Schneider Electric LC1D115M7C 115A AC Contactor – TeSys D Series
When a high-current AC contactor fails mid-operation, the consequences cascade instantly: motors stall, production lines halt, and every minute of downtime translates directly into lost revenue and safety risk. In heavy-duty motor control applications running at 115A, there is no acceptable substitute for a proven, specification-grade contactor. The Schneider Electric LC1D115M7C is engineered precisely for these mission-critical moments — delivering reliable switching performance where failure is not an option.
Within the globally trusted TeSys D series, the LC1D115M7C occupies the upper tier of the standard contactor range, rated at 115A AC-3 for squirrel-cage motor loads. TeSys D is the world’s most widely deployed contactor platform, with installations across manufacturing, infrastructure, and energy sectors on every continent. The LC1D115M7C’s 220V AC (M7) coil voltage makes it the preferred choice for European and Asian industrial power systems, and its IEC 60947-4-1 compliance ensures seamless integration into certified control panels worldwide.
Technical Specifications
- Model / SKU: LC1D115M7C
- Brand: Schneider Electric
- Series: TeSys D
- Rated Current (AC-3): 115A
- Coil Voltage: 220V AC, 50/60Hz (M7)
- Poles: 3-pole main contacts
- Auxiliary Contacts: 1 NO + 1 NC (integrated)
- Motor Power (400V, AC-3): 55 kW
- Motor Power (690V, AC-3): 90 kW
- Utilization Category: AC-3, AC-4
- Standard: IEC 60947-4-1
- Mounting: DIN rail or screw mounting
- Degree of Protection: IP20 (open type)
- Operating Temperature: -5°C to +60°C
- Weight: Approx. 1.36 kg
- Color: Black
Key Features & Benefits
- High-Current Reliability: 115A AC-3 rating handles large squirrel-cage and slip-ring motors without derating in standard ambient conditions.
- Universal Coil Compatibility: 220V AC M7 coil suits the majority of Asian and European control circuits, reducing the need for additional transformers.
- Compact TeSys D Footprint: Despite its high current rating, the LC1D115M7C maintains the compact DIN-rail-compatible form factor of the TeSys D family, saving panel space.
- Modular Accessory Ecosystem: Compatible with the full TeSys D accessory range — add-on auxiliary contact blocks, surge suppressors, mechanical interlocks, and timer modules snap on without tools.
- Long Electrical Life: Optimized silver-alloy contact material ensures millions of operating cycles under rated load, minimizing maintenance intervals.
- IEC & CE Certified: Fully compliant with IEC 60947-4-1 and CE marking requirements, accepted by panel builders and end-users globally.
- Vibration & Shock Resistance: Designed to withstand the mechanical stresses of industrial environments including pumping stations, compressor rooms, and heavy machinery floors.
Industry & Equipment Applications
- Manufacturing & Assembly: Conveyor drives, press machines, CNC spindle motors, and robotic work cells requiring reliable high-current switching.
- Water & Wastewater: Large pump motor starters in municipal water treatment plants and industrial effluent systems.
- HVAC & Building Automation: Chiller compressor starters, air handling unit (AHU) fan motors, and cooling tower drives.
- Oil & Gas: Pump jack drives, compressor motor control panels, and offshore platform auxiliary systems.
- Mining & Minerals: Crusher drives, conveyor belt motors, and ventilation fan starters in underground and surface operations.
- Marine & Offshore: Deck machinery, ballast pump control, and engine room auxiliary motor starters.
- Renewable Energy: Wind turbine yaw and pitch motor control, solar tracker drive systems.
System Integration & Compatible Parts
The LC1D115M7C is designed for seamless integration within Schneider Electric’s TeSys D ecosystem and broader motor control architectures:
- Overload Relays: LRD340 (30–40A), LRD350 (37–50A), LRD365 (48–65A) — select based on motor FLA
- Auxiliary Contact Blocks: LADN11, LADN20, LADN02 (snap-on, front-mount)
- Surge Suppressors: LAD4RCU (RC type), LAD4RCE (varistor type) for coil protection
- Mechanical Interlock: LAD9R1 for reversing contactor configurations
- Timer Modules: LADR2 (star-delta timing) for soft-start applications
- Circuit Breakers: Schneider GV2, GV3, NSX series for upstream protection
- PLC Integration: Compatible with Schneider Modicon M221, M241, M340 PLC digital output modules via 220V AC coil drive
Our Quality Assurance Process
At Konmask.com, every Schneider Electric LC1D115M7C unit undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: Products are sourced exclusively from authorized distributors and verified supply chains with full traceability documentation.
- Visual Inspection: Each unit is inspected for label authenticity, housing integrity, contact condition, and coil terminal markings.
- Functional Testing: Coil energization and contact continuity are verified using calibrated test equipment.
- Packaging Integrity: Original manufacturer packaging is preserved; anti-static and moisture-barrier packaging is applied for international shipments.
- Documentation: Certificate of conformity and test reports available upon request for critical applications.
How to Order
- Submit your inquiry via the Contact / Request a Quote form on this page.
- Provide your required quantity, delivery destination, and any project-specific requirements (e.g., certifications, lead time).
- Our technical sales team will respond within 24 hours with pricing, availability, and lead time confirmation.
- Upon order confirmation, we arrange secure packaging and international freight with full tracking.
- Post-delivery technical support is available via email and phone for installation and commissioning queries.
Why Choose Konmask.com?
- ✅ Specialist B2B Supplier: Focused exclusively on industrial automation components — we speak your engineering language.
- ✅ Verified Authentic Stock: No grey-market or counterfeit risk — every part is traceable to authorized sources.
- ✅ Global Export Experience: Serving buyers in Europe, Southeast Asia, the Middle East, and the Americas with compliant international shipping.
- ✅ Technical Pre-Sales Support: Our engineers help you select the right contactor, overload relay, and accessories for your application.
- ✅ Fast Response: Inquiries answered within 24 hours; urgent requirements accommodated.
- ✅ Competitive Pricing: Volume discounts available for project and OEM orders.
Frequently Asked Questions
Q: What is the difference between LC1D115M7C and LC1D115B7C?
A: The suffix letter before “C” denotes the coil voltage. M7 = 220V AC 50/60Hz; B7 = 24V AC 50/60Hz. All other electrical and mechanical specifications are identical. Ensure your control circuit voltage matches the coil rating before ordering.
Q: Can the LC1D115M7C be used for AC-4 (plugging/inching) duty?
A: Yes, TeSys D contactors are rated for AC-4 duty, but the current rating is derated. Consult the TeSys D selection guide (Schneider document reference: MKTED210045EN) for AC-4 derating curves specific to your application.
Q: Is the LC1D115M7C compatible with a star-delta starter configuration?
A: Yes. Three LC1D115M7C units (or a combination with smaller contactors for the star leg) can be configured with the LAD9R1 mechanical interlock and LADR2 timer module to form a complete star-delta starter for motors up to 55kW at 400V.
Q: What overload relay should I pair with the LC1D115M7C?
A: The LRD3365 (63–80A) or LRD3375 (70–90A) are common pairings depending on motor FLA. For motors near the 115A limit, consult Schneider’s TeSys D selection tool or contact our technical team for a recommendation.
Q: Do you provide a certificate of conformity or test report?
A: Yes. Documentation including certificate of conformity is available upon request for project and tender requirements. Please specify your documentation needs when submitting your inquiry.
Q: What is the minimum order quantity (MOQ)?
A: There is no strict MOQ for standard orders. Single-unit orders are accepted. Volume pricing is available for orders of 5 units or more.
