Schneider Electric 171CCC78010 – Processor Adaptor Module | Modicon Quantum Platform
Engineering Background: The Modicon Quantum series represents Schneider Electric’s flagship high-performance PLC platform, engineered for mission-critical industrial automation in process control, power distribution, and manufacturing environments. The 171CCC78010 is a dedicated processor adaptor module that enables seamless integration and communication between Quantum CPU racks and peripheral I/O expansion systems.
Product Positioning: Designed for procurement engineers and system integrators who require a verified, OEM-grade replacement or expansion component for existing Modicon Quantum architectures. The 171CCC78010 ensures backward compatibility and deterministic performance in high-availability control systems.
Complete Technical Specifications
- Part Number / SKU: 171CCC78010
- Manufacturer: Schneider Electric (Modicon)
- Series / Platform: Modicon Quantum
- Module Type: Processor Adaptor
- Form Factor: Single-slot Quantum backplane module
- Weight: 215 g
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Relative Humidity: 5% to 95% non-condensing
- Compliance: CE, UL, cUL, IEC 61131-2
- Country of Origin: France / EU
Proven Application Environments
- Oil & gas upstream/downstream process control
- Power generation and electrical substation automation
- Water and wastewater treatment SCADA systems
- Automotive and discrete manufacturing lines
- Chemical plant distributed control integration
- Railway and infrastructure safety-critical systems
Engineering Advantages
- Direct OEM-compatible replacement — no firmware reconfiguration required
- Deterministic scan-cycle performance for time-sensitive control loops
- Hot-standby redundancy support within Quantum architecture
- Robust EMI shielding for electrically noisy industrial environments
- Plug-and-play backplane interface — minimizes downtime during replacement
- Long-term Schneider Electric lifecycle support and spare parts availability
System Architecture & Signal Flow
The 171CCC78010 mounts directly into the Modicon Quantum backplane and acts as the communication bridge between the central processing unit (CPU) and remote I/O drops or co-processor modules. Data exchange occurs over the proprietary Quantum backplane bus, ensuring low-latency, high-integrity signal transfer. The adaptor supports both local rack and remote rack topologies, compatible with Modbus Plus and Ethernet-based I/O architectures when paired with appropriate head-end modules.
Sourcing & Quality Verification
- All units sourced from authorized Schneider Electric distribution channels or verified OEM surplus
- Pre-shipment functional inspection and visual QC performed on every unit
- Original manufacturer labeling and firmware version preserved
- Traceability documentation available upon request (batch records, test reports)
- 30-day return policy for DOA (Dead on Arrival) units
Procurement Process
- Confirm part number 171CCC78010 matches your existing Quantum rack configuration
- Submit purchase order or inquiry via Konmask.com product page
- Receive order confirmation with estimated lead time within 1 business day
- Unit ships with packing list and optional certificate of conformance
- Post-delivery technical support available via email or phone
Technical FAQ
Q: Is the 171CCC78010 compatible with all Modicon Quantum CPU modules?
A: It is designed for use within the Quantum platform. Compatibility depends on the specific CPU and rack configuration — please consult your system’s hardware reference manual or contact our technical team for confirmation.
Q: Can this module be used in a hot-standby redundancy setup?
A: Yes, the Quantum platform supports hot-standby configurations. Verify your primary and standby CPU firmware versions are aligned before installation.
Q: What is the lead time for this part?
A: In-stock units typically ship within 1–3 business days. For bulk orders or urgent requirements, contact us directly for expedited options.
Q: Do you provide a warranty?
A: Yes. All units carry a 90-day functional warranty against manufacturing defects. Extended warranty options are available upon request.
