Pump & Motor Control Solution — Schneider Electric ATS48C32Y | Altistart 48 Series
Where This Product Is Used
The Schneider Electric ATS48C32Y is a high-power soft starter engineered for demanding industrial motor control applications where direct-on-line starting causes mechanical stress, voltage dips, or excessive inrush current. Typical deployment environments include:
- Water & Wastewater Treatment Plants — controlled ramp-up of centrifugal pumps eliminates water hammer and pipe stress in municipal and industrial water systems.
- HVAC Systems — smooth starting of large air-handling unit fans and chiller compressors reduces peak demand charges and extends belt/bearing life.
- Mining & Quarrying — belt conveyor drives and crusher motors benefit from torque-controlled acceleration, reducing mechanical shock on gearboxes and couplings.
- Oil & Gas Facilities — pipeline booster pumps and gas compressors require controlled starts to protect seals and prevent pressure surges.
- Marine & Offshore — generator-limited power systems where inrush current must be strictly managed during motor starting sequences.
- Cement & Aggregate Processing — high-inertia loads such as ball mills and rotary kilns where extended ramp times are required.
- Food & Beverage Processing — hygienic pump and mixer drives where smooth torque delivery prevents product spillage and equipment damage.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | ATS48C32Y |
| Brand | Schneider Electric |
| Series | Altistart 48 (ATS48) |
| Rated Motor Power (400V) | 160 kW |
| Rated Current (In) | 320 A |
| Supply Voltage Range | 208 – 690 VAC, 3-phase, 50/60 Hz |
| Control Supply Voltage | 110 – 230 VAC (separate control circuit) |
| Starting Torque Range | 10% – 100% of nominal torque (adjustable) |
| Ramp Time (Start/Stop) | 1 – 60 seconds (adjustable) |
| Bypass Contactor | Internal bypass (line current = motor current at full speed) |
| Protection Class | IP00 (chassis mount); IP20 with optional cover |
| Thermal Protection | Electronic motor thermal protection (class 10/20/30) |
| Communication | Modbus RTU (optional); compatible with CANopen, Profibus DP via gateway |
| Certifications | CE, UL, CSA, IEC 60947-4-2 |
| Mounting | Panel / MCC cubicle (chassis) |
| Weight | Approx. 14 kg |
Why Engineers Specify This Model
- Internal Bypass Contactor — eliminates the need for an external bypass contactor, reducing panel space and wiring complexity. Once at full speed, the bypass engages and the SCRs carry zero current, minimizing heat dissipation.
- Torque Control Algorithm — unlike voltage-ramp-only starters, the ATS48 series uses a closed-loop torque control strategy, delivering consistent acceleration regardless of load variation — critical for pump and compressor applications.
- Soft Stop Function — programmable deceleration ramp prevents water hammer in pump systems without the cost of a variable frequency drive.
- Advanced Motor Protection — integrated phase loss, phase imbalance, overcurrent, undercurrent (dry-run), and thermal overload protection reduces the need for external relay modules.
- Wide Voltage Tolerance — 208–690 VAC range makes this unit globally deployable across North American (480V), European (400V), and Asian (660V) grid standards without hardware changes.
- Fieldbus Ready — native Modbus RTU port enables integration into SCADA, DCS, and PLC-based control architectures for remote monitoring and parameter adjustment.
Complete System Bill of Materials
For a complete motor soft-start panel using the ATS48C32Y, engineers typically specify the following complementary components:
- Main Circuit Breaker — Schneider Electric GV7 or NSX series, rated ≥320A with motor protection curve
- Input Line Contactor — LC1D series (optional, for remote isolation)
- Control Transformer — 230VAC control supply if main supply is 400V or 690V
- Surge Protection Device (SPD) — iPRD series for supply line protection
- Modbus Gateway — VW3A8306 (if CANopen or Profibus integration is required)
- Remote Keypad / Display — VW3G48101 for door-mounted parameter access
- Thermal Sensor Input Module — for PTC/PT100 motor winding temperature monitoring
- DIN Rail & Enclosure — IP54 or IP65 rated steel enclosure for outdoor or washdown environments
Compliance & Industry Standards
- IEC 60947-4-2 — AC semiconductor motor controllers and starters
- CE Marking — Low Voltage Directive (LVD) and EMC Directive compliant
- UL 508 — Industrial Control Equipment (UL Listed)
- CSA C22.2 No. 14 — Industrial Control Equipment (CSA Certified)
- RoHS Compliant — Restriction of Hazardous Substances
- REACH Compliant — EU chemical regulation compliance
Quality Assurance & Sourcing
Konmask.com sources the ATS48C32Y exclusively through verified industrial distribution channels. Every unit undergoes the following quality checks before dispatch:
- Visual inspection of housing, terminals, and label integrity
- Serial number verification against Schneider Electric’s authorized supply chain records
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card for long-term storage protection
- Original manufacturer documentation and warranty card included
We do not source from grey-market or unauthorized secondary channels. All products carry the original Schneider Electric manufacturer warranty.
How to Source This Part
To place an order or request a quotation for the Schneider Electric ATS48C32Y:
- Online: Add to cart directly on this page. Bulk pricing available for orders of 2+ units.
- Email RFQ: Send your BOM or purchase order to support@konmask.com for a formal quotation within 24 hours.
- Phone / WhatsApp: +0086 19859288691 — speak directly with our industrial automation specialists.
- Lead Time: In-stock units ship within 1–3 business days. Ex-stock or special-order units: 5–15 business days depending on origin warehouse.
- Export & Cross-Border: We support DDP, DAP, and EXW Incoterms. Export documentation (CO, packing list, commercial invoice) provided for all international shipments.
Application-Specific FAQ
Q: Can the ATS48C32Y be used with a bypass contactor for energy saving?
A: The ATS48C32Y has an internal bypass contactor built in. Once the motor reaches full speed, the internal bypass engages automatically — no external bypass contactor is required, saving panel space and cost.
Q: Is this soft starter suitable for high-inertia loads like centrifuges or ball mills?
A: Yes. The ATS48 series supports extended ramp times up to 60 seconds and can be configured for Class 20 or Class 30 thermal protection to accommodate high-inertia starting cycles.
Q: Can I control the ATS48C32Y via Modbus from a Schneider M340 or M580 PLC?
A: Yes. The unit has a built-in Modbus RTU port (RJ45). It is fully compatible with Schneider Electric Unity Pro / EcoStruxure Control Expert environments using standard Modbus function codes.
Q: What is the difference between ATS48C32Y and ATS48C32Q?
A: The suffix letter denotes the control supply voltage. The Y variant accepts 110–230 VAC control supply; the Q variant is designed for 380–415 VAC control supply. Ensure your control circuit voltage matches before ordering.
Q: Does this unit require derating in high-altitude or high-ambient-temperature installations?
A: Yes. Above 1000m altitude or 40°C ambient, current derating applies per Schneider Electric’s ATS48 installation guide. Contact our technical team for site-specific derating calculations.
Q: Can Konmask.com provide the ATS48C32Y with a test report or factory certificate?
A: Yes. Factory test certificates and CE declarations of conformity are available upon request. Contact support@konmask.com with your order reference.
