Schneider Electric XBTGT7340 Magelis HMI Touch Panel | Replacement, Equivalent & Selection Guide
The Schneider Electric XBTGT7340 is a high-performance Magelis XBTGT series industrial HMI touch panel featuring a 12.1-inch TFT color display. Designed for demanding industrial automation environments, it delivers reliable human-machine interface functionality for Modicon PLC systems and third-party controllers. This page provides full technical specifications, compatible replacement models, equivalent alternatives, and a practical selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | XBTGT7340 |
| Brand | Schneider Electric |
| Series | Magelis XBTGT |
| Display Type | 12.1″ TFT Color LCD |
| Resolution | 800 × 600 (SVGA) |
| Touchscreen | Analog Resistive |
| Processor | 32-bit RISC |
| Memory (RAM) | 64 MB |
| Memory (Flash) | 128 MB |
| Communication Ports | Ethernet (RJ45), USB Host, USB Device, Serial (RS232/RS485) |
| Power Supply | 24 VDC (±20%) |
| Power Consumption | ≤ 30 W |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Protection Rating | IP65 (front panel) |
| Weight | ~5.14 kg |
| Configuration Software | Vijeo Designer |
| Certifications | CE, UL, cUL |
Compatible Replacement & Equivalent Models
If the XBTGT7340 is discontinued, out of stock, or outside budget, the following models offer compatible or equivalent functionality:
| Model | Brand | Display | Notes |
|---|---|---|---|
| XBTGT7345 | Schneider Electric | 12.1″ TFT | Direct upgrade — adds additional communication ports |
| HMIGTO6310 | Schneider Electric | 12.1″ TFT | Magelis GTO series successor; Vijeo Designer compatible |
| HMIGTU6310 | Schneider Electric | 12.1″ TFT | Universal series; broader protocol support |
| KTP1200 Basic | Siemens | 12″ TFT | Cross-brand alternative; requires TIA Portal reconfiguration |
| MT8121iE | Weintek (Weinview) | 12.1″ TFT | Cost-effective alternative; EasyBuilder Pro software |
| GT2715-XTBA | Mitsubishi | 15″ TFT | Larger screen alternative; GT Works3 software |
Note: Cross-brand replacements require project re-engineering. Contact our team for compatibility assessment.
Why Choose the Original XBTGT7340
- Seamless Modicon Integration — Native support for Modbus TCP/IP, Uni-Telway, and Modicon PLC protocols without additional gateways.
- Vijeo Designer Ecosystem — Existing project files (.vdz) are directly reusable, eliminating re-engineering costs.
- IP65 Front Panel — Certified dust-tight and water-resistant for harsh industrial environments.
- Proven Reliability — Widely deployed in automotive, food & beverage, water treatment, and energy sectors globally.
- OEM Warranty Compliance — Using the original part maintains machine warranty and CE/UL certification integrity.
Typical Applications
- Machine control panels in automotive assembly lines
- SCADA visualization terminals in water & wastewater plants
- Process monitoring in food & beverage production
- Energy management dashboards in power distribution
- Packaging machine operator interfaces
- Building automation and HVAC control systems
System Compatibility
The XBTGT7340 communicates natively with the following Schneider Electric PLC families and is also compatible with third-party controllers via standard protocols:
- Schneider Modicon M340 — Modbus TCP/IP, Ethernet
- Schneider Modicon M580 — Modbus TCP/IP, EtherNet/IP
- Schneider Modicon Premium / Quantum — Uni-Telway, Modbus
- Siemens S7-300/400/1200/1500 — via Modbus TCP or MPI gateway
- Mitsubishi MELSEC Q/L/iQ-R — via Modbus RTU/TCP
- Allen-Bradley (Rockwell) — via EtherNet/IP or DF1
- Omron CJ/CS/NJ Series — via Modbus TCP/RTU
Selection Guide
Use this guide to determine whether the XBTGT7340 is the right choice or if an alternative better fits your requirements:
| Requirement | Recommended Model |
|---|---|
| Direct drop-in replacement, same footprint | XBTGT7340 (original) or XBTGT7345 |
| Upgrade to newer Schneider platform | HMIGTO6310 / HMIGTU6310 |
| Budget-sensitive replacement, Modbus only | Weintek MT8121iE |
| Siemens TIA Portal environment | Siemens KTP1200 Basic |
| Larger display needed (15″) | Mitsubishi GT2715-XTBA |
| Existing Vijeo Designer project reuse | XBTGT7340 or HMIGTO6310 |
Quality Assurance & Sourcing
- Authentic Parts — All units sourced from authorized distributors or verified surplus channels with full traceability.
- Pre-shipment Testing — Each unit undergoes power-on and communication port verification before dispatch.
- Anti-Counterfeit Inspection — Serial number, label, and firmware version verified against manufacturer records.
- Packaging — ESD-safe packaging with original or equivalent protective materials.
- Warranty — 12-month warranty against manufacturing defects on all units supplied by Konmask.com.
How to Order
- Confirm your exact part number: XBTGT7340 (check nameplate on existing unit).
- Verify firmware version requirements with your system integrator if applicable.
- Add to cart or contact us for bulk pricing and lead time confirmation.
- Provide your shipping address — we ship worldwide with DHL, FedEx, and UPS Express options.
- Receive order confirmation and tracking within 24 hours of payment.
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Is the XBTGT7340 still in production?
A: The XBTGT7340 has been superseded by newer Magelis GTO/GTU series models. Stock availability varies — contact us to confirm current inventory.
Q: Can I use the HMIGTO6310 as a direct replacement?
A: Yes, with minor project migration in Vijeo Designer. The physical cutout dimensions are compatible. Our team can advise on migration steps.
Q: Will a cross-brand HMI (e.g., Weintek) work with my Modicon PLC?
A: Yes, via Modbus TCP/RTU. However, you will need to rebuild the HMI project from scratch in the alternative software. We recommend this only when cost is the primary constraint.
Q: Do you provide a warranty on used/refurbished units?
A: Yes. All units — new, surplus, or refurbished — carry a 12-month warranty from Konmask.com.
Q: What is the lead time for the XBTGT7340?
A: Typically 3–7 business days for in-stock units. Express shipping available. Contact us for urgent requirements.
