Siemens 6AV6648-1AC22-0AX0 SIMATIC HMI KTP1000 Basic PN | Replacement, Equivalent & Selection Guide
The Siemens 6AV6648-1AC22-0AX0 is a SIMATIC HMI KTP1000 Basic PN — a 10-inch TFT widescreen touch panel with PROFINET interface, designed for machine-level visualization in industrial automation systems. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: 6AV6648-1AC22-0AX0
- Series: SIMATIC HMI KTP1000 Basic PN
- Display: 10.1″ TFT widescreen, 1280 × 800 px, 16M colors
- Touch: Resistive single-touch + 8 function keys
- Interface: 1 × PROFINET (RJ45)
- USB: 1 × USB Type-A (host)
- Power Supply: 24 V DC (20.4–28.8 V)
- Power Consumption: Approx. 18 W
- Protection Rating: IP65 (front panel)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +60 °C
- Dimensions (W×H×D): 310 × 220 × 46 mm
- Weight: Approx. 1.9 kg
- Configuration Software: WinCC Basic / TIA Portal V13 SP1 and above
- Memory: 10 MB user memory
- Certifications: CE, UL, cULus, ATEX Zone 2
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or direct replacements for the 6AV6648-1AC22-0AX0. Always verify interface type, display size, and TIA Portal version compatibility before substitution.
- 6AV6648-1AC22-0AX0 — Original model (this listing)
- 6AV2123-2JB03-0AX0 — KTP1000 Basic PN (2nd Gen, TIA Portal V14+), direct functional replacement
- 6AV6648-1DC22-0AX0 — KTP1000 Basic DP (MPI/PROFIBUS interface), same display, different bus
- 6AV6643-0CD01-1AX1 — MP 277 10″ Touch (legacy, larger memory, multi-protocol)
- 6AV2124-0JC01-0AX0 — KTP1200 Basic PN (12″ upgrade option, same PROFINET)
- 6AV6545-0CC10-0AX0 — TP 270 10″ (legacy WinCC flexible, for older S7-300/400 systems)
Note: Replacement compatibility depends on PLC series, TIA Portal version, and project configuration. Contact Konmask for pre-sales verification.
Why Choose the Original Model
- ✅ Native TIA Portal integration — seamless project migration from WinCC Basic
- ✅ PROFINET-only architecture — simplified wiring, no additional gateway required
- ✅ IP65 front protection — suitable for dusty and splash-prone environments
- ✅ Siemens global support — firmware updates, spare parts, and long-term availability
- ✅ Proven reliability — widely deployed in automotive, food & beverage, and packaging industries
Typical Applications
- Machine-level HMI for SIMATIC S7-1200 / S7-1500 PLC systems
- Production line visualization and operator control panels
- Conveyor, packaging, and assembly automation
- Water treatment and HVAC control systems
- Food & beverage processing with washdown-resistant enclosures
- OEM machine builders requiring compact, cost-effective HMI solutions
System Compatibility
- PLC: Siemens S7-1200, S7-1500 (PROFINET); S7-300/400 via PN/DP coupler
- Engineering Software: TIA Portal V13 SP1 / V14 / V15 / V16 / V17 / V18 / V19
- Communication Protocol: PROFINET IO (RT)
- Not compatible with: S7-200 (requires KTP series with PPI), WinCC flexible standalone projects without migration
Selection Guide
Use this guide to confirm the 6AV6648-1AC22-0AX0 is the right choice, or to identify a better-fit alternative:
- Display size needed < 10"? → Consider KTP700 Basic PN 6AV2123-2GB03-0AX0
- Display size needed > 10″? → Consider KTP1200 Basic PN 6AV2124-0JC01-0AX0
- Need PROFIBUS/MPI instead of PROFINET? → Use KTP1000 Basic DP 6AV6648-1DC22-0AX0
- Need multi-touch or higher resolution? → Consider SIMATIC HMI Comfort Panel series
- Connecting to S7-300/400 legacy systems? → Verify PN/DP coupler or use MP 277 series
- Budget-sensitive OEM project? → 6AV6648-1AC22-0AX0 offers the best price-to-performance ratio in the Basic PN line
Quality Assurance & Sourcing
- 🔒 Authentic Siemens product — sourced from authorized distributors and verified supply chains
- 🔒 Anti-counterfeit inspection — each unit verified against Siemens hologram and serial number database
- 🔒 Warranty: 12-month Konmask warranty; original Siemens factory warranty honored where applicable
- 🔒 Condition: New-in-box (NIB) and refurbished options available — clearly labeled
- 🔒 Export compliance: All shipments comply with applicable export control regulations
How to Order
- Confirm part number: 6AV6648-1AC22-0AX0
- Specify quantity and required delivery timeline
- Request a formal quotation via support@konmask.com or WhatsApp +0086 19859288691
- Receive proforma invoice with lead time and shipping options (DHL / FedEx / sea freight)
- Payment: T/T, PayPal, or credit card via Shopify secure checkout
Replacement & Compatibility FAQ
Q: Can I replace 6AV6648-1AC22-0AX0 with 6AV2123-2JB03-0AX0 directly?
A: Yes, the 6AV2123-2JB03-0AX0 (2nd Gen KTP1000 Basic PN) is the functional successor. You will need to migrate your TIA Portal project to V14 or higher. Physical dimensions and PROFINET interface are identical.
Q: Is this panel compatible with S7-300 via PROFIBUS?
A: No. The 6AV6648-1AC22-0AX0 uses PROFINET only. For PROFIBUS/MPI connectivity, use the KTP1000 Basic DP (6AV6648-1DC22-0AX0) or add a PN/DP coupler.
Q: What is the difference between KTP1000 Basic PN and KTP1000 Comfort?
A: The Basic PN supports WinCC Basic (TIA Portal) with limited tag count and no recipe/trend functions. The Comfort Panel supports WinCC Comfort with advanced features, higher tag count, and multi-touch display.
Q: Can Konmask provide a certificate of origin or test report?
A: Yes. We provide CoO, packing list, and inspection reports upon request. Contact us before placing your order.
