Siemens 6ES7272-0AA30-0YA1 TD 200 Text Display Operator Interface – SIMATIC S7-200 Series
Imagine a production line running unattended overnight — a pump cavitates, a temperature threshold is breached, or a conveyor jams. Without a reliable local operator interface, the machine offers no feedback, no alarm acknowledgment, and no way for maintenance staff to intervene without a laptop and engineering software. Downtime compounds. The Siemens 6ES7272-0AA30-0YA1 TD 200 Text Display eliminates this vulnerability by placing real-time process messages, alarm text, and parameter adjustment capability directly at the machine panel — no PC required.
The 6ES7272-0AA30-0YA1 is the third-generation TD 200 operator panel within the Siemens SIMATIC S7-200 Micro PLC ecosystem — one of the most widely deployed compact automation platforms in global manufacturing history. Designed specifically to interface with S7-200 CPUs via the PPI (Point-to-Point Interface) port, this unit delivers a cost-effective, space-saving HMI solution for OEM machinery, process skids, and standalone automation cells across industries worldwide. Its longevity in the field and broad installed base make it a critical spare part for facilities that continue to operate legacy S7-200 infrastructure.
Technical Specifications
- Part Number: 6ES7272-0AA30-0YA1
- Product Family: SIMATIC S7-200 TD 200 Text Display
- Display Type: 2-line × 20-character LCD text display
- Interface: PPI (RS-485) via S7-200 CPU communication port
- Power Supply: Powered directly from S7-200 CPU port (no separate PSU required)
- Number of Function Keys: 8 programmable function keys (F1–F4 × 2 shift levels)
- Messages: Up to 80 user-defined text messages
- Languages Supported: Configurable via STEP 7-Micro/WIN software
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Rating: IP65 (front panel)
- Dimensions (W × H × D): 182 mm × 74 mm × 33 mm
- Weight: Approx. 250 g
- Mounting: Panel cutout mounting with snap-in clips
- Certifications: CE, UL, cUL
Key Features & Benefits
- Zero-wiring power: Draws power directly from the S7-200 CPU port — eliminates the need for a dedicated 24 VDC supply to the HMI panel.
- Plug-and-play connectivity: Connects via standard MPI/PPI cable to any S7-200 CPU; no additional communication modules required.
- 80 configurable text messages: Display process status, alarm conditions, and operator prompts in plain language — reducing reliance on trained PLC engineers for routine diagnostics.
- 8 programmable function keys: Allow operators to trigger setpoint changes, acknowledge alarms, or switch operating modes without accessing the PLC program.
- IP65 front panel: Sealed against dust and water jets — suitable for wash-down environments, food processing areas, and outdoor enclosures.
- Compact form factor: Fits standard 182 × 74 mm panel cutout; ideal for space-constrained control cabinets and machine panels.
- Long-term availability: As a proven legacy component, the 6ES7272-0AA30-0YA1 remains available as a genuine and tested replacement unit through specialist distributors like Konmask.com.
Industry & Equipment Applications
- Food & Beverage: Conveyor control panels, filling machine HMIs, pasteurizer monitoring stations
- Water & Wastewater: Pump station local control panels, dosing system interfaces
- Packaging Machinery: OEM wrapping, labeling, and cartoning machine operator panels
- HVAC & Building Automation: Air handling unit control panels, chiller plant local displays
- Plastics & Rubber: Injection molding machine auxiliary panels, extruder control stations
- General Manufacturing: Assembly line status displays, test rig operator interfaces
System Integration & Compatible Parts
The 6ES7272-0AA30-0YA1 is designed for seamless integration within the Siemens SIMATIC S7-200 control system. Compatible and commonly paired components include:
- S7-200 CPUs: CPU 221, CPU 222, CPU 224, CPU 224XP, CPU 226 (all variants)
- Programming Cable: 6ES7901-3CB30-0XA0 (PC/PPI cable, USB)
- Communication Module: 6ES7241-0BC22-0XA0 (EM 241 Modem Module)
- Power Supply: 6EP1331-1SH03 (SITOP PSU100S 24 VDC/0.5 A) — for cabinet power
- Expansion Modules: EM 221, EM 222, EM 223 digital I/O modules
- Software: STEP 7-Micro/WIN V4.0 SP9 (required for TD 200 message configuration)
Our Quality Assurance Process
Every Siemens 6ES7272-0AA30-0YA1 unit supplied by Konmask.com undergoes a structured verification process before dispatch:
- Visual Inspection: Housing integrity, connector condition, label legibility, and absence of physical damage assessed against OEM standards.
- Functional Verification: Where applicable, units are powered and communication port functionality is confirmed.
- Authenticity Check: Part markings, date codes, and firmware version labels are cross-referenced against Siemens documentation to screen for counterfeit components.
- Secure Packaging: Anti-static packaging with moisture barrier and shock-absorbing foam — compliant with IEC 60068 transport requirements.
- Documentation: Shipment includes packing list with part number, serial/batch reference, and inspection sign-off.
How to Order
- Submit your inquiry via the “Request a Quote” button on this page, or email [email protected].
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation, freight, and tracking.
- For urgent requirements, please indicate “URGENT” in your subject line for priority handling.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and drive components — not a generalist marketplace.
- Global Export Experience: We ship to 60+ countries with full export documentation, commercial invoices, and packing lists.
- Legacy Component Expertise: Discontinued and hard-to-find parts are our core competency — we maintain stock of obsolete Siemens S7-200 components.
- Responsive B2B Service: Dedicated account support for MRO buyers, system integrators, and OEM procurement teams.
- Transparent Sourcing: We disclose product condition (new, tested-used, refurbished) clearly on every quotation.
Frequently Asked Questions
Q: Is the Siemens 6ES7272-0AA30-0YA1 still in production?
A: The S7-200 series, including the TD 200 Text Display, has been discontinued by Siemens. However, Konmask.com maintains stock of genuine units sourced from authorized channels and decommissioned systems. Contact us for current availability.
Q: What software is required to configure the TD 200?
A: Configuration is performed using STEP 7-Micro/WIN (V4.0 or later) via the TD 200 Wizard. The software is available from Siemens Industry Online Support.
Q: Can the 6ES7272-0AA30-0YA1 work with S7-300 or S7-1200 PLCs?
A: No. The TD 200 uses the PPI protocol specific to the S7-200 CPU communication port and is not compatible with S7-300, S7-400, S7-1200, or S7-1500 series PLCs.
Q: What is the difference between 6ES7272-0AA30-0YA1 and earlier TD 200 versions?
A: The “-0YA1” suffix denotes the third hardware revision of the TD 200, incorporating minor firmware and manufacturing improvements over the “-0XA0” and “-0XA8” variants. All versions share the same functional specification and are interchangeable in most applications.
Q: Do you provide a warranty on this part?
A: Yes. Konmask.com provides a standard 90-day functional warranty on all tested units. Terms are detailed in our quotation documentation.
