Pump & Fan Drive Solution – YASKAWA CIMR-L5JJ4011 | L5 Series
Where This Product Is Used
The YASKAWA CIMR-L5JJ4011 is a 15 kW (20 HP), 400 V class variable frequency drive from the YASKAWA L5 Series, purpose-engineered for variable-torque loads in building services and light industrial environments. Typical deployment scenarios include:
- HVAC Systems – Supply and return air fans in commercial buildings, AHUs, and rooftop units where energy savings through speed control are critical.
- Pump Stations – Centrifugal water pumps, booster pumps, and chilled-water circulation loops requiring smooth ramp-up and pressure regulation.
- Cooling Towers – Fan speed modulation to maintain condenser water temperature setpoints.
- Industrial Ventilation – Exhaust and supply fans in manufacturing plants, clean rooms, and process facilities.
- Water Treatment – Aeration blowers and transfer pumps in municipal and industrial water/wastewater plants.
- OEM Machinery – Embedded in packaged pump skids, fan arrays, and compressor systems where compact footprint and reliable V/f control are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | CIMR-L5JJ4011 |
| Series | YASKAWA L5 (GPD515 / G5) |
| Rated Output Power | 15 kW (20 HP) |
| Input Voltage | 3-Phase 380–480 V AC ±10% |
| Output Voltage | 3-Phase 0–480 V AC |
| Output Frequency Range | 0.1–400 Hz |
| Rated Output Current | 31 A |
| Control Method | V/f Control (Variable Torque) |
| Enclosure Rating | IP20 (NEMA 1 with conduit kit) |
| Cooling Method | Forced air cooling |
| Weight | 6.28 kg |
| Communication | RS-422/485 (MEMOBUS/Modbus RTU) |
| Braking | Dynamic braking transistor built-in |
| Ambient Temperature | -10°C to +40°C (operating) |
| Humidity | 95% RH max, non-condensing |
| Altitude | Up to 1,000 m without derating |
Why Engineers Specify This Model
- Variable-Torque Optimized: The L5 Series is factory-configured for fan and pump loads, delivering up to 30–50% energy savings versus across-the-line starters through affinity-law speed reduction.
- Proven Reliability: YASKAWA’s L5/G5 platform has millions of installed units globally across HVAC and water infrastructure — a benchmark for mean time between failures (MTBF) in the VFD industry.
- Built-in PID Control: Closed-loop pressure or flow control without an external PLC, reducing panel complexity and BOM cost.
- Modbus RTU Native: Direct integration with BMS/SCADA systems via RS-485 without additional gateways.
- Dynamic Braking Transistor: Enables fast deceleration for applications requiring controlled stop cycles.
- Auto-Restart & Fault Ride-Through: Minimizes unplanned downtime in critical infrastructure applications.
- Compact Panel Footprint: Optimized chassis dimensions for retrofit into existing MCC or control panel enclosures.
Complete System Bill of Materials
For a fully commissioned CIMR-L5JJ4011 drive installation, engineers typically specify the following complementary components:
- Input Line Reactor – 3% impedance AC reactor for harmonic mitigation and protection against line transients
- EMC Input Filter – Class C2/C3 filter for CE compliance in sensitive environments
- Dynamic Braking Resistor – External resistor for high-inertia load deceleration (if duty cycle exceeds internal transistor rating)
- Output dV/dt Filter – Motor protection filter for long cable runs (>50 m) to prevent winding insulation stress
- Bypass Contactor Assembly – Manual or automatic bypass for maintenance continuity in critical HVAC systems
- Remote Operator Panel – YASKAWA JVOP-182 or compatible remote keypad for panel-door mounting
- RS-485 Communication Cable – Shielded twisted-pair for Modbus RTU BMS integration
- Fused Disconnect Switch – Upstream protection per NEC/IEC installation requirements
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C – Power Conversion Equipment (UL Listed)
- cUL – Canadian market compliance
- RoHS Compliant – Restriction of Hazardous Substances
- ISO 9001 – YASKAWA manufacturing quality management system
- IEC 61800-3 – Adjustable speed electrical power drive systems EMC standard
- IEC 61800-5-1 – Safety requirements for adjustable speed drive systems
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers, system integrators, and MRO procurement teams. Every unit offered is:
- Sourced from authorized distributors or verified surplus channels with full traceability
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with original manufacturer packaging where available
- Supported by pre-sale technical consultation to confirm compatibility with your application
We maintain stock of YASKAWA L5/G5 series drives across multiple power ratings. Contact us for lead time, quantity pricing, and cross-reference to equivalent current-generation YASKAWA GA700 or GA500 models.
How to Source This Part
- Confirm your application requirements – motor kW, supply voltage, control method (V/f vs. vector), and communication protocol.
- Verify the part number – CIMR-L5JJ4011 decodes as: L5 Series | 400V class | 11 kW heavy-duty / 15 kW normal-duty frame.
- Request a quote – Contact support@konmask.com with your quantity, delivery location, and required lead time.
- Place your order – Secure checkout with bank transfer, PayPal, or trade account terms for qualified buyers.
- Receive & commission – Units ship with parameter initialization guide; our engineers are available for remote commissioning support.
Application-Specific FAQ
Q: Can the CIMR-L5JJ4011 control a 15 kW pump motor directly?
A: Yes. The drive is rated for 15 kW normal-duty (variable torque) loads. For constant-torque or heavy-duty applications at 15 kW, verify the output current against your motor’s FLA and consider the next frame size up.
Q: Is this drive compatible with BACnet or LonWorks BMS systems?
A: The CIMR-L5JJ4011 natively supports Modbus RTU via RS-485. BACnet/IP or LonWorks integration requires an optional YASKAWA SI-B3 or third-party protocol gateway.
Q: What is the replacement/equivalent current-generation YASKAWA model?
A: The functional successor is the YASKAWA GA500 (CIPR-GA50B4011ABB) or GA700 series for higher-performance vector control requirements. Konmask can supply both legacy and current-generation units.
Q: Can I use this drive for a constant-torque conveyor application?
A: The L5 Series is optimized for variable-torque (fan/pump) loads. For constant-torque conveyors or hoists, the YASKAWA A1000 or GA700 with open-loop vector control is the recommended specification.
Q: What is the warranty and return policy?
A: Please contact support@konmask.com for current warranty terms applicable to your order. We offer pre-shipment inspection reports on request.
