Siemens 6DR4004-8J – Interface Unit for SIPART PS2 Smart Positioner
Engineering Background: The Siemens 6DR4004-8J is a dedicated interface unit designed for the SIPART PS2 family of electropneumatic smart positioners. SIPART PS2 is Siemens’ flagship positioner platform, widely deployed across oil & gas, chemical, power generation, and water treatment industries for precise valve control in demanding process environments.
Product Positioning: The 6DR4004-8J serves as the communication and signal interface backbone of the SIPART PS2 positioner, enabling seamless integration with distributed control systems (DCS), HART-based asset management tools, and fieldbus architectures. It is the critical link between the positioner’s internal electronics and the plant’s control infrastructure, ensuring reliable setpoint transmission, position feedback, and diagnostic data exchange.
Complete Technical Specifications
- Part Number / SKU: 6DR4004-8J
- Product Family: SIPART PS2
- Manufacturer: Siemens AG
- Function: Interface Unit for Smart Positioner
- Compatible Platform: SIPART PS2 (6DR5xxx series)
- Communication Protocol: HART (Highway Addressable Remote Transducer)
- Signal Interface: 4–20 mA analog with HART overlay
- Enclosure: Module form factor for SIPART PS2 housing
- Country of Origin: Germany
- Approvals: CE, ATEX (refer to product datasheet for full certification list)
- Weight: Approx. 40 g
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline valve automation, downstream refinery process control
- Chemical & Petrochemical: Reactor feed control, distillation column valve management, batch process automation
- Power Generation: Turbine bypass valve control, boiler feedwater regulation, steam header management
- Water & Wastewater: Pump station flow control, treatment plant valve automation
- Pharmaceutical: Clean-in-place (CIP) valve sequencing, sterile process control
Engineering Advantages
- Plug-and-Play Integration: Designed as a factory-matched accessory for SIPART PS2, ensuring zero compatibility risk and simplified commissioning
- HART Diagnostics: Enables full HART communication for remote valve diagnostics, partial stroke testing (PST), and predictive maintenance via asset management systems (e.g., Siemens PDM, AMS Device Manager)
- High Signal Integrity: Maintains accurate 4–20 mA setpoint and feedback signals even in electrically noisy industrial environments
- Compact Module Design: Minimal footprint within the SIPART PS2 housing; no additional enclosure required
- Long Service Life: Built to Siemens industrial-grade standards for continuous operation in harsh field conditions
System Architecture & Signal Flow
In a typical SIPART PS2 installation, the 6DR4004-8J interface unit receives the 4–20 mA control signal from the DCS output card. The HART protocol layer is superimposed on this analog signal, allowing bidirectional digital communication. The interface unit conditions and routes this signal to the positioner’s main electronics board, which drives the pneumatic output to the actuator. Position feedback from the internal potentiometer or external sensor is returned via the same interface path to the DCS and HART master.
Sourcing & Quality Verification
- Source: Authorized distribution channels and verified OEM surplus inventory
- Inspection: Each unit undergoes visual inspection and functional verification prior to shipment
- Traceability: Original Siemens part markings and labeling preserved; no remarked or counterfeit parts
- Packaging: Anti-static protective packaging with original or equivalent protective materials
- Warranty: 12-month operational warranty against manufacturing defects
Procurement Process
- Confirm compatibility with your SIPART PS2 model (6DR5xxx series) and existing interface configuration
- Submit your purchase order or inquiry via the product page or email support@konmask.com
- Receive order confirmation with lead time and shipping details within 1 business day
- Unit ships with inspection certificate and packing list
- Post-delivery technical support available via email or phone
Technical FAQ
Q: Is the 6DR4004-8J compatible with all SIPART PS2 variants?
A: The 6DR4004-8J is designed for the SIPART PS2 platform. Compatibility depends on the specific 6DR5xxx model and firmware version. Please confirm your positioner model number before ordering.
Q: Does this unit support PROFIBUS or FOUNDATION Fieldbus?
A: The 6DR4004-8J is the HART interface variant. Separate interface modules exist for PROFIBUS PA and FOUNDATION Fieldbus versions of SIPART PS2.
Q: Can this module be field-replaced without returning the positioner to the factory?
A: Yes. The SIPART PS2 is designed for modular field maintenance. The interface unit can be replaced on-site by qualified instrumentation technicians following Siemens service documentation.
Q: What is the lead time for the 6DR4004-8J?
A: In-stock units ship within 1–3 business days. Contact us for current stock status and expedited shipping options.
