Distributed I/O Solution – Schneider Electric 140CRA21110 | Quantum Series
The Schneider Electric 140CRA21110 is a DIO (Drop Interface) module engineered for the Modicon Quantum distributed I/O architecture. It serves as the remote drop adapter that connects field-level I/O modules to the Quantum PLC backplane via the Modbus Plus or RIO (Remote I/O) network — enabling deterministic, high-availability control across large-scale industrial installations.
Where This Product Is Used
The 140CRA21110 is specified in applications where I/O must be distributed across large plant footprints while maintaining tight scan-cycle synchronization with the Quantum CPU:
- Oil & Gas Processing Plants — Remote drop adapters installed in field junction boxes, connecting pressure, temperature, and valve I/O back to the control room PLC over RIO cable.
- Water & Wastewater Treatment Facilities — Distributed pump station control where each lift station runs a local I/O drop, supervised by a central Quantum rack.
- Automotive Assembly Lines — Body-in-white and paint shop conveyors using Quantum RIO drops for zone-level I/O without running individual wires to a central panel.
- Power Generation & Utilities — Turbine auxiliary systems and switchgear control panels requiring IEC-compliant, deterministic I/O scanning.
- Mining & Minerals Processing — Crusher, conveyor, and flotation cell control in harsh environments where remote I/O reduces cable runs and improves fault isolation.
- Chemical & Pharmaceutical Manufacturing — Process skids requiring segregated I/O drops for safety-zone compliance and ease of validation.
Technical Specifications
| Part Number | 140CRA21110 |
| Manufacturer | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Type | DIO Drop Interface (Remote I/O Adapter) |
| Network Protocol | Modbus Plus / Quantum RIO |
| Drop Address Range | 1–31 (configurable via rotary switch) |
| Max I/O Modules per Drop | Up to 6 I/O modules per drop rack |
| Power Supply Voltage | 24 VDC (from backplane) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | 600 g |
| Mounting | Quantum backplane slot (leftmost position) |
| Dimensions | Standard Quantum single-slot form factor |
| Indicators | RUN, ERR, COM LEDs for rapid field diagnostics |
| SKU / Order Reference | 140CRA21110 |
Why Engineers Specify This Model
- Deterministic RIO Scanning — The Quantum RIO network delivers fixed, predictable scan times critical for motion-sensitive and safety-related applications.
- High Drop Count — Supports up to 31 remote drops per RIO head, enabling plant-wide I/O distribution from a single Quantum CPU.
- Plug-and-Play Replacement — Drop address is set via hardware rotary switch; no software reconfiguration required on module swap, minimizing MTTR.
- Proven Platform Longevity — The Modicon Quantum platform has decades of installed base in critical infrastructure, with long-term spare parts availability.
- Integrated Diagnostics — Onboard LED indicators and Unity Pro / Concept software diagnostics allow rapid fault isolation without test equipment.
- Robust Environmental Rating — Designed for industrial panel environments with wide temperature tolerance and vibration resistance per IEC standards.
Complete System Bill of Materials
A typical Quantum remote I/O drop using the 140CRA21110 requires the following components:
| Component | Schneider Electric Part No. | Description |
|---|---|---|
| Drop Interface Adapter | 140CRA21110 | This module — RIO drop adapter |
| Remote I/O Rack | 140XBP01600 / 140XBP00600 | Quantum backplane (16-slot or 6-slot) |
| Power Supply | 140CPS11420 / 140CPS21400 | Quantum rack power supply (24 VDC or 115/230 VAC) |
| RIO Cable | AS-MBKT-085 / Belden 9463 | Modbus Plus / RIO coaxial trunk cable |
| RIO Tap | AS-MBKT-085 series | T-tap connector for RIO trunk |
| Discrete Input Module | 140DAI54000 / 140DDI35300 | 16/32-ch 24 VDC discrete input |
| Discrete Output Module | 140DAO84000 / 140DDO35300 | 16/32-ch 24 VDC discrete output |
