicon Quantum system.
- IEC 61131-2: Programmable controllers — hardware requirements (platform-level compliance).
- RoHS Compliant: Restriction of Hazardous Substances per EU Directive 2011/65/EU.
- ATEX / IECEx: Consult Schneider Electric for zone-rated installation requirements in hazardous areas.
Quality Assurance & Sourcing
Konmask.com sources the 140XTS00200 through verified industrial distribution channels. Every unit is subject to the following quality controls:
- Visual inspection for physical damage, label integrity, and connector condition.
- Verification of part number markings against Schneider Electric product documentation.
- Packaging inspection to confirm OEM or equivalent protective packaging.
- Traceability documentation available upon request for regulated industries.
We do not source from unauthorized secondary markets. All stock is traceable to authorized distribution or OEM surplus channels.
How to Source This Part
- In Stock: Add to cart and proceed to checkout. Orders confirmed before 3:00 PM CST typically ship same business day.
- Bulk / Project Quantities: Email support@konmask.com with your project BOM for volume pricing and lead-time confirmation.
- Urgent / Emergency: Call +0086 19859288691 for expedited sourcing and same-day quotation.
- Cross-Reference Needed: Provide your existing part number or module type — our team will confirm compatibility before shipment.
Application-Specific FAQ
Q: Is the 140XTS00200 compatible with all Quantum I/O modules?
A: The 140XTS002xx series is designed for specific Quantum I/O module connector types. Confirm your module’s connector specification against the Schneider Electric Quantum Hardware Reference Guide (840USE10000) before ordering.
Q: Can I replace the terminal strip without powering down the PLC rack?
A: The terminal strip is designed to be disconnected from the I/O module while field wiring remains intact. However, always follow your site’s lockout/tagout (LOTO) procedures and consult the module’s datasheet for hot-swap capability.
Q: Are label inserts included?
A: Label inserts are typically ordered separately. Contact us to confirm availability of matching Schneider label accessories for the 140XTS00200.
Q: What is the lead time if out of stock?
A: Standard lead time for sourced stock is 3–7 business days. Emergency sourcing for critical plant shutdowns is available — contact us directly.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. CoC documentation is available upon request for quality-critical or regulated applications.
