SIEMENS 3RV6011-1BA15 Motor Starter Protector Circuit Breaker | Replacement, Equivalent & Selection Guide
The SIEMENS 3RV6011-1BA15 is a compact motor starter protector (MSP) from the SIEMENS SIRIUS 3RV6 series, designed for motor branch circuit protection up to 2A. It combines overload and short-circuit protection in a single device, making it ideal for industrial automation and motor control centers (MCC). Konmask.com supplies genuine and compatible units with fast global shipping.
Technical Specifications
- Part Number / SKU: 3RV6011-1BA15
- Brand: SIEMENS
- Series: SIRIUS 3RV6
- Type: Motor Starter Protector (MSP) / Circuit Breaker
- Current Setting Range: 1.4 – 2 A
- Rated Voltage (Ue): Up to 690 V AC
- Rated Frequency: 50/60 Hz
- Short-Circuit Breaking Capacity (Icu): 100 kA at 400 V
- Frame Size: S00 (smallest frame)
- Poles: 3-pole
- Mounting: DIN rail (35 mm) or screw mounting
- Protection Class: IP20
- Ambient Temperature: -20 °C to +60 °C
- Weight: Approx. 230 g
- Standards: IEC/EN 60947-4-1, UL 508, CSA C22.2
Compatible Replacement & Equivalent Models
The following models are commonly used as replacements or equivalents for the SIEMENS 3RV6011-1BA15. Always verify electrical ratings before substitution:
- SIEMENS 3RV1011-1BA10 – Previous generation 3RV1 series, same S00 frame, 1.4–2A range (direct predecessor)
- SIEMENS 3RV2011-1BA10 – 3RV2 series equivalent, compatible mounting footprint
- ABB MS116-2.0 – ABB manual motor starter, 1.6–2.0A, IEC compliant alternative
- Schneider Electric GV2ME07 – TeSys GV2 series, 1.6–2.5A, functionally equivalent MSP
- Eaton PKZM0-2 – PKZ series motor-protective circuit breaker, 1.6–2.0A range
Note: Cross-brand substitutions require verification of terminal compatibility, tripping characteristics, and system approvals.
Why Choose the Original SIEMENS 3RV6011-1BA15
- ✅ Certified Performance: Fully compliant with IEC/EN 60947-4-1 and UL 508 for global deployments
- ✅ High Breaking Capacity: 100 kA Icu at 400 V — superior short-circuit protection
- ✅ Modular Ecosystem: Seamlessly integrates with SIEMENS 3RT contactors, 3RV6 accessories (auxiliary contacts, shunt trips, alarm switches)
- ✅ Compact S00 Frame: Space-saving design for dense panel layouts
- ✅ Long Service Life: Rated for 1,000,000 mechanical operations
- ✅ Genuine Traceability: Factory serial numbers and CE/UL markings for audit compliance
Typical Applications
- Motor branch circuit protection for small 3-phase motors (up to ~0.75 kW / 1 HP at 400 V)
- Motor Control Centers (MCC) and control panels
- Conveyor systems, pumps, fans, and compressors
- HVAC equipment and building automation
- Packaging machinery and food processing lines
- OEM machine builders requiring IEC-certified protection
System Compatibility
The 3RV6011-1BA15 is designed for use within the SIEMENS SIRIUS modular system:
- Contactors: 3RT2015, 3RT2016, 3RT2017 (S00 frame contactors)
- Accessories: 3RV6901 auxiliary switch blocks, 3RV6921 shunt trip, 3RV6931 undervoltage release
- Bus Systems: Compatible with AS-Interface and PROFIBUS via appropriate gateway modules
- Enclosures: Fits standard 35 mm DIN rail in IEC-compliant control panels
Selection Guide
Use the table below to select the correct 3RV6011 variant based on your motor’s full-load current (FLC):
- 3RV6011-0AA15: 0.11 – 0.16 A
- 3RV6011-0BA15: 0.14 – 0.20 A
- 3RV6011-0CA15: 0.18 – 0.25 A
- 3RV6011-0DA15: 0.22 – 0.32 A
- 3RV6011-0EA15: 0.28 – 0.40 A
- 3RV6011-0FA15: 0.35 – 0.50 A
- 3RV6011-0GA15: 0.45 – 0.63 A
- 3RV6011-0HA15: 0.55 – 0.80 A
- 3RV6011-0JA15: 0.70 – 1.00 A
- 3RV6011-0KA15: 0.90 – 1.25 A
- 3RV6011-1AA15: 1.1 – 1.6 A
- 3RV6011-1BA15 (This Model): 1.4 – 2.0 A ← You are here
- 3RV6011-1CA15: 1.8 – 2.5 A
- 3RV6011-1DA15: 2.2 – 3.2 A
- 3RV6011-1EA15: 2.8 – 4.0 A
- 3RV6011-1FA15: 3.5 – 5.0 A
Tip: Set the current dial to match your motor’s nameplate FLC. For star-delta starters, select based on the motor’s rated current, not the contactor current.
Quality Assurance & Sourcing
- Source: Authorized distribution channels and verified surplus stock
- Inspection: Each unit inspected for physical integrity, markings, and date codes before shipment
- Packaging: Original SIEMENS retail or OEM packaging where available
- Documentation: Certificate of conformity and datasheet available on request
- Warranty: 12-month warranty against manufacturing defects
- Anti-Counterfeit: All units sourced from traceable supply chains; counterfeit detection checks applied
How to Order
- SKU / Part Number: 3RV6011-1BA15
- Minimum Order Quantity: 1 piece
- Lead Time: In-stock items ship within 1–3 business days; ex-stock orders confirmed within 24 hours
- Payment: T/T, PayPal, credit card, and trade terms available for qualified buyers
- Shipping: DHL, FedEx, UPS worldwide; sea freight available for bulk orders
- RFQ for bulk quantities: Contact support@konmask.com for volume pricing
Replacement & Compatibility FAQ
Q: Can I replace a 3RV1011-1BA10 with a 3RV6011-1BA15?
A: Yes. The 3RV6011 series is the direct successor to the 3RV1011 series with the same S00 frame and identical mounting footprint. Electrical ratings are equivalent.
Q: Is the 3RV6011-1BA15 compatible with 3RT2015 contactors?
A: Yes. The 3RV6011 S00 frame is designed to directly couple with S00-frame 3RT2 contactors using the 3RA6912-2A coupling link.
Q: What is the difference between 3RV6011-1BA10 and 3RV6011-1BA15?
A: The suffix “15” indicates the unit includes a trip indicator and is rated for 100 kA breaking capacity. The “10” suffix has 55 kA. Always specify the full part number when ordering.
Q: Can I use an ABB MS116-2.0 as a drop-in replacement?
A: Electrically compatible in most cases, but terminal layout and accessory mounting differ. Panel modifications may be required. Consult your panel builder before substituting.
Q: Does this unit support remote tripping?
A: Yes, with the optional 3RV6921 shunt trip accessory or 3RV6931 undervoltage release add-on.
