Industrial Ethernet Communication Solution – Schneider Electric BMXXBE1000 | Modicon M340
Where This Product Is Used
The Schneider Electric BMXXBE1000 is a dedicated Ethernet communication module engineered for the Modicon M340 PLC platform. It is deployed across a wide range of industrial automation environments where reliable, high-speed network connectivity is mission-critical:
- Automotive Manufacturing: Real-time data exchange between M340 PLCs and SCADA/MES systems on assembly lines, enabling traceability and OEE monitoring.
- Water & Wastewater Treatment: Remote monitoring and control of pump stations, filtration systems, and chemical dosing units via Modbus TCP over plant-wide Ethernet networks.
- Oil & Gas Upstream/Midstream: Integration of M340 controllers into DCS architectures for pipeline monitoring, compressor control, and LACT unit automation.
- Building Management Systems (BMS): Connecting M340 PLCs to BACnet/IP gateways and energy management platforms in commercial and industrial facilities.
- Food & Beverage Processing: Hygienic-area machine control with Ethernet-based recipe management and batch reporting to ERP systems.
- Power Distribution & Utilities: Substation automation and feeder protection coordination using IEC 61850-compatible Ethernet infrastructure.
- Pharmaceutical & Life Sciences: 21 CFR Part 11-compliant data logging and audit trail transmission from M340 controllers to validated historian servers.
Technical Specifications
| Part Number | BMXXBE1000 |
| Brand | Schneider Electric |
| Series | Modicon M340 |
| Module Type | Ethernet Communication Module |
| Network Interface | 10/100BASE-TX (RJ45) |
| Supported Protocols | Modbus TCP/IP, EtherNet/IP, FTP, HTTP, SNMP |
| Number of Ethernet Ports | 1 × RJ45 |
| Max. Simultaneous Connections | 64 (Modbus TCP server) |
| Backplane Bus | Modicon M340 X-Bus |
| Power Consumption | 3.3 W (from backplane) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 10% to 95% (non-condensing) |
| Protection Rating | IP20 |
| Weight | 140 g |
| Dimensions (H × W × D) | 100 × 30 × 73 mm |
| Certifications | CE, UL, cUL, RCM |
Why Engineers Specify This Model
- Dedicated Ethernet Slot: Offloads network processing from the CPU module, preserving scan-cycle performance even under heavy Modbus TCP polling loads.
- Dual-Protocol Support: Native Modbus TCP and EtherNet/IP on a single module eliminates the need for protocol converters in mixed-vendor environments.
- Web Server Built-In: Embedded HTTP server provides browser-based diagnostics and I/O visualization without additional software licenses.
- FTP File Transfer: Enables automated data logging and firmware update workflows directly over the plant network.
- SNMP Agent: Integrates with enterprise IT network management systems (NMS) for proactive fault detection and asset inventory.
- Hot-Swap Compatible: Supports module replacement without full rack power-down, minimizing unplanned downtime in 24/7 production environments.
- Unity Pro / EcoStruxure Machine Expert Compatible: Full configuration and diagnostics within Schneider’s standard engineering toolchain — no third-party software required.
Complete System Bill of Materials
A typical M340 Ethernet-networked control panel using the BMXXBE1000 includes:
- BMXXBE1000 — Ethernet Communication Module (this item)
- BMXP342020 / BMXP342030 — Modicon M340 CPU Module
- BMXXBP0400 / BMXXBP0800 — M340 Backplane (4-slot or 8-slot)
- BMXCPS2000 / BMXCPS3500 — M340 Power Supply Module
- BMXDDI1602 / BMXDDO1602 — Digital I/O Modules
- BMXAMI0410 / BMXAMO0210 — Analog I/O Modules
- TSXCSA100 / TSXCSA200 — Shielded Ethernet Cable (Cat5e/Cat6)
- Managed Industrial Ethernet Switch (e.g., Schneider ConneXium TCSESM083F23F0)
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL 508 — Industrial Control Equipment (UL & cUL listed)
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- IEEE 802.3 — Ethernet Standard (10BASE-T / 100BASE-TX)
- RFC 1213 / RFC 1157 — SNMP MIB-II compliance
- RCM (RoHS) — Australia/New Zealand market compliance
Quality Assurance & Sourcing
At Konmask.com, every BMXXBE1000 unit is subject to a rigorous incoming inspection protocol:
- ✅ Authenticity Verification: Serial number cross-referenced against Schneider Electric’s authorized distributor database.
- ✅ Functional Bench Test: Ethernet link negotiation, Modbus TCP connectivity, and LED status verification prior to dispatch.
- ✅ ESD-Safe Packaging: Shipped in anti-static bags with foam-lined cartons to prevent transit damage.
- ✅ Traceability Documentation: Certificate of conformity and test report available upon request.
- ✅ Warranty: 12-month replacement warranty against manufacturing defects.
How to Source This Part
- Add to Cart — Click the purchase button above for standard stock orders.
- Request a Quote — For volume orders (5+ units), OEM pricing, or project-based procurement, email [email protected].
- Expedited Sourcing — Need it urgently? Call/WhatsApp +0086 19859288691 for same-day shipping confirmation.
- Cross-Reference Check — Our engineers can verify compatibility with your existing M340 rack configuration before you order.
Application-Specific FAQ
Q: Can the BMXXBE1000 communicate with third-party SCADA systems like Ignition or WinCC?
A: Yes. Both Modbus TCP and EtherNet/IP are natively supported by Ignition, WinCC, iFIX, and most major SCADA platforms. No additional gateway hardware is required.
Q: How many Modbus TCP client connections can the module handle simultaneously?
A: The BMXXBE1000 supports up to 64 simultaneous Modbus TCP server connections, making it suitable for large polling architectures with multiple SCADA clients.
Q: Is this module compatible with the Modicon M340 Hot Standby (BMXCRA31210) configuration?
A: The BMXXBE1000 is used in standard M340 racks. For Hot Standby architectures, the BMXNOE0110 or BMXNOE0100 modules are typically specified. Contact our team to confirm your exact topology.
Q: Can I configure the IP address without Unity Pro software?
A: Yes. The module supports IP address assignment via DHCP, BOOTP, or the embedded web server — no engineering software is required for basic network commissioning.
Q: What is the difference between BMXXBE1000 and BMXNOE0110?
A: The BMXXBE1000 is an X-Bus Ethernet module with a single RJ45 port, optimized for cost-sensitive applications. The BMXNOE0110 offers dual Ethernet ports and advanced features such as RSTP and device-level ring (DLR) topology support for higher-availability networks.
