Genuine SEW MDX60A0055-5A3-4-00 Frequency Inverter | MOVIDRIVE B Series – Verified Source
The SEW-EURODRIVE MDX60A0055-5A3-4-00 is a compact, high-performance AC frequency inverter from the renowned MOVIDRIVE® B series. Designed for demanding industrial motion control applications, this drive delivers precise speed and torque regulation for three-phase asynchronous and synchronous motors. Konmask.com supplies this unit as a genuine, traceable component — backed by our 4-step verification process and sourced through authorized industrial channels.
Technical Specifications
- Part Number / SKU: MDX60A0055-5A3-4-00
- Series: MOVIDRIVE® B (MDX60A)
- Manufacturer: SEW-EURODRIVE
- Output Power: 0.55 kW (0.75 HP)
- Supply Voltage: 3-phase AC 380–500 V (±10%), 50/60 Hz
- Output Current: 1.7 A (continuous)
- Control Mode: VFC (Voltage Frequency Control) / CFC (Closed-loop Flux Control)
- Communication: RS-485 (SBus), optional fieldbus via expansion card
- Protection Class: IP20 (panel-mount)
- Ambient Temperature: 0 °C to +40 °C (operating)
- Weight: approx. 1.8 kg
- Standards: CE, UL, cUL
Our 4-Step Quality Verification Process
- Step 1 – Source Traceability: Every unit is procured through documented industrial supply chains with verifiable origin records.
- Step 2 – Visual & Label Inspection: Nameplate data, holographic seals, and housing integrity are checked against OEM specifications.
- Step 3 – Functional Pre-check: Where applicable, units undergo power-on diagnostics and firmware version confirmation.
- Step 4 – Secure Packaging: Anti-static packaging with tamper-evident sealing ensures safe transit to your facility.
Key Features & Benefits
- Compact footprint — ideal for space-constrained control cabinets
- Integrated brake chopper for dynamic braking applications
- Plug-in option cards for PROFIBUS, DeviceNet, CANopen, and EtherCAT
- Parameterization via MOVITOOLS® MotionStudio software
- Safe Stop function (STO) compliant with EN 61800-5-2
- Energy-saving ECO mode for reduced power consumption at partial load
- Wide input voltage tolerance — suitable for unstable grid environments
Typical Applications
- Conveyor and material handling systems
- Pump and fan speed control
- Packaging and filling machinery
- Textile and printing equipment
- Hoisting and crane drives (with appropriate brake control)
- General industrial automation and OEM machine building
Compatible System Components
- Gearboxes: SEW-EURODRIVE R, F, K, S series helical and bevel-helical gear units
- Motors: SEW DRN / DR series AC motors; compatible with third-party motors
- Option Cards: DFP21B (PROFIBUS), DFE24B (EtherNet/IP), DFC21B (CANopen)
- Braking Resistors: BW series external resistors for high-cycle braking duty
- Filters: NF series input line filters for EMC compliance
- HMI / Keypad: DBG60B handheld operator panel
Global Sourcing & Shipping Capabilities
Konmask.com ships the SEW MDX60A0055-5A3-4-00 worldwide from our warehouse in China. We support:
- Express delivery: DHL / FedEx / UPS — typically 3–7 business days globally
- Sea freight consolidation for bulk orders
- Export documentation: Commercial invoice, packing list, COO, and HS code 8504.40 declaration
- Customs support: We assist with HS classification and export licensing where required
Certifications & Compliance Statement
This product is manufactured by SEW-EURODRIVE and carries the following certifications:
- CE Marking — compliant with EU Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU
- UL / cUL Listed
- RoHS compliant
Konmask.com is an independent distributor and is not an authorized SEW-EURODRIVE dealer. All brand names and trademarks are the property of their respective owners. Products are sourced from legitimate industrial supply channels.
How to Order
- Click Add to Cart or use the Request a Quote button for bulk pricing.
- Provide your required quantity, delivery address, and any special requirements.
- Our team will confirm stock availability and issue a proforma invoice within 1 business day.
- Payment accepted via T/T (bank transfer), PayPal, and major credit cards.
- Tracking number provided upon shipment.
Authenticity & Trust FAQ
Q: Is this a genuine SEW-EURODRIVE product?
A: Yes. We source only genuine OEM parts through verified industrial supply channels. Each unit passes our 4-step inspection before dispatch.
Q: Can you provide documentation or test reports?
A: Yes. We can provide available inspection records, photos of the actual unit, and shipping documentation upon request.
Q: What if the product is faulty on arrival?
A: We offer a 30-day DOA (Dead on Arrival) guarantee. Contact us immediately with photos and we will arrange a replacement or full refund.
Q: Do you offer warranty?
A: We provide a 90-day seller warranty covering manufacturing defects. Extended warranty options are available — please inquire.
Q: Can I order in bulk?
A: Yes. Volume discounts are available for orders of 3+ units. Contact us for a custom quote.
