Industrial HMI Solution — Schneider Electric XBTGT7340 | Magelis XBTGT Series
The Schneider Electric XBTGT7340 is a high-performance Magelis XBTGT series Human-Machine Interface (HMI) panel engineered for demanding industrial automation environments. With a 12.1″ TFT color touch screen, multi-protocol communication, and robust construction, this panel bridges the gap between operator control and machine intelligence across a wide range of process and discrete manufacturing applications.
Where This Product Is Used
The XBTGT7340 is specified by automation engineers and system integrators across the following industries and applications:
- Water & Wastewater Treatment — SCADA visualization for pump stations, filtration systems, and dosing control
- Food & Beverage Processing — Recipe management, batch control, and CIP (Clean-In-Place) sequence monitoring
- Pharmaceutical Manufacturing — GMP-compliant process visualization, alarm logging, and audit trail display
- Oil & Gas / Petrochemical — Pipeline monitoring, compressor control panels, and wellhead automation
- Building Automation & HVAC — Chiller plant control, AHU management, and energy monitoring dashboards
- Automotive Assembly Lines — Conveyor control, torque tool management, and production line status display
- Power Distribution & Utilities — Substation HMI, generator control panels, and UPS monitoring
- Packaging Machinery — Filling, sealing, and labeling machine operator interfaces
Technical Specifications
| Part Number | XBTGT7340 |
| Manufacturer | Schneider Electric (Magelis) |
| Series | XBTGT |
| Display Size | 12.1″ TFT Color LCD |
| Resolution | 800 × 600 (SVGA) |
| Touch Technology | Analog Resistive Touch Screen |
| Processor | 32-bit RISC, 400 MHz |
| Memory | 64 MB RAM / 128 MB Flash |
| Operating System | Windows CE 6.0 |
| Communication Ports | Ethernet 10/100 Mbps, 2× Serial (RS-232/RS-485), USB Host & Device, CANopen |
| Supported Protocols | Modbus TCP/IP, Modbus RTU, CANopen, Uni-Telway, EtherNet/IP (via gateway) |
| Power Supply | 24 VDC (18–32 VDC range) |
| Power Consumption | ≤ 30 W |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +70 °C |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cut-out, landscape orientation |
| Dimensions (W×H×D) | Approx. 340 × 270 × 60 mm |
| Weight | 5.6 kg |
| Programming Software | Vijeo Designer (v6.x and above) |
| Certifications | CE, UL, cUL, RoHS |
Why Engineers Specify This Model
- Large 12.1″ Display — Provides ample screen real estate for complex mimic diagrams, trend graphs, and multi-zone alarm displays without operator eye strain
- Multi-Protocol Native Support — Communicates natively with Modbus RTU/TCP, CANopen, and Uni-Telway devices without additional gateways in most topologies
- Vijeo Designer Ecosystem — Drag-and-drop symbol libraries, built-in alarm management, data logging, and recipe management reduce engineering hours significantly
- IP65 Front Panel — Suitable for wash-down environments and dusty factory floors without additional enclosure protection
- Proven Reliability — Magelis XBTGT series has a decade-long installed base in global process industries, ensuring long-term spare parts availability
- Windows CE Platform — Familiar runtime environment with stable, deterministic HMI performance and broad third-party driver support
Complete System Bill of Materials
For a complete XBTGT7340-based control station, engineers typically specify the following complementary components:
- XBTGT7340 — HMI Panel (this unit)
- Schneider TM5 / Modicon M340 PLC — Logic controller communicating via Modbus TCP or Uni-Telway
- TSXCUSB485 — USB to RS-485 converter for Vijeo Designer programming cable
- VW3A8306D — CANopen communication cable (if CANopen topology used)
- ABL8REM24030 — 24 VDC / 3 A regulated power supply for HMI panel
- XBTZG935 — Replacement touch screen overlay / protective film
- Vijeo Designer v6.2+ — Engineering software license (PC-based)
- Stainless steel panel enclosure — IP66 rated, sized for 12.1″ cut-out (customer-specified)
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive (LVD) and EMC Directive
- UL / cUL Listed — Recognized for use in North American industrial installations
- RoHS Compliant — Restriction of Hazardous Substances Directive (EU 2011/65/EU)
- IEC 61131-2 — Programmable controller equipment standard compatibility
- ATEX / IECEx — Not rated for Zone 0/1 hazardous areas; use appropriate barrier or purge enclosure for Ex applications
- IP65 (IEC 60529) — Front panel dust-tight and protected against water jets
Quality Assurance & Sourcing
At Konmask.com, every XBTGT7340 unit is subject to the following quality process before dispatch:
- ✅ Visual Inspection — Housing, connectors, and display surface checked for physical damage
- ✅ Power-On Verification — Unit powered at 24 VDC; display, touch response, and boot sequence confirmed
- ✅ Communication Port Test — Ethernet, serial, and USB ports verified functional
- ✅ Firmware Version Check — Runtime version documented and provided with shipment
- ✅ Authenticity Verification — Units sourced from authorized distributors or verified surplus channels; counterfeit screening applied
- ✅ Packaging — Anti-static bag, foam-lined carton, and moisture desiccant for safe international transit
All units ship with a 90-day Konmask warranty covering defects in materials and workmanship.
How to Source This Part
- Request a Quote — Contact us at [email protected] or via the product page inquiry form with your required quantity and delivery timeline
- Lead Time Confirmation — We confirm stock availability and estimated ship date within 1 business day
- Order Placement — Purchase via the Konmask.com storefront (credit card, T/T wire transfer, or PayPal accepted)
- Export Documentation — Commercial invoice, packing list, and certificate of origin provided for international shipments
- Shipping — DHL Express, FedEx International Priority, or sea freight (LCL/FCL) based on order volume and urgency
- After-Sales Support — Technical assistance available for installation, Vijeo Designer configuration, and communication setup
Application-Specific FAQ
Q: Can the XBTGT7340 communicate directly with a Siemens S7 PLC?
A: Not natively. Vijeo Designer supports Modbus and Schneider-native protocols. For Siemens S7 communication, a Modbus TCP gateway (e.g., Anybus X-gateway) or a third-party Vijeo Designer driver is required.
Q: Is this panel suitable for outdoor installation?
A: The front panel is IP65 rated, but the operating temperature range (0–50 °C) and lack of sunlight-readable display make direct outdoor installation inadvisable without a climate-controlled, shaded enclosure.
Q: What version of Vijeo Designer is required to program this unit?
A: Vijeo Designer v6.0 or higher is required. v6.2 SP5 or later is recommended for full feature compatibility and security patches.
Q: Can this HMI log data to an external USB drive or network share?
A: Yes. The XBTGT7340 supports data logging to USB flash drives via the USB Host port and to network file shares via Ethernet, configurable within Vijeo Designer’s data logging module.
Q: Is the XBTGT7340 still in production by Schneider Electric?
A: The XBTGT series has reached end-of-active-production. Schneider Electric recommends the Magelis HMIGTU series as the successor. Konmask.com maintains stock of XBTGT7340 units to support existing installed base maintenance and spare parts requirements.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more — contact us for a tiered quote.
