Siemens 6ES7138-4DF11-0AB0 ET 200S 4DO 24VDC/0.5A | Replacement, Equivalent & Selection Guide
The Siemens 6ES7138-4DF11-0AB0 is a 4-channel digital output electronic module for the SIMATIC ET 200S distributed I/O system. Rated at 24 VDC / 0.5 A per channel, it delivers reliable transistor switching in compact panel and field-cabinet installations. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide for engineers and procurement teams.
Technical Specifications
- Part Number: 6ES7138-4DF11-0AB0
- Series: SIMATIC ET 200S
- Module Type: Electronic Module – Digital Output (4DO)
- Output Channels: 4 × digital output
- Output Voltage: 24 VDC
- Output Current: 0.5 A per channel (max 2 A total)
- Output Type: Transistor, sourcing (PNP)
- Short-Circuit Protection: Yes (electronic)
- Isolation: Optocoupler (field ↔ backplane bus)
- Power Consumption: Approx. 1.5 W (from backplane bus)
- Dimensions (W × H × D): 15 × 81 × 52 mm
- Weight: Approx. 270 g (with terminal module)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Degree of Protection: IP20
- Country of Origin: Germany
- HS Code: 8537.10
- Compatible Terminal Module: TM-E15S24-01 (6ES7193-4CA30-0AA0)
Compatible Replacement & Equivalent Models
When the 6ES7138-4DF11-0AB0 is unavailable or discontinued, the following models are functionally compatible or serve as direct/near-direct replacements. Always verify firmware and terminal module compatibility before substitution.
- 6ES7138-4DF01-0AB0 – Earlier revision; functionally identical, different firmware baseline. Direct drop-in replacement.
- 6ES7138-4DB03-0AB0 – 2DO 24VDC/2A variant; use when higher per-channel current is required.
- 6ES7138-4DC01-0AB0 – 2DO relay output; suitable for AC load switching.
- 6ES7138-4CA01-0AA0 – 4DO 24VDC/0.5A (older generation); verify terminal module compatibility.
- Third-Party Equivalents: Phoenix Contact IL DO 4/M-PAC, Wago 750-504 — require adapter or rewiring; not plug-and-play.
Note: ET 200S modules are not interchangeable with ET 200SP or ET 200MP without hardware and configuration changes.
Why Choose the Original Model
- Guaranteed Compatibility: Plug-and-play with all ET 200S IM 151-x interface modules and TIA Portal / STEP 7 configurations.
- Proven Reliability: Siemens manufacturing process; consistent performance in 24/7 industrial environments.
- Firmware Continuity: Revision 11 (AB0) compatible with current GSD/GSDML files — no re-parameterization required.
- Warranty & Traceability: Full Siemens factory warranty; traceable batch and serial numbers for quality audits.
- Long-Term Support: Siemens spare-parts availability through the full product lifecycle.
Typical Applications
- Solenoid valve control in pneumatic and hydraulic systems
- Indicator lamp and signal tower switching
- Conveyor belt and motor starter enable signals
- Packaging machinery actuator control
- Automotive assembly line I/O expansion
- Water treatment and HVAC distributed control panels
- Food & beverage process automation (IP20 cabinet-mounted)
System Compatibility
- Interface Module: ET 200S IM 151-1 Standard / IM 151-1 FO / IM 151-7 CPU
- Terminal Module Required: TM-E15S24-01 (6ES7193-4CA30-0AA0) — sold separately
- Bus System: PROFIBUS DP
- Programming Software: SIMATIC STEP 7 V5.x, TIA Portal V13+
- GSD File: SI008132.GSD (ET 200S standard)
- Not Compatible With: ET 200SP, ET 200MP, ET 200M, S7-300/400 direct I/O slots
Selection Guide
Use the criteria below to select the correct ET 200S digital output module:
- 4 ch · 24VDC · 0.5A · transistor PNP: → 6ES7138-4DF11-0AB0 ✓ (this model)
- 2 ch · 24VDC · 2A · transistor PNP: → 6ES7138-4DB03-0AB0
- 2 ch · relay · 24VDC/230VAC · 2A: → 6ES7138-4DC01-0AB0
- 4 ch · 24VDC · 0.5A · fail-safe (F-DO): → 6ES7138-4FB03-0AB0
- 8 ch · 24VDC · 0.5A (compact): → ET 200SP 8DO module (requires system migration)
Key selection criteria: channel count → load current → load type (resistive / inductive / lamp) → safety requirements (standard vs. fail-safe) → terminal module availability.
Quality Assurance & Sourcing
- Source: Authorized distribution channel and verified surplus stock.
- Inspection: Every unit inspected for physical integrity, label authenticity, and firmware revision before shipment.
- Packaging: Original Siemens anti-static packaging or equivalent ESD-safe packaging.
- Documentation: Certificate of conformity and packing list provided on request.
- Counterfeit Prevention: Konmask.com sources only from traceable supply chains. Batch records available for enterprise buyers.
How to Order
- Part Number: 6ES7138-4DF11-0AB0
- Minimum Order Quantity: 1 piece
- Lead Time: In-stock items ship within 1–3 business days. Contact us for bulk order lead times.
- Payment: T/T, PayPal, credit card, and trade-term arrangements for qualified buyers.
- RFQ / Bulk Inquiry: Email support@konmask.com or call +0086 19859288691.
- Export: We ship worldwide. Export documentation (commercial invoice, packing list, CO) provided.
Replacement & Compatibility FAQ
Q: Can I replace 6ES7138-4DF01-0AB0 with 6ES7138-4DF11-0AB0?
A: Yes. The -11- revision is the updated version of -01-. Direct drop-in replacement using the same terminal module and GSD file. No hardware or software reconfiguration required in most cases.
Q: Is the 6ES7138-4DF11-0AB0 compatible with ET 200SP?
A: No. ET 200S and ET 200SP use different mechanical and electrical interfaces. Migration requires replacing the interface module, terminal modules, and updating the hardware configuration in TIA Portal.
Q: What terminal module does this electronic module require?
A: TM-E15S24-01 (6ES7193-4CA30-0AA0). Ensure the terminal module is pre-installed on the DIN rail before inserting the electronic module.
Q: Can this module switch AC loads?
A: No. This is a DC transistor output module (24 VDC only). For AC load switching, use the relay output variant 6ES7138-4DC01-0AB0.
Q: What is the maximum total current for all 4 channels?
A: 0.5 A per channel; do not exceed 2 A total simultaneous load. Refer to Siemens ET 200S manual (A5E00124871) for derating curves.
