SCHNEIDER 170INT11003 Interbus-S Network Interface Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 170INT11003 is a Modicon Quantum series Interbus-S network interface module designed for high-speed, deterministic fieldbus communication in industrial automation systems. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: 170INT11003
- Brand / Manufacturer: Schneider Electric (Modicon)
- Series: Modicon Quantum
- Module Type: Interbus-S Network Interface Module (NIM)
- Fieldbus Protocol: Interbus-S (IBS)
- Backplane Interface: Modicon Quantum I/O backplane
- Communication Speed: Up to 500 kbps (Interbus-S standard)
- Max. Devices Supported: Up to 512 I/O devices per ring segment
- Connector Type: DB9 / Phoenix-style Interbus-S ring connector
- Power Supply: Supplied via Quantum backplane (5 VDC)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: -40 °C to +85 °C
- Relative Humidity: 5% to 95% non-condensing
- Weight: Approx. 910 g (with housing)
- Certifications: CE, UL, cUL
- Firmware: Configurable via Unity Pro / Concept software
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents for the 170INT11003. Always verify firmware compatibility and I/O mapping before substitution.
- 170INT11003 — Original Schneider Electric Modicon Quantum Interbus-S NIM (this product)
- 170INT11000 — Earlier revision of the same Interbus-S NIM; functionally equivalent, check firmware version
- 170INT11001 — Intermediate revision; pin-compatible, verify configuration file compatibility
- PHOENIX CONTACT IBS SYS ME DSC/I-T — Third-party Interbus-S master controller; requires gateway or re-engineering
- Hilscher CIFX 50-IBS — PC-based Interbus-S master card; suitable for migration to PC-based control architectures
- Schneider 140NOE77100 + IBS Gateway — Ethernet-based alternative with Interbus-S gateway for modernization projects
Note: Third-party replacements may require additional configuration, gateway hardware, or software re-mapping. Contact Konmask for pre-sales compatibility assessment.
Why Choose the Original Model
- Plug-and-play compatibility with existing Modicon Quantum racks — no re-engineering required
- Validated firmware tested with Unity Pro and Concept PLC programming environments
- Deterministic Interbus-S communication ensures cycle-accurate I/O synchronization
- Long-term spare parts availability through authorized and secondary market channels
- Reduced commissioning risk — drop-in replacement for existing 170INT1100x installations
- OEM-grade quality with full CE/UL certification for regulated industries
Typical Applications
- Automotive assembly lines with Interbus-S distributed I/O networks
- Packaging machinery requiring high-speed, synchronized fieldbus communication
- Material handling systems (conveyors, sorters, palletizers)
- Process automation in chemical and pharmaceutical plants
- Machine tool control with distributed sensor/actuator networks
- Spare part replacement in legacy Modicon Quantum PLC installations
System Compatibility
- PLC Platform: Modicon Quantum (140-series CPU modules)
- Supported CPUs: 140CPU31110, 140CPU43412A, 140CPU65150, 140CPU65160, and other Quantum CPUs
- Programming Software: Schneider Unity Pro (v2.0+), Concept (v2.6+)
- Rack Compatibility: All standard Modicon Quantum I/O racks (140XBP series)
- Interbus-S Ring: Compatible with all IEC 61158 Type 8 (Interbus) compliant slave devices
- Not compatible with: Modicon Premium, M340, M580, or Momentum platforms without additional gateway hardware
Selection Guide
Use the following criteria to determine whether the 170INT11003 is the right module for your application:
- Existing Quantum rack? → 170INT11003 is a direct fit. No additional hardware needed.
- Need Interbus-S master on a non-Quantum platform? → Consider Hilscher CIFX or Phoenix Contact IBS master cards with appropriate gateway.
- Migrating to Ethernet/IP or Modbus TCP? → Evaluate Schneider 140NOE77100 or M580 platform migration.
- Budget-constrained spare part sourcing? → Refurbished 170INT11003 or 170INT11001 from certified secondary market (e.g., Konmask) is a cost-effective option.
- Expanding I/O beyond 512 devices? → Consider segmenting into multiple Interbus-S rings or migrating to a higher-capacity fieldbus (PROFIBUS, EtherNet/IP).
- Regulatory / safety-critical environment? → Always use OEM-original or certified refurbished modules with full traceability documentation.
Quality Assurance & Sourcing
- All units sourced through verified industrial supply chains with full traceability
- Pre-shipment functional testing available on request
- Certificates of conformity and test reports provided upon request
- Packaging: anti-static ESD bag + foam-lined carton for safe international shipping
- Warranty: 12 months from date of shipment (defects in materials and workmanship)
- Returns accepted within 30 days for unused, unopened items in original packaging
How to Order
- Step 1: Confirm your Quantum CPU model and rack slot availability
- Step 2: Verify Interbus-S ring topology and device count
- Step 3: Add 170INT11003 to cart or contact us for bulk/project pricing
- Step 4: Provide your shipping address and preferred freight method (DHL / FedEx / sea freight)
- Step 5: Receive order confirmation, proforma invoice, and tracking number within 1 business day
For urgent requirements or project quantities (>5 units), email [email protected] for priority processing.
Replacement & Compatibility FAQ
Q: Is 170INT11003 a direct replacement for 170INT11001?
A: Yes, in most cases. Both are Interbus-S NIMs for the Quantum platform. Verify firmware version compatibility and re-download the configuration if upgrading.
Q: Can I use 170INT11003 on a Modicon M340 or M580 rack?
A: No. The 170INT11003 is designed exclusively for the Modicon Quantum backplane. M340/M580 use different module form factors and communication architectures.
Q: What software do I need to configure this module?
A: Schneider Unity Pro (v2.0 or later) or Concept (v2.6 or later). The module is configured as an Interbus-S master within the PLC project.
Q: Do you supply refurbished units?
A: Yes. Konmask supplies both new and certified refurbished 170INT11003 modules. All refurbished units undergo functional testing and are shipped with a 12-month warranty.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items typically have a 2–4 week lead time. Contact us for real-time stock status.
Q: Can you provide a datasheet or wiring diagram?
A: Yes. Email [email protected] with your part number and we will send the relevant documentation.
