Siemens 6ES7197-1LB00-0XA0 SIMATIC S7-300 IM Interface Module | Replacement, Equivalent & Selection Guide
The Siemens 6ES7197-1LB00-0XA0 is an interface module (IM) for the SIMATIC S7-300 programmable logic controller (PLC) system. Designed for expanding the S7-300 rack configuration, this module enables reliable communication between the central rack and expansion racks in distributed automation architectures. At Konmask.com, we specialize in sourcing, cross-referencing, and supplying original and equivalent automation components for industrial buyers worldwide.
Technical Specifications
- Part Number: 6ES7197-1LB00-0XA0
- Brand: Siemens
- Series: SIMATIC S7-300
- Module Type: Interface Module (IM)
- Function: Rack-to-rack interface / expansion bus connector
- Mounting: DIN rail, S7-300 standard rack
- Country of Origin: Germany
- Weight: 2,600 g (shipping weight)
- Compatibility: SIMATIC S7-300 central and expansion racks
- Standards: CE, UL, IEC 61131-2
Compatible Replacement & Equivalent Models
When the 6ES7197-1LB00-0XA0 is unavailable or discontinued, the following models may serve as functional replacements or equivalents depending on your rack configuration and firmware version. Always verify compatibility with your system integrator before substitution.
- 6ES7197-1LB00-0XA0 — Original model (this listing)
- 6ES7360-3AA01-0AA0 — IM 360 sending interface module (central rack)
- 6ES7361-3CA01-0AA0 — IM 361 receiving interface module (expansion rack)
- 6ES7365-0BA01-0AA0 — IM 365 interface module pair (single-tier expansion)
- 6ES7368-3BB01-0AA0 — Connecting cable for IM 360/361
Note: Cross-reference compatibility depends on firmware revision and rack generation. Contact support@konmask.com for a verified match.
Why Choose the Original Model
- Guaranteed compatibility with all SIMATIC S7-300 rack generations
- Siemens factory quality — tested to IEC 61131-2 industrial standards
- Long-term support — spare parts and firmware updates available through Siemens TIA Portal ecosystem
- Reduced integration risk — no re-engineering or re-validation required
- Traceable provenance — original part with full documentation and CE marking
Typical Applications
- Automotive assembly line PLC rack expansion
- Chemical plant distributed control system (DCS) integration
- Food & beverage processing automation
- Water treatment and utilities SCADA systems
- Machine tool and CNC controller backplane expansion
- Building automation and HVAC control panels
System Compatibility
The 6ES7197-1LB00-0XA0 is designed for use within the Siemens SIMATIC S7-300 platform. Verify the following before ordering:
- Central rack model: S7-300 standard or compact CPU rack
- Expansion rack: ET 200M or S7-300 ER rack
- Programming software: STEP 7 v5.x or TIA Portal V13+
- Bus connector type: K-bus (backplane bus)
- Power supply: PS 307 or equivalent S7-300 PSU
Selection Guide
Use this guide to select the correct interface module for your S7-300 expansion topology:
- Single-tier expansion (1 ER rack): Use IM 365 pair — 6ES7365-0BA01-0AA0
- Multi-tier expansion (up to 3 ER racks): Use IM 360 (CR) + IM 361 (ER) — 6ES7360-3AA01-0AA0 + 6ES7361-3CA01-0AA0
- Replacement / spare for existing installation: Match exact part number — 6ES7197-1LB00-0XA0
- Unsure of topology? Send your rack layout or STEP 7 hardware config to support@konmask.com for a free selection review.
Quality Assurance & Sourcing
- All modules sourced from authorized distributors or verified surplus channels
- Pre-shipment inspection: visual, label verification, and functional check where applicable
- Anti-static packaging with humidity indicator card
- Counterfeit prevention: serial number and hologram label verified against Siemens records
- Warranty: 12 months from date of shipment (DOA replacement within 7 days)
How to Order
- Add 6ES7197-1LB00-0XA0 to cart and proceed to checkout
- For bulk orders (>5 units) or urgent requirements, email support@konmask.com
- Provide your rack configuration or STEP 7 hardware config file for free compatibility verification
- Lead time: in-stock items ship within 1–3 business days; sourced items 5–15 business days
- Payment: T/T, PayPal, credit card, and trade assurance accepted
Replacement & Compatibility FAQ
Q: Is 6ES7197-1LB00-0XA0 discontinued?
A: Please contact us for current stock and lifecycle status. We maintain access to both new and refurbished stock.
Q: Can I use IM 365 instead of IM 360/361?
A: IM 365 supports only one expansion rack. For multi-rack expansion, IM 360 + IM 361 is required.
Q: Will this module work with TIA Portal?
A: Yes, SIMATIC S7-300 hardware is supported in TIA Portal V13 and later via the S7-300 hardware catalog.
Q: Do you provide a certificate of conformity?
A: Yes, CoC and test reports are available upon request for orders of 3+ units.
Q: What is the lead time for out-of-stock items?
A: Typically 5–15 business days depending on sourcing channel. Contact us for urgent requirements.
