SIEMENS 6ES7157-0AC85-0XA0 IM157 EtherNet/IP Coupler | ET 200S Interface Module
Engineering Background
The SIEMENS 6ES7157-0AC85-0XA0 is the IM157 EtherNet/IP Interface Module (Coupler) for the ET 200S distributed I/O system — part of Siemens’ SIMATIC S7 automation platform. Designed to integrate ET 200S I/O stations directly into EtherNet/IP networks, this module enables seamless communication between Allen-Bradley / Rockwell Automation PLCs and Siemens ET 200S field I/O, making it a critical interoperability component in mixed-vendor automation architectures.
Product Positioning
Targeted at process engineers and system integrators who require reliable, standards-compliant EtherNet/IP connectivity for distributed I/O in manufacturing, energy, and process automation environments. The IM157 coupler eliminates the need for protocol gateways by natively speaking EtherNet/IP, reducing latency, wiring complexity, and commissioning time.
Complete Technical Specifications
- Part Number: 6ES7157-0AC85-0XA0
- Module Type: IM157 EtherNet/IP Interface Module (Coupler)
- Platform: SIMATIC ET 200S Distributed I/O
- Communication Protocol: EtherNet/IP (CIP)
- Network Interface: 2 × RJ45 (integrated switch, linear/ring topology support)
- Transmission Rate: 10/100 Mbit/s, auto-negotiation
- Supply Voltage: 24 V DC (20.4 – 28.8 V DC)
- Current Consumption: Typ. 200 mA at 24 V DC
- Power Dissipation: Max. 4.8 W
- Max. I/O Modules per Station: Up to 63 ET 200S I/O modules
- Max. Process Data: 128 bytes input / 128 bytes output
- Topology Support: Line, star, ring (MRP)
- Degree of Protection: IP20
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Relative Humidity: 5% to 95% (non-condensing)
- Dimensions (W × H × D): 60 × 81 × 52 mm
- Weight: Approx. 500 g (with packaging)
- Mounting: DIN rail (35 mm)
- Certifications: CE, UL, cULus, ATEX (Zone 2), FM
- MLFB / Order Number: 6ES7157-0AC85-0XA0
Proven Application Environments
- Automotive Manufacturing: Body-in-white assembly lines with mixed Siemens/Rockwell PLC architectures requiring unified EtherNet/IP I/O networks.
- Oil & Gas / Petrochemical: Distributed field I/O in hazardous areas (ATEX Zone 2 rated), connecting ET 200S stations to ControlLogix/CompactLogix controllers.
- Food & Beverage: High-availability ring topologies (MRP) for continuous production lines where network redundancy is mandatory.
- Water Treatment & Utilities: Remote I/O stations in pump houses and substations integrated into plant-wide EtherNet/IP SCADA networks.
- Machine Building (OEM): Modular machine designs where ET 200S I/O flexibility and EtherNet/IP standardization reduce engineering overhead across variants.
Engineering Advantages
- Native EtherNet/IP (CIP): No protocol converter required — direct integration with Rockwell Automation PLCs and any EtherNet/IP scanner device.
- Integrated 2-Port Switch: Supports line topology without external switches, reducing cabinet space and BOM cost.
- Media Redundancy Protocol (MRP): Ring topology support provides sub-200 ms failover for high-availability applications.
- Hot-Swap I/O Modules: ET 200S I/O modules can be replaced under power without station shutdown, minimizing production downtime.
- Compact Form Factor: 60 mm width fits dense DIN rail layouts in space-constrained control cabinets.
- Wide Certification Coverage: CE, UL, ATEX Zone 2 — suitable for global deployment including hazardous area installations.
- STEP 7 / TIA Portal Compatible: Full hardware configuration support in Siemens engineering tools for hybrid project environments.
System Architecture & Signal Flow
The 6ES7157-0AC85-0XA0 acts as the head station of an ET 200S I/O rack. The EtherNet/IP scanner (e.g., Allen-Bradley ControlLogix) communicates with the IM157 coupler over a standard 100 Mbit/s Ethernet network using the CIP protocol. The coupler translates CIP I/O messages into the ET 200S backplane bus, distributing process data to up to 63 downstream I/O modules (digital, analog, motor starter, safety). Return data is aggregated and transmitted back to the scanner in the same CIP I/O cycle.
Typical Signal Flow: EtherNet/IP Scanner (PLC) → Ethernet Switch (optional) → IM157 Coupler (6ES7157-0AC85-0XA0) → ET 200S Backplane Bus → I/O Modules (DI/DO/AI/AO/Motor Starters)
Sourcing & Quality Verification
- Origin: Genuine SIEMENS product — sourced through authorized distribution and verified secondary market channels with full traceability.
- Inspection Standard: Each unit undergoes visual inspection, label verification (MLFB, date code, firmware version), and functional power-on test prior to shipment.
- Condition Options: New-in-box (NIB), factory-refurbished, and tested-used grades available — specify at inquiry.
- Documentation: Original Siemens product documentation, EU Declaration of Conformity, and test report available upon request.
- Counterfeit Risk Mitigation: All units verified against Siemens MLFB structure, holographic labels, and PCB markings. Suspicious units are quarantined and not listed.
Procurement Process
- Step 1 — Inquiry: Submit your RFQ via the product page, email support@konmask.com, or WhatsApp/WeChat +0086 19859288691 with quantity and required delivery date.
- Step 2 — Quote: Receive a formal quotation within 1 business day including unit price, lead time, shipping options, and payment terms.
- Step 3 — Order Confirmation: Confirm PO or proforma invoice. Payment via T/T bank transfer, PayPal, or trade assurance.
- Step 4 — Inspection & Dispatch: Unit inspected, photographed, and packed. Tracking number provided within 24–48 hours of payment clearance.
- Step 5 — After-Sales: 90-day warranty on all tested units. Technical support available for integration and commissioning questions.
Technical FAQ
Q: Is the 6ES7157-0AC85-0XA0 compatible with Allen-Bradley ControlLogix and CompactLogix?
A: Yes. The IM157 is a native EtherNet/IP device and is fully compatible with any EtherNet/IP scanner including Rockwell Automation ControlLogix (L6x/L8x) and CompactLogix (L3x/L4x) platforms. An EDS file is available for RSLogix 5000 / Studio 5000 configuration.
Q: What is the maximum number of I/O modules supported per IM157 station?
A: Up to 63 ET 200S I/O modules per station, with a maximum of 128 bytes input and 128 bytes output process data.
Q: Can this module be used in PROFINET or PROFIBUS networks?
A: No. The 6ES7157-0AC85-0XA0 is exclusively an EtherNet/IP coupler. For PROFINET, use the IM151-3 PN series; for PROFIBUS DP, use the IM151-1 series.
Q: Does the IM157 support Media Redundancy Protocol (MRP) for ring topologies?
A: Yes. The integrated 2-port switch supports MRP, enabling ring topology with sub-200 ms reconfiguration time for high-availability installations.
Q: What firmware version is required for full EtherNet/IP functionality?
A: Firmware V1.0 or higher. Current production units ship with the latest firmware. Firmware version is printed on the module label and can be verified via the web server interface.
Q: Is ATEX certification included for hazardous area use?
A: Yes. The module carries ATEX Zone 2 certification (II 3 G), suitable for use in areas where explosive gas atmospheres may occasionally be present.
